Summary of Contents for Fortinet FortiFone FON-580B
- Page 1 FortiFone FON-580B QuickStart Guide FON-580B_Telephone-QSG.indd 1 FON-580B_Telephone-QSG.indd 1 1/10/2024 5:21:51 PM 1/10/2024 5:21:51 PM...
- Page 2 Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that...
-
Page 3: Table Of Contents
Box Includes Installation Attaching the stand Connecting the phone Setting up the phone Using the Phone Troubleshooting Cautions and Warnings Regulatory Compliance Fortinet Product License Agreement / EULA and Warranty Terms FON-580B_Telephone-QSG.indd 3 FON-580B_Telephone-QSG.indd 3 1/10/2024 5:21:51 PM 1/10/2024 5:21:51 PM... -
Page 4: Register For Support
Register for Support Register your Fortinet product to receive: • Technical Support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces La reistrazione ti permette di usufruire di: •... -
Page 5: Box Includes
Box Includes This guide describes how to set up your phone and provides a brief overview of its features. Start by configuring an extension in the phone system. Refer to the FortiVoice Administration Guide for information about configuring an extension. For further details about your phone, please see the FON-x80/x80B Series User Guide. -
Page 6: Installation
Installation Attaching the stand 1. Line the posts on the top of the base with the holes on the back of the phone, depending on the level of tilt you prefer. 2. Push the stand into place until secure. FON-580B_Telephone-QSG.indd 6 FON-580B_Telephone-QSG.indd 6 1/10/2024 5:21:51 PM 1/10/2024 5:21:51 PM... -
Page 7: Connecting The Phone
Connecting the phone 1. Connect the handset cord to the handset jack on the phone. 2. Optionally, connect an amplified headset to the jack. 3. Connect the WAN port to the network with the provided Ethernet cable. 4. Optionally, connect your desktop PC to the PC port with an Ethernet cable (not supplied). -
Page 8: Setting Up The Phone
Setting up the phone For use as an internal extension The phone supports plug and play installation and will automatically download its configuration from the FortiVoice system. The phone will display the extension number and name when it has registered. For use as an external extension The phone can be used outside of the FortiVoice location as an external extension. -
Page 9: Using The Phone
Using the Phone Softkey Function History Accesses the call history stored on the phone. Contact Accesses the contacts stored on the phone. Toggles Do Not Disturb on and off. Accesses the phone menu. Menu FON-580B_Telephone-QSG.indd 9 FON-580B_Telephone-QSG.indd 9 1/10/2024 5:21:51 PM 1/10/2024 5:21:51 PM... - Page 10 Button Function Navigation keys — used to navigate items within the History/ Contact/Menu. Hold — places and retrieves calls on hold. Transfer — transfers calls to another extension or outside line. Volume control — adjusts the volume of the handset/headset/speaker. Mute —...
-
Page 11: Troubleshooting
Troubleshooting Symptom Corrective Action Display is blank Confirm the phone’s power source. 1. If you are using Power over Ethernet (PoE): • Ensure your Ethernet cable is plugged into the WAN port on the back of your phone. • Ensure the PoE switch is properly configured. If it still doesn’t work, replace the Ethernet cable. -
Page 12: Cautions And Warnings
Cautions and Warnings Environmental specifications Ambient operating temperature: 0°C to 45°C Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (température de fonctionnement, température de stockage, humidité... -
Page 13: Regulatory Compliance
Regulatory Compliance Federal Communication Commission (FCC) — USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. - Page 14 EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products.
-
Page 15: Fortinet Product License Agreement / Eula And Warranty Terms
This product is in compliance with Statutory Instrument 1206 Radio Equipment Regulations 2017. The full Declaration of Conformity for this product is available at the link below: https://site.fortinet.com/ProductRegulatory/UK Fortinet Product License Agreement / EULA and Warranty Terms For Product License Agreement / EULA and Warranty Terms, visit https://www.fortinet.com/ content/dam/fortinet/assets/legal/EULA.pdf FON-580B_Telephone-QSG.indd 15... - Page 16 Create a support account, register and manage your products, download updates, firmware images and release notes, and create technical support tickets. https://support.fortinet.com Fortinet Document Library Up-to-date versions of Fortinet publications for the entire family of Fortinet products. https://docs.fortinet.com Training Services Course descriptions, availability, schedules, and location of training programs in your area.
