Samsung VXK-306 Service Manual

MODEL : VXK-306/336
~XK-307/337-
VXK-306/336
|
|
|
|
|
|
|
|
|
L
VXK-307/337
ee
:
a ee
a
SPECIFICATIONS
Format: VHS PAL standard AUDIO
Video Recording
Input:
Line ; -8 dBm, 50 Kohin unbalanced
VXK-306/307 ; 2 Rotary Heads
VXK-336/337 ; Double Azimuth 4 Rotary Heads
Luminance ; FM Azimuth recording
Color ; Down converted subcarrier phase
shifted direct recording
CCIR standard (B/G System)
12.65 mm G/2 inch)
Output:
Wow-Flutter (WTD) :
1.2% Max (LP)
40 dB Min (HF'A FILTER)
100Hz ~ 8KHz (SP)
100Hz ~ SKHz (LP)
Signal-Noise Ratio :
_- Frequency Response:
Television Systein :
Tape Width :
Tape Speed :
SP : 23.39 mm/sec
LP: 11.69 mm/sec ~
Receiving Channel :
Power Requirement :
VHF LOW, VHF HIGH,UHF
230V (AC 50/60H2)
i
Operation Temperature: 41° F~ 104° F(5° C~ 40°C) |
Weight: 5 Kg
Better than 43 JB (SP), Better than 40 dB (LP)
More than 240 lines (SP)
More than 220 lines (LP)
Signal-to-Noise Ratio:
Horizontal Resolution :
ee
Printed in Korea
NOV. 1993
