INSTRUCTIONS:
------------------------
Press keys listed in the menu at the bottom of the screen.
This program only displays information. It cannot make changes.
Numbers preceeded by "0x" are hexadecimal.
PCI BIOS detected, version 2.10
Quatech PCI adapters detected
---------------------------------------------
QSC-200/300 Four-port RS-232 adapter
Uses IRQ 3
Base addr 1 = 0xff80
_
Q - Quatech PCI adapters
N - Other PCI devices
X - EXIT
Figure 16 shows the Expert Mode display for the QSC-200/300 after the "Q" key has
been pressed. The information from the Basic Mode display is presented along with more details
such as the Vendor and Device IDs, PCI Class Code, size of memory and I/O regions, etc.
Pressing the "N" key will show similar information for all non-Quatech PCI devices in the
system, including those devices integrated on the motherboard. In this example, the "Base addr
0" resource is reserved.
Quatech QSC-200/300 Users Manual
Quatech PCI Configuration Information Display Software
Version 1.00
I/O
Figure 15 --- QTPCI.EXE Basic Mode display
(Hardware Revision A1)
M - Change to Expert Mode
