Novita PuriDry ND60 Operating Instructions And E-Warranty Application

2-in-1 dehumidifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THE HIGHEST CAPACITY
CONSUMER UNIT
2-IN-1 DEHUMIDIFIER
ND60
PRODUCT FEATURES
SEMI-
AUTO
PERMANENT
HUMIDITY
BUILT-IN IONIZER
SENSOR
SLEEP
TIMER
MODE
50% RH
01
REGULATE
HUMIDITY
LEVELS
OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION
Please read instructions before using the Dehumidifier
PREFERRED
LAUNDRY
HUMIDITY
DRYING
SETTINGS
MODE
ROTARY
AUTO-SHUT OFF
CONTINUOUS
COMPRESSOR
WITH FULL TANK
INDICATOR
02
DEHUMIDIFY
EXCESSIVE
MOISTURE
H11
HEPA
FILTRATION
DRAINAGE
OPTION
03
DRYING
EFFECTIVE INDOOR
LAUNDRY DRYING
UP TO 20 MILLION
UP TO 20 MILLION
NEGATIVE IONS / CM³
NEGATIVE IONS / CM³
04
PURIFY
WITH H11 HEPA &
ACTIVATED CARBON FILTER
10
TEN YEARS
WARRANTY
COVERAGE
ON COMPRESSOR
POWERFUL · STABLE · DURABLE
SINGAPORE'S
HIGHEST
capacity consumer
dehumidifier at
ℓ
60
/day
05
IONIZE
REFRESHING
INDOOR AIR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PuriDry ND60 and is the answer not in the manual?

Questions and answers

Related Manuals for Novita PuriDry ND60

Summary of Contents for Novita PuriDry ND60

  • Page 1 THE HIGHEST CAPACITY CONSUMER UNIT 2-IN-1 DEHUMIDIFIER ND60 UP TO 20 MILLION UP TO 20 MILLION NEGATIVE IONS / CM³ NEGATIVE IONS / CM³ TEN YEARS WARRANTY COVERAGE ON COMPRESSOR POWERFUL · STABLE · DURABLE PRODUCT FEATURES SINGAPORE’S HIGHEST capacity consumer dehumidifier at SEMI- AUTO...

  • Page 2: Table Of Contents

    LIMITED WARRANTY EXTENSION – EXTENDED WARRANTY This product includes: • novita 2-In-1 Dehumidifier ND60 • novita 2-In-1 Dehumidifier ND60 Operating Instructions & e-Warranty Application (e-copy) • Starter Guide • 1 x 2 Metres PE Hose (16 mm inner diameter) • 1 x H11 HEPA & Granular Activated Carbon Filter •...

  • Page 3: Product Description

    PRODUCT DESCRIPTION 2-In-1 Dehumidifier ND60 FRONT VIEW BACK VIEW Semi-Permanent Water Level Indicator Rear Panel Casing Built-In Ionizer Water Tank Groove Continuous Drainage Air Outlet Oscillation Flap Outlet Port 2-In-1 Air Inlet Frame Control Panel & Pre-Filter Screen Cord Holder Carrying Handle Enhanced Dual Mesh Power Cord &...

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS Voltage / Frequency 220-240V 50Hz 700 Watts Rated Power (27℃/60%RH) 1010 Watts Max. Power (35°C/80%RH) Extraction Rate (30°C/80%RH) - 60L/Day - 45L/Day (With H11 HEPA Filter) Humidity Setting Available Auto Humidity Sensor Available Operating Temperature 5°C - 35°C Compressor Rotary R410A...

  • Page 5: Filtration System

    FILTRATION SYSTEM STEP STEP STEP STEP STEP 2B-1 2B-2 PRE-FILTER FILTER TYPE 1: FILTER TYPE 2: FILTER TYPE 2: BUILT-IN IONIZER SCREEN ENHANCED DUAL MESH GRANULAR ACTIVATED H11 HEPA (SEMI-PERMANENT) ACTIVATED CARBON FILTER CARBON FILTER FILTER ◊ ◊ LEGEND ALLERGENS COARSE DUST HAIR...

  • Page 6: Features

    FEATURES Laundry Drying Mode Besides functioning as portable dehumidifier to safeguard your valuables from moisture and mold, ND60 also doubles up as an effective laundry drying device. DRYING - REMOVING EXCESS MOISTURE Remove excess moisture in the air and maintain ideal humidity conditions to prevent mold and mildew growth.

  • Page 7: Humidity Setting Control

    Humidity Setting Control User can set the humidity level according to individual’s desire within a range of 30% to 80% RH at an interval of 5% RH or Continuous Dehumidification Mode. Selected RH% level will be displayed on the display screen. •...

