- Page 1 Ranger 41 Push CODE 415C OWNER'S HANDBOOK (English Version) 415C001001 FROM SERIAL NO: HANDBOOK: 415022 (Rev.0.) Issue : 21.02.05...
- Page 2 10 Height of Cut Adjuster 11 Serial No. Label 12 Exhaust Guard 13 Rear Deflector 14 Spark Plug Lead 1C415A05 Specifications Code 415C Engine Briggs & Stratton Quantum XTS 50 Engine type 12F802-1325-01 Engine/Cutterbar speed 3000 rpm Fuel type Unleaded petrol Fuel capacity 1.5 litres...
- Page 3 1ST Year (12 months) 1ST Year (12 months) Owner’s Name: We certify that this service has been carried out by an Authorised Hayter Serial Number: Service Dealer Date: Date: Note for dealer: Please retain this voucher for your records. 2nd Year (24 months) 2nd Year (24 months) Owner’s Name:...
-
Page 4: Table Of Contents
CONTENTS 1.2 Main Features/Specifications 1.20 Maintenance Schedule 1.5 Contents 1.21 - 1.27 Mower Maintenance 1.6 Introduction 1.21 - Engine 1.21 - Throttle Cable Adjustment 1.7 Warranty 1.21 - Carburettor Adjustments 1.22 - Oil Service 1.8 - 1.11 Safety Precautions 1.22 - Air Cleaner Service 1.23 - Spark Plug Service... -
Page 5: Introduction
INTRODUCTION Thank you for purchasing a Hayter mower. The following pages are designed to help you gain safe and efficient service from your mower. IMPORTANT: This ‘Owners Handbook’ should be regarded as part of the mower as it gives essential information regarding mower safety, operation, maintenance and specifications. Read and understand this handbook prior to operating your mower for the first time. -
Page 6: Warranty
This warranty does not apply to any unit that has been tampered with, altered, misused, abused or used for hire, and will become invalid if non genuine Hayter parts are fitted. This warranty does not cover minor mechanical adjustments unless they are due to defective material or workmanship. -
Page 7: 1.11 Safety Precautions
SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury. - Page 8 A damaged cutterblade must be replaced immedi- ately with a genuine Hayter replacement part Operation Do not operate the engine in a confined space where exhaust fumes (carbon monoxide) can collect.
- Page 9 SAFETY PRECAUTIONS Operation Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running. Never touch the exhaust/exhaust guard or cooling fins when the engine is hot.
-
Page 10: Safety Symbols
Wear strong work gloves when removing and reassembling the cut- terblade. Always replace worn or faulty parts with genuine Hayter parts. Safety Symbols Safety Alert - Be aware to the Danger of severing toes or fin- Danger of being hit by thrown possibility of injury. -
Page 11: Assembling The Mower
Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Engine Handbook. To prevent accidents cut off the long ribbon attached to the grass- bag and discard. -
Page 12: Prevent Engine Damage
STARTING MOWER BEFORE Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Oil Type Always use high quality detergent oil classified SAE 30 oil. Never use additives with recommended oil. -
Page 13: 1.17 Operating The Mower
OPERATING THE MOWER Controls Check that the engine stop lever returns freely to its rest position when released. Whilst operating the engine throttle mechanism slight resistance should be felt when moving the lever to the ‘choke’ position. Starting - Step 1 Move the throttle control lever to the ‘choke’... -
Page 14: Turning
OPERATING MOWER Turning To turn steer the mower with the handlebar in the direction required. To make a tight turn, apply downward pressure on the handlebar to raise the front wheels just above ground level and steer in the required direction. -
Page 15: Before Mowing
OPERATING THE MOWER Before Mowing To prevent accidents thoroughly inspect the area and remove all objects which when contacted by the mower cutterblade could become dangerous projectiles. Inspect the area for hidden obstruc- tions which when contacted by the cutterblade could risk health and safety. -
Page 16: Friction Disc
OPERATING MOWER Friction Disc The cutterblade is driven by the engine via a friction disc to help pre- vent damage occurring to the engine crankshaft and cutting mecha- nism when a hidden obstruction or overload is encountered. Always stop the engine when a hidden obstruction or excessive vibra- tion is encountered. - Page 17 LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. Spike the lawn to aerate and stimulate soil organisms and root growth and apply lawn sand if necessary.
