Conotec FOX-2001D Instruction Manual

Version 2.0.0(2024.03.22) WWW.CONOTEC.CO.KR
CONOTEC CO., LTD.
DIGITAL TEMPERATURE CONTROLLER
Instruction Manual
FOX-2001D, 2001T, 2001F
FOX-2001D FOX-2001T FOX-2001F
• A user manual for this product is posted on the company website.
• Please download the technical document and communications
manual on the company website
01 Safety precautions
Please read the safety precautions carefully for correct
operation of the product.
※ The specifications and dimensions specified in this instruction
manual may be changed without any notice for performance
enhancement.
Warning
!
1. This product was not made as a safe device. Therefore, this
product should be attached with dual safety devices if it is used
for the control purposes (e.g. a device vulnerable to accident and
property damage, etc.).
2. Do not wire, inspect or service this product while the power is
being supplied.
3. You must attach this product to a panel. Otherwise, it may cause
an electric shock.
4. When connecting the power, you must check the terminal number.
5. Do not ever disassemble, process, modify or repair this product.
Caution
!
1. Please make yourself familiar with all the operation instructions,
safety precautions and warnings before using this product.
Comply with related specifications and capacity requirements
2. Do not wire or install this product to any unit with high inductive
load (e.g. motor, solenoid, etc.).
3. Use a shielded cable with a proper length when extending a sensor.
4. Do not use any part that generates an arc when used in the same
power or directly switched in close proximity.
5. Keep the power cable away from a high-voltage cable and do not
install this product in any place that is full of water, oil and dust.
6. Do not install this product in any place that is exposed to direct
sunlight or rain.
7. Do not install this product in any place that is subject to strong
magnetic power, noise, vibration or shock.
8. Keep this product away from any place that generates strong
alkaline or acid substances. Use a separate pipe.
9. Do not sprinkle water onto this product for cleaning when
installing it in the kitchen.
10. Do not install this product in any place where the temperature/
humidity ratings are exceeded
11. The sensor cable should not be cut or cracked..
12. Keep the sensor cable away from a signal cable, a power cable
or a load cable. Use a separate pipe.
13. Keep in mind that the follow-up service will not be available if
this product has been arbitrarily disassembled and modified
14. symbol on the terminal wiring diagram indicates a safety
statement that alerts a warning or caution.
15. Do not use this product near any device generating strong
high-frequency noise (e.g. high-frequency welding machine
high-frequency sewing machine, high-frequency radio,
large-capacity SCR controller, etc.).
16. Using this product in any method other than those specified by
by the manufacturer may lead an injury or a property damage
17. The product is not a toy. Keep it away from children.
18. The product should be installed only by an expert or
a qualified person.
19. The company will not be liable for any damage caused by the
violation of the above warnings and cautions or by a consumer's fault
Danger
!
Caution: Risk of electric shock
• Electric shock - Do not touch the AC terminal while the current is flowing.
It may cause an electric shock.
• Please intercept input power surely when input power check
02 Model Types
Model Sensor Output Temp.Range
Relay
FOX-2001D NTC
(2EA)
Relay
FOX-2001T NTC -55.0℃ ~ +99.9℃
(3EA)
Relay
FOX-2001F NTC
(4EA)
03 Components
5
℃
1 K1
2 K2
6
3 Set
K3
4
K4
7
2001F
OUT1 output lamp OUT2 output lamp OUT3 output lamp
1 2 3
Setting up A key for function's change
4 OUT4 output lamp 5 6
7 Setting down
· The function of each key.
1. : A key to change of the program & setting temperature.
Set
2. : A key to change of the temperature or the program's set values
04 Terminal wiring diagram
[FOX-2001D,2001T]
OUT1 OUT2 OUT3
sensor AC220V
OUT3
1 2 3 4 5 6 7 8 9 11 12
[FOX-2001F]
OUT1OUT2 OUT3 COM OUT1OUT2 OUT3 COM
OUT4 OUT3 OUT2 OUT1
1 2
Relay junction
machine(load)
A
power
~
C
Function
relay contact
B
7
※ Output: 250VAC 2A;
Temp. control
A power relay or a magnet must
be used. Be careful that any load over
the contact capacity may cause
contact fusion, contact defect,
relay damage or others.
05 Diemension and panel hole sizes
77.0mm
71.0mm
36.0mm
SET
66.5mm
61.0mm
4.0mm
05 Setting process
Setting temperature
OUT2 OUT1
25.0
The current temperature will be displayed.
!
AC LINE
220VAC
50/60Hz
Set
5T1
By pressing the
sensor
OUT4 AC220V
3 4 5 6 7 8 9 10 11 12
Set
(NTC) 10.0
!
AC LINE
Set
220VAC
50/60Hz
5T2
By pressing the
Set
10.0
Set
5T3
By pressing the
Set
(Unit : mm / error : ±0.5)
10.0
71.0mm
Set
PANEL HOLE
29.0mm
5T4
By pressing the
Set
10.0
Set
O-K
O-K, a setting confirmation text, will be
displayed, and the current temperature
will be shown.
25.0
setting temp.
1 change
5T1
Set key, the is displayed.
HSP
Press key to change the set value.
~
LSP
setting temp.
2 change
key, the 5T2 is displayed.
Set
HSP
~ Press key to change the set value.
LSP
setting temp.
3 change
5T3
Set key, the is displayed.
HSP
~ Press key to change the set value.
LSP
setting temp.
4 change
5T4
Set key, the is displayed.
HSP
~ Press key to change the set value.
LSP
By pressing the Set key
after changing of the set value.
