Classeq Eco 1 Installation And Operation Manual
Under counter glasswashers/dishwasher
Hide thumbs
Also See for Eco 1:
- Installation & operation instructions (33 pages) ,
- Installation & operator's manual (20 pages)
Table of Contents
Advertisement
Installation and Operations Manual
The Classeq Under Counter Range
G
l
a
s
s
w
a
s
h
G
l
a
s
s
w
a
s
h
Eco 1
Eco 2
Eco 3
Duo 2
Duo 3
Service
0844 2245 245
0844 2245 252
Spares
0844 2245 249
Sales
www.classeq.co.uk
e
r
s
D
i
e
r
s
D
i
Hydro 400
Hydro 700
Hydro 750
service@classeq.co.uk
spares@classeq.co.uk
sales@classeq.co.uk
Page 1
Document Number: 902.001111/29/2012
s
h
w
a
s
h
e
r
s
h
w
a
s
h
e
r
Duo 400
Duo 750
Advertisement
Table of Contents
Related Manuals for Classeq Eco 1
Summary of Contents for Classeq Eco 1
- Page 1 Installation and Operations Manual The Classeq Under Counter Range Eco 1 Hydro 400 Eco 2 Hydro 700 Eco 3 Hydro 750 Duo 2 Duo 400 Duo 3 Duo 750 Service 0844 2245 245 service@classeq.co.uk 0844 2245 252 spares@classeq.co.uk Spares 0844 2245 249 sales@classeq.co.uk...
-
Page 2: Table Of Contents
Installation and Operations Manual Section Title Page(s) Safety instructions Your Classeq appliance 4 – 7 Installation Commissioning 8 – 9 10 - 12 Operation 13 - 14 Cleaning 14 - 16 Trouble shooting Decommissioning Useful Contact Details www.classeq.co.uk Service 0844 2245 245 service@classeq.co.uk... -
Page 3: 1.0 Safety Instructions
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH, OR OPERATE THE APPLIANCE Installation : Installation should only be carried out by a ‘Classeq’ approved technician, and in accordance with current regulations and within our instructions. Modification : ‘Classeq’... -
Page 4: Your Classeq Appliance
Once installed ensure the appliance is stable, with its weight being distributed equally and does not tilt more than 3° in any direction. Eco 2 Eco 3 Duo 2 Duo 3 Dimensions (mm) Eco 1 & Hydro 700 & & Hydro 400 Hydro 750 Duo 400 Duo 750 ‘A’... - Page 5 H = Earth bonding / Equi-potential stud J = Water supply connector (G 3/4”) K = Drain / waste water hose To aid both installation and connection of the appliance, ‘Classeq’ recommends the following hand tools are used. Recommended hand tools 4.0mm - Allen key...
- Page 6 Installation and Operations Manual 3.3.1 Electrical rating : Within the ‘Classeq’ range several of the 500mm² basket appliances can be either down rated or up rated electrically, such a procedure MUST be carried out by a ‘Classeq’ approved technician. The down / up rating of the machine is carried out by configuring the...
- Page 7 Ø40mm (1 ½”) standpipe required, must be no lower than 600mm The baseline of the appliance. maximum If you have any doubts about the drainage system on the machine, please either contact Classeq or your dealer / agent Page 7 Document Number: 902.001111/29/2012...
-
Page 8: Commissioning
Installation and Operations Manual 4.1 Rinse aid & detergent : Chemical pump(s) are located behind the front lower panel, prior to removing any panels all electrical supplies MUST be isolated. An Allen key is required for this operation. A coil of PVC hose is attached to each chemical pump, un-coil PVC hose and feed through either the slots just behind the chemical pumps, or out through the rear of the base. - Page 9 Increase dosage, rotate screw clockwise Decrease dosage, rotate screw anticlockwise Rinse & wash tank temperatures : The water temperatures on ’Classeq’ range of machines are adjustable, but have been preset, and should never be adjusted above these temperatures. Temperatures Machine type...
-
Page 10: Operation
Appliances fitted with a drain pump, the Cycle switch and lamp double as the drain down switch and lamp If in doubt please contact ’Classeq’ for advise. Switch the machine on : Ensure that both the water and electrical supply are connected and switched on, then depress the ‘ON/OFF’... - Page 11 It is very important the machine is drained down at the end of each working day and the door is left open to allow drying. The machine should never be left full of water if you are switching the machine off. Please contact Classeq Technical for advice and assistance : Technical support tech.support@classeq.co.uk Page 11 Document Number: 902.001111/29/2012...
- Page 12 Note ! Once empty ‘Classeq’ recommends that the mains water and electricity supplies are isolated at the wall and the machine be cleaned as instructed in section 6 of this manual For hygiene reasons it is recommended that once the appliance has been drained that the...
-
Page 13: Cleaning
Installation and Operations Manual Prior to cleaning : Switch off and isolated electrical supply before cleaning the appliance WARNING DO NOT use cleaning agents that contain CHLORINE, BLEACH or HYPOCHLORITE. DO NOT use STEEL WOOL, WIRE BRUSHES or any other abrasive materials. DO NOT jet wash or hose pipe the appliance down either internally or on the exterior... -
Page 14: Trouble Shooting
If you wish to purchase stainless steel cleaning agent, please contact : Spares 0844 2245 252 spares@classeq.co.uk Before placing a service call, please check the following: Check the appliance is connected to the mains water and electricity supply and both are turned on. - Page 15 Installation and Operations Manual Appliance fills slowly : Check water supply tap is fully open. Check water supply pressure, should be above 2 bar, if not ask your dealer to install a booster pump to increase water pressure. Check and clean rinse jets (located on the wash arms within the appliance). Check water supply hose is not trapped or kinked.
- Page 16 Will not switch OFF : Isolate at mains electricity before calling for a service technician immediately. If you still require service, please contact : Service 0844 2245 245 service@classeq.co.uk or for Technical support tech.support@classeq.co.uk Page 16 Document Number: 902.001111/29/2012...
-
Page 17: Decommissioning
Installation and Operations Manual If for any reason you require removing or, de-commissioning your appliance, then do so in accordance with local and national regulations. As a minimum ‘Classeq’ recommends the following procedure is followed. Remove chemical tubes from the chemical bottles, ensuring bottles are then capped to prevent any further spillage;... - Page 18 Air pressure switch 530.0004 (Gravity) 3 pole relay CONT/30 4 pole contactor CONTACTOR/4 If you wish to order any of the parts for your Classeq machine please contact our Spares Parts Department. 0844 2245 252 0870 224 7153 spares@classeq.co.uk Spares A comprehensive parts manual is available on the Classeq website: www.classeq.co.uk...
- Page 19 Installation and Operations Manual Page 19 Document Number: 902.001111/29/2012...
- Page 20 Installation and Operations Manual Page 20 Document Number: 902.001111/29/2012...