- Page 18 LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow.
-
Page 19: Maintenance Schedule
MAINTENANCE SCHEDULE To prevent accidents stop the engine disconnect the spark plug lead before attempting to carry out maintenance procedures on the mower. After the very first five hours change the engine oil. Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass. -
Page 20: 1.27 Mower Maintenance
MOWER MAINTENANCE To prevent accidents stop the engine and disconnect the spark plug lead before attempting to carry out maintenance proce- dures on the mower. Engine Air Filter Fuel Cap Start Grip Oil Cap/ Dipstick Exhaust Guard Spark Plug / Lead Throttle Cable Adjustment Loosen casing clamp screw (1) and move the governor lever (2) in the direction of screw (1) as far as posible. -
Page 21: Oil Service
MAINTENANCE MOWER Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- 1. -
Page 22: Spark Plug Service
MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first. A spark plug wrench is available from any authorised Briggs &... -
Page 23: Deck Housing
MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treat- ed grass and store well away from corrosive materials. Securing Nuts &... -
Page 24: Cutterblade Removal
DO NOT rotate tools towards the cut- ting edges to avoid the risk of injury should the tool slip. ALWAYS use genuine Hayter replacement parts. The condition of the cutterblade and its mounting arrangement should be checked regularly for signs of wear or damage. Ensure that the cut- terblade is not bent or cracked. -
Page 25: Cutterblade Assembly
MOWER MAINTENANCE Cutterblade Assembly Assemble the cutterblade with the turned up edges facing towards the engine. Secure the cutterblade using the bolt (1), spring washer (2), and distance piece (3) and tighten to a torque of 54Nm Cutterblade Sharpening 30°-45° A slightly worn cutterblade may be re-sharpened. -
Page 26: Storage
MOWER MAINTENANCE Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to be pivoted forwards to rest against the mower. Take care to ensure that the control cables do not become snagged at the pivot point and depress the engine stop lever to prevent it being dam- aged through contact with the engine spark plug. -
Page 27: 1.29 Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine will not turn over Engine stop lever released. Operate engine stop lever. Incorrect oil level. Check oil level. Obstruction under deck. Remove obstruction. Engine smokes Excess oil level. Check oil level. Air cleaner cartridge oil Service air cleaner. - Page 28 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine vibrates excessively Mounting bolts loose. Tighten bolts Cutterblade bolt loose. Tighten bolt Cutterblade out of balance. Balance cutterblade Bent crankshaft. Consult your dealer Uneven cut Undulating ground conditions Change direction of travel Cutterblade worn Sharpen the cutterblade Cutterblade out of balance Balance the cutterblade...
-
Page 29: Declaration Of Conformity
Declaration done and Technical Documentation kept at: HAYTER LIMITED, S.A. Maryniak Spellbrook, Bishop’s Stortford, (Technical Director) Herts CM23 4BU ENGLAND VIBRATION INFORMATION The Lawnmower Vibration level at the operator contact position, measured in accordance with Euopean Standard Code 415C = 7.0ms EN836-Handlebars. 1.30... - Page 30 PARTS LIST ITEM NO. DESCRIPTION PART NO. QTY. ITEM NOTE Mainframe 410010V Guard Foot 415016W Screw - Taptite M6x16 09365 Rod - Deflector 305103 Key - Woodruff 1662 Decal - Grass Blade 410064 Engine - B&S Quantum XTS50 410007 Decal - Engine 398013 Cover - Nut M8 234051...
- Page 31 480128 Housing - Bearing Support 410048 Bracket - Roller Support LH 410002 Grip Fix - 5/16” L.D. 04020 Plate - Securing 219037 Box Battery 410080 Decal - Hayter 410087 Bracket - Roller Support RH 415010 Plate Axle Tie 415015 1.32...
- Page 32 PARTS LIST 30 34 1C415A06B 1.33...
- Page 33 NOTES Notes:- 1.34...
- Page 34 NOTES Notes:- 1.35...
-
Page 35: Customer Info
INFORMATION CUSTOMER Serial No: Engine Type:-12F802-1325-01 Engine:-Briggs & Stratton Quantum XTS 50 Date of Sale:- Your Local Dealer:- 1.36...
