PRODUCT FEATURES
SEMI-
AUTO
PERMANENT
HUMIDITY
BUILT-IN IONIZER
SENSOR
LAUNDRY
AIR
DRYING
PURIFYING
MODE
MODE
CONTINUOUS
EASY
DRAINAGE
ROLL
CASTORS
OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION
Please read instructions before using the Dehumidifier
AUTO
PREFERRED
MODE
HUMIDITY
SETTINGS
SLEEP
TIMER
MODE
ROTARY
COMPRESSOR
OPTION
LAUNDRYFRESH
L A U N D R Y D R Y I N G S E R I E S
DEHUMIDIFIER
ND838i
NEW & ENHANCED
NEW & ENHANCED
CONFIGURATION
CONFIGURATION
TM
34.8L/DAY
EXTRACTION RATE
COMPLETE
LAUNDRYFRESH
™
EXPERIENCE
LAUNDRY DRYING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAUNDRYFRESH ND838i and is the answer not in the manual?

Questions and answers

Related Manuals for Novita LAUNDRYFRESH ND838i

Summary of Contents for Novita LAUNDRYFRESH ND838i

  • Page 1 LAUNDRYFRESH L A U N D R Y D R Y I N G S E R I E S DEHUMIDIFIER ND838i NEW & ENHANCED NEW & ENHANCED CONFIGURATION CONFIGURATION PRODUCT FEATURES 34.8L/DAY EXTRACTION RATE AUTO SEMI- AUTO PREFERRED MODE PERMANENT HUMIDITY HUMIDITY...

  • Page 2: Table Of Contents

    LIMITED WARRANTY EXTENSION - EXTENDED WARRANTY This product includes: • novita Dehumidifier ND838i • novita Dehumidifier ND838i Operating Instructions & e-Warranty Application (e-copy) • 1 x PVC Hose (14 mm inner diameter) • Starter Guide * Please contact us immediately if any of the above-mentioned items are not included.

  • Page 3: Product Description

    PRODUCT DESCRIPTION Dehumidifier ND838i FRONT VIEW BACK VIEW SIDE VIEW Carrying Handle Water Tank Water Level Indicator Easy Roll Castors Continuous Drainage Outlet Air Outlet Semi-Permanent Built-In Ionizer Oscillating Flaps Control Panel Air Inlet Frame Pre-Filter Screen Enhanced Dual Mesh Activated Carbon Filter ◊...

  • Page 4: Control Panel Description

    CONTROL PANEL DESCRIPTION 01. Power Control 10. Prog. Mode (Laundry Drying, 17. Fan Speed Indicator 02. Auto Dehumidification Mode Purify or Sleep) 18. Timer Indicator 03. Anion Mode 11. Auto Dehumidification 19. Full Tank Indicator 04. Increase Setting Mode Indicator 20.

  • Page 5: Features

    FEATURES Laundry Drying Mode Besides functioning as a portable dehumidifier to safeguard your valuables from moisture and mold, ND838i also doubles up as an effective laundry drying device with 4 accompanying features - Enhanced Dual Mesh Activated Carbon Filter , Dehumidification, Negative Ions and Controlled Ozone Concentration via ◊...

  • Page 6: Air Purifying Mode

    Air Purifying Mode Air Purifying Mode helps to eliminate airborne allergens to improve the air quality. At this mode, dehumidification function will be deactivated while unit continues to run on high fan speed setting to purify the air. • At air purifying mode, dehumidification function is programmed to be deactivated hence user is unable to select RH% level setting, while fan speed setting can be manually adjusted in accordance to user preference.

  • Page 7: Manual Humidity Setting Control

    Manual Humidity Setting Control Under Manual Dehumidifying Mode, user can set the humidity level according to individual’s desire within a range of 30% to 80% RH in intervals of 5% RH. Selected RH% level will be displayed on the LCD screen. •...

  • Page 8: Timer Function

    Timer Function At ON Mode, the unit can be programmed with a timer from 1 to 24 hours at an interval of 1 hour for an automatic shutoff. Oscillating Air Outlet Oscillating flap oscillates from 45˚ to 85˚ for better air circulation and optimum diffusion of the dehumidified air throughout the room.