  • Page 8: Sleep Mode

    Sleep Mode Unit is programmed with a sleep mode function whereby upon activation, all the light indicators on the control panel stops illuminating after 10 seconds and low fan speed will be activated for an undisturbed operation. To wake the unit up, simply press any button, then select your desired operating setting. Timer Function At On Mode, the unit can be programmed with a timer from 01 to 24 hours at an interval of 1 hour for an automatic shutoff.

  • Page 9: Defrost Mode

    Defrost Mode Defrost Mode will be activated automatically with “F” shown on the display screen when room temperature drops to 4 C and below. The compressor stops operation and unit runs of high fan speed setting until the defrosting process is completed. Auto-Shut Off with Full Tank Indicator Unit shuts off automatically with full water tank indicator illuminates and unit beeps 5 times in following...

  • Page 10: Continuous Drainage Option

    Continuous Drainage Option Side View Continuous Drainage Outlet Port Rubber Plug Obstruction-Free Drainage Pipe Stable & Level Surface Continuous drainage option allows easy removal of collected water instead of manually empty from the water tank. Using the continuous drainage option: 01.

  • Page 11: Using The Novita 2-In-1 Dehumidifier

    USING THE NOVITA 2-IN-1 DEHUMIDIFIER Setting Up 01. Remove all packaging materials and place the unit on a dry, stable and level surface. • DO NOT remove the polystyrene from the water tank. 02. From the back of the unit, grasp the upper latch of the 2-In-1 air inlet frame & pre-filter screen and pull it outwards to remove it from the unit.

  • Page 12: Operating Notes

    Operating Notes 01. Power Control Press the power button once to turn on the unit. By default, unit runs on Manual Dehumidifying Mode. • To turn off the unit, press button once again. • If the dehumidifier is turned off and then turn on again immediately, the unit will take approximately 3 minutes to reach the full power of the compressor.

  • Page 13: Emptying The Water Tank

    • At sleep mode, simply press any button to wake the unit up, then select your desired operating setting. Emptying the Water Tank novita Dehumidifier ND60 shut off automatically when the water tank is full and unit beeps 5 times with indicator illuminating on the display screen. Follow the simple steps below to empty the water tank.

  • Page 14: Months* Enhanced Dual Mesh Activated Carbon Filter Replacement

    6 Months* Enhanced Dual Mesh Activated Carbon Filter Replacement For an optimum air purification performance, it is recommended to replace the Enhanced Dual Mesh Activated Carbon Filter once every 6 months*/approx. 1,500 hours from initial usage. * Based on average 8 hours a day, 7 days a week usage under normal domestic indoor environment. •...

  • Page 15: Cleaning & Maintenance

    • DO NOT use the dehumidifier without the 2-in-1 air inlet frame & pre-filter screen in place. “CLICK” “CLICK” CLEANING & MAINTENANCE Cleaning the novita Dehumidifier Front Side It is important to conduct service maintenance of the unit at least once a week to ensure unit...
  • Page 16 Cleaning the 2-in-1 Air Inlet & Pre-Filter Screen For optimum performance, it is recommended to clean the 2-in-1 air inlet frame & pre-filter screen once every 2 weeks. From the back of the unit, grasp the latch of the 2-in-1 air inlet frame &...

  • Page 17: Troubleshooting

    • Remove water tank and re-assemble it into the unit again. • Power plug or cord damaged. • Contact novita Customer Care Centre. Fan not working. • The desired RH% setting is achieved. • Set the desired RH% lower than the surrounding humidity level.
  • Page 18 • Internal drainage passage is blocked or • Contact novita Customer Care Centre. obstructed. Display screen • The ambient humidity is lower than 30% RH.

  • Page 19: Safety Precautions

    SAFETY PRECAUTIONS DO NOT pull or tug the unit by Keep the unit away from Refrain from placing the Servicing should only be the power cord to prevent flammable liquids. dehumidifier in confined closets. conducted by professional safety hazards or damage to service technicians.

  • Page 20: Novita Customer Service Guarantee

    Service Trekking* With everyone’s busy schedule, it’s sometimes hard to keep track of everything. Sit back, relax and leave the fussing to us. Instead of calling and checking up on the status of your product, let novita keeps you updated.

  • Page 21: Limited Warranty Terms & Conditions

    negligence.

  • Page 22: Limited Warranty Extension - Extended Warranty

    PuriDry™ 2-In-1 Dehumidifier ND60 NEXT 12 MONTHS STANDARD EXTENDED S$160 /Unit LIMITED WARRANTY T & C Updates Commission/Effective from 08 Dec 2023 • All Information is accurate at the point of print. novita reserves all rights to update the information without prior notice.
  • Page 23 Notes...
  • Page 24 COPYRIGHT © 2023 NOVITA SG SV/M/ND60/V2...
