DEHUMIDIFIER
ND288
PRODUCT FEATURES
AUTO
PREFERRED
HUMIDITY
HUMIDITY
SENSOR
SETTING
CONTINUOUS
AUTO STOP
DRAINAGE
WITH FULL
OPTION
TANK INDICATOR
OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION
Please read instructions before using the Dehumidifier
PROG.
CFC FREE
TIMER
REFRIGERANT
EASY ROLL
COMPACT
CASTORS
& HANDY
HUMICONTROL
S A F E G U A R D I N G V A L U A B L E S E R I E S
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HumiControl ND288 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Novita HumiControl ND288

Summary of Contents for Novita HumiControl ND288

  • Page 1 HUMICONTROL S A F E G U A R D I N G V A L U A B L E S E R I E S DEHUMIDIFIER ND288 PRODUCT FEATURES AUTO PROG. CFC FREE PREFERRED HUMIDITY TIMER REFRIGERANT HUMIDITY SENSOR SETTING CONTINUOUS...

  • Page 2: Table Of Contents

    LIMITED WARRANTY EXTENSION - EXTENDED WARRANTY This product includes: • novita Dehumidifier ND288 • novita Dehumidifier ND288 Operating Instructions & e-Warranty Application (e-copy) • Starter Guide * Please contact us immediately if any of the above-mentioned items are not included.

  • Page 3: Product Description

    PRODUCT DESCRIPTION Dehumidifier ND288 FRONT VIEW BACK VIEW Air Outlet Easy Roll Castor Water Float Sensor Control Panel Housing Water Tank Carrying Handle Pre-Filter Screen Power Cord & Plug Water Tank Compartment Enhanced Pre-Mesh Activated Carbon Filter (Optional) Water Tank Handle Continuous Drainage Port CONTROL PANEL DESCRIPTIONS Power ON/OFF Button...

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS Rated Power 190 Watts (30 C/80% RH) Max. Consumption 200 Watts (35 C/90% RH) Extraction Rate 12L/Day (30 C/80% RH) Voltage/Frequency 220-240V/50Hz Humidity Setting Available Auto Humidity Sensor Available Easy Roll Castors Available Running Temperature C to 35 Refrigerant/Charge Limit R290/0.058 Kg Empty Weight...

  • Page 5: Fan Speed

    Fan Speed Packed with 2 fan speed settings of high and low to satisfy different usage requirement. Auto Dehumidification Mode At auto dehumidification mode, the humidity level is auto pre-set and regulated between 45% RH to 55% RH to provide a comfortable range of humidity level. Programmable Timer At either ON or OFF Mode, the unit can be programmed with a timer from 01 to 24 hours for an automatic shut off or start up respectively.

  • Page 6: Auto-Shut Off Function

    Auto-Shut Off Function Unit shut off automatically with full water tank indicator in red in the following circumstances: • Water tank is full. • Water tank is not placed properly. • Water tank is removed. Room Humidity Display The display screen also shows the relative humidity level of the room/surrounding for user easy reference and to facilitate the humidity level adjustments accordingly to individual preference.

  • Page 7: Pre-Filter Screen & Enhanced Pre-Mesh Activated Carbon Filter

    Pre-Filter Screen & Enhanced Pre-Mesh Activated Carbon Filter ◊ Pre-Filter Screen at the back panel sieves out contaminants from the air that is drawn into the unit. This process increases the efficiency of the unit and helps to filter the air that is released back into the surroundings.

  • Page 8: Using The Novita Dehumidifier

    USING THE NOVITA DEHUMIDIFIER Setting Up 01. Remove all packaging materials and place the unit on a dry, stable and level surface. • DO NOT remove the polystyrene from the water tank. 02. Remove the water tank and then proceed to grasp the grooves at the bottom of the pre-filer screen and slide it downwards to remove it from the unit.
  • Page 9 03. Programmable Timer Unit can be programmed with a timer from 01 to 24 hours at an interval of 1 hour time for an automatic shutoff or start up respectively and its unit corresponding light indicator illuminates. TIMER • The programmable timer function will deactivate when user turns off the unit before the programmable timer duration is up.

  • Page 10: Emptying The Water Tank

    Compressor resumes its normal operation once the defrosting process is completed. EMPTYING THE WATER TANK novita Dehumidifier ND288 shuts off automatically when the water tank is full and its corresponding full FULL tank light indicator flashes and beep 3 times. Follow the simple steps below to empty the water tank.

  • Page 11: Cleaning & Maintenance

    It is recommended to perform weekly cleaning & maintenance for unit optimum performance. CLEANING & MAINTENANCE Cleaning the novita Dehumidifier It is important to conduct service maintenance of the unit at least once a week to ensure unit optimum performance and to prevent dust/dirt built up at the continuous drainage outlet port and water float sensor, which may lead to water leakage.
  • Page 12 Cleaning the Pre-Filter Screen For optimum performance, it is recommended to clean the pre-filter screen once every 2 weeks. Hold onto both sides of the water tank and pull the water tank outwards to remove it from the unit. Grasp the grooves at the Remove Remove bottom of the prefilter screen and slide it downwards to remove it...

  • Page 13: Troubleshooting

    • Water tank not placed properly. • Remove water tank and replace it into the unit again. • Power plug or cord damaged. • Contact novita Customer Care Centre. Fan not working • Motor may be malfunction. • Contact novita Customer Care Centre.

  • Page 14: Safety Precautions

    Error code • Temperature sensor error. • Please contact novita Customer message E1 Care Centre. □ It is recommended to confine to the stated recommended coverage area for effective and optimum dehumidification performance.

  • Page 15: Safety Instructions

    Before moving the unit • Repairs of appliance should only be done by qualified service technicians from novita. Improper repair work can cause considerable danger to the user. DO NOT replace the power cord without authorization or connect the power cord midway or use it in parallel with other high power electrical appliances.

  • Page 16: Novita Customer Service Guarantee

    Service Trekking* With everyone’s busy schedule, it’s sometimes hard to keep track of everything. Sit back, relax and leave the fussing to us. Instead of calling and checking up on the status of your product, let novita keeps you updated.

  • Page 17: Limited Warranty Terms & Conditions

    negligence.

  • Page 18: Limited Warranty Extension - Extended Warranty

    HumiControl™ Dehumidifier ND288 NEXT 12 MONTHS STANDARD EXTENDED S$60/Unit LIMITED WARRANTY T & C Updates Commission/Effective from 08 Dec 2023 • All Information is accurate at the point of print. novita reserves all rights to update the information without prior notice.
  • Page 19 COPYRIGHT © 2023 NOVITA SG SV/M/ND288/V1...