  • Page 9: Defrost Mode

    Defrost Mode Defrost Mode will be activated automatically when room temperature drop to 4 C and below. Defrost indicator appears on the LCD screen as sensor detects the drops in temperature. Compressor shuts off and unit runs on high fan speed setting. •...

  • Page 10: 2-In-1 Air Inlet Frame And Pre-Filter Screen

    2-In-1 Air Inlet Frame and Pre-Filter Screen & Enhanced Dual Mesh Activated Carbon Filter ◊ The 2-In-1 Air Inlet Frame and Pre-Filter Screen at the back panel sieves out contaminants from the air that is drawn into the unit. This process increases the efficiency of the unit and helps to filter the air that is released back into the surroundings.

  • Page 11: Using The Novita Dehumidifier

    USING THE NOVITA DEHUMIDIFIER Setting Up 01. Remove all packaging materials and place the unit on a dry, stable and level surface. • DO NOT remove the polystyrene from the water tank. 02. From the back of the unit, grasp the top handle of the 2-In-1 Air Inlet Frame and Pre-Filter Screen and pull it outwards to remove it from the unit.
  • Page 12 03. Press Auto button once to activate Auto Dehumidification Mode and its corresponding indicator will be illuminated on the display screen. At this mode, unit runs automatically in accordance to the ambient humidity level detected. Ambient RH% Detected 55% ≤ RH% ≤ 65% RH% >65% RH% <...

  • Page 13: Emptying The Water Tank

    RH% setting when the power is restored. Emptying the Water Tank novita Dehumidifier ND838i shuts off automatically when the water tank is full and unit beeps 5 times with indicator illuminated on the display screen. Follow the simple steps below to empty the water tank.

  • Page 14: Cleaning & Maintenance

    Pre-Filter Screen back onto the unit. • DO NOT use the dehumidifier without the 2-In-1 Air Inlet Frame and Pre-Filter Screen in place. CLEANING & MAINTENANCE Cleaning the novita Dehumidifier It is important to conduct service maintenance of Front Back...

  • Page 15: Cleaning The Aircare™ Air Sterilizer Nas

    Cleaning the novita AirCare™ Air Sterilizer NAS 03 ◊ To enhance the overall LaundryFresh™ experience, we recommend to perform cleaning and maintenance of the unit once every 240 hours/1 month* from initial usage for optimum performance. ◊ AirCare™ Air Sterilizer NAS 03 is an optional product accessory and can be purchased separately.

  • Page 16: Troubleshooting

    • Water tank not placed properly. • Remove water tank and replace it into the unit again. • Power plug or cord damaged. • Contact novita Customer Care Centre. Fan not working • Motor may be malfunction. • Contact novita Customer Care Centre.

  • Page 17: Safety Precautions

    CONDITION POSSIBLE CAUSE POSSIBLE SOLUTION • Temperature sensor malfunction. • Contact novita Customer Care Centre. E1 error message flashes on the LCD screen every 30 seconds E2 error message • Humidity sensor malfunction. • Contact novita Customer Care Centre. flashes on the LCD...

  • Page 18: Safety Instructions

    Service Trekking* With everyone’s busy schedule, it’s sometimes hard to keep track of everything. Sit back, relax and leave the fussing to us. Instead of calling and checking up on the status of your product, let novita keeps you updated.

  • Page 19: E-Warranty Application

    By submitting your e-warranty application, you have agreed to all the terms and conditions stated for this warranty. We hope you find it a breeze to dry your laundry with novita LaundryFresh™ Dehumidifier ND838i. LIMITED WARRANTY TERMS & CONDITIONS...
  • Page 20 Replacement parts and Products assume the remaining original limited warranty. In the event that the Product is out of stock, obsolete or beyond repair, novita reserves all rights to replace the Product with another similar value as deem appropriate, subject to availability.

  • Page 21: Limited Warranty Extension - Extended Warranty

    LaundryFresh™ Dehumidifier ND838i NEXT 12 MONTHS STANDARD EXTENDED S$120/Unit LIMITED WARRANTY T & C Updates Commission/Effective from 08 Dec 2023 • All Information is accurate at the point of print. novita reserves all rights to update the information without prior notice.
  • Page 22 COPYRIGHT © 2023 NOVITA SG SV/M/ND838i/V1...
