VIDEO CASSETTE RECORDER
Chassis : Khan II
VR8460
SERVICE
If you want to know additional information which is not included on this Service Manual, please refer to the
VR8460 Training Manual (AC82-00088A).
VIDEO CASSETTE RECORDER
POWER
EJECT
REW
F.F
PLAY
REC
STOP
CHANNEL
MENU
Manual
CONTENTS
5. Block Diagram
