Side & Front View/ 側面和前面
434mm
421mm
Case Features / 機殼特色
IO Panel / IO面板
216mm
210mm
499mm
Optimized Air Flow
RGB Fan Included
Tool-Less Tempered Glass
最佳風流設計
內含RGB風扇
無螺絲與強化玻璃側板
ARGB Fan Included
Mystic Light
1 to 6 ARGB Control Board
內含ARGB風扇
支援燈效軟體
1對6 ARGB 控制板
1
2
3
1. LED switch button / LED切換按鈕
2. USB 3.2 Gen1 Type A
3. Mic in / 音訊輸入
4. Audio out / 音訊輸出
5. Reset button / 重新開機按鈕
6. Power button / 電源按鈕
Magnetic Filter
磁吸防塵網
For MAG FORGE 100R only
僅 MAG FORGE 100R 支援
4
5
6
Advertisement
Related Manuals for MSI MAG FORCE 100M
Summary of Contents for MSI MAG FORCE 100M
- Page 1 Case Features / 機殼特色 Optimized Air Flow RGB Fan Included Tool-Less Tempered Glass Magnetic Filter 最佳風流設計 內含RGB風扇 無螺絲與強化玻璃側板 磁吸防塵網 For MAG FORGE 100R only 僅 MAG FORGE 100R 支援 ARGB Fan Included Mystic Light 1 to 6 ARGB Control Board 內含ARGB風扇...
- Page 2 Accessories / 配件 Specification / 產品規格 Item 項目 Name 名稱 / Q’ty 數量 Used for 用途 MAG FORGE 100M MAG FORGE 101M MAG FORGE 100R 1 to 6 RGB (4pin) 1 to 6 RGB (4pin) 1 to 6 ARGB (3pin) Fan LED Controller Cable ties Control Board...
- Page 3 SYS_FAN ⚠ Note / 注意 ∙ This LED Hub can support up to 10 MSI devices or 6 non-MSI devices. ∙ Each port can support a maximum of 64 ARGB LEDs, with a total of no more than SATA Power 128 LEDs.
-
Page 4: Caractéristiques Du Boîtier
Caractéristiques du boîtier Optimized Air Flow RGB Fan Included Tool-Less Tempered Glass Magnetic Filter Pour MAG FORGE 100R ARGB Fan Included Mystic Light Carte de contrôle ARGB 1 à 6 Vue de face et de côté Panneau E/S 434mm 216mm 421mm 210mm 499mm... -
Page 5: Caractéristiques
Accessoires Caractéristiques Élément Nom / Quantité Utilisé pour MAG FORGE 100M MAG FORGE 101M MAG FORGE 100R Carte de contrôle Carte de contrôle Carte de contrôle Contrôleur LED du Attaches de câble RGB 1 à 6 RGB 1 à 6 ARGB 1 à... - Page 6 SYS_FAN SYS_FAN ⚠ Remarque Alimentation ∙ Ce Hub LED supporte jusqu’à 10 appareils MSI ou 6 appareils non MSI. SATA ∙ Chaque port peut supporter un maximum de 64 LED ARGB, le nombre total de LED ne peut excéder 128.
