Gardener's Stack-n-Grow Light System Assembly Instructions page 2

SECTION : Adding a Stack-n-Grow Light Add-On Unit
Stack the space-saving Stack-n-Grow Light System up to three units high! Each add-on unit comes with two Wall Brackets (Figure 4)
to anchor it to the wall. Important: For stability, anchor all systems stacked more than two levels high. Important: Prevent water from
dripping from upper shelves onto light fixtures. See Tips for Using the Stack-n-Grow Light System, below.
Parts Included
1 Shelf 4 Light Brackets (2 Left, 2 Right)
4 Legs 4 Light Fixture Clips
2 Light Fixtures 2 Wall Brackets
1 Light Cord 2 Nano Reflectors
Step 1. Remove the Corner Caps from the corners of the top Shelf of an assembled
base unit. Insert the widest part of the tapered legs into the corner holes of
assembled Shelf, pushing the legs down so they connect with the assembled base.
Step 2. Follow Steps 3 through  (other side).
Step 3. For systems with more than one Add-On Unit, secure the system to a wall. Place the two Wall Brackets (Figure 4) around
the two Legs closest to the wall, either at the top or bottom of the Legs. Attach the Wall Brackets to the wall using screws (not
included) that are suitable for your wall configuration.
Tips for Using the Stack-n-Grow Light System
• Caution: Prevent water from dripping from upper shelves onto the light fixtures below by using our Small Boot Trays (32-),
drip trays or saucers on each shelf. Exposure to water may damage the light fixture and cause electrical shock.
• Adjust the height of the lights to within a few inches of the plant tops for strongest growth.
• Add a light timer to automatically turn lights on and off. Most plants grow best with 12 to 14 hours of light daily.
• Lift the assembled system by supporting the bottom shelf.
• Each shelf is rated to hold up to 11 pounds.
Stack-n-Grow Light Base Unit #513
Figure 4
Wall Bracket
Stack-n-Grow Base Unit & one Add-On Unit
Requires :
(1) Stack-n-Grow Light Base Unit #513
(1) Stack-n-Grow Add-On Unit #5134
For more gardening accessories, information and articles, please
visit us at gardeners.com.
Stack-n-Grow Light
Add-On Unit
Stack-n-Grow Base Unit & two Add-On Units
Requires :
(1) Stack-n-Grow Light Base Unit #513
(2) S (2) Stack-n-Grow Add-On Units #5134
