- Page 1 Off Line UPS PowerWalker VFD 400 PowerWalker VFD 600 PowerWalker VFD 800 Quick Start Guide...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS – This manual contains important instructions for models PowerWalker VFD 400/600/800 that should be followed during installation and maintenance of the UPS and batteries. This product is specially designed for PCs and it is not recommended for use in any life- supporting system and other specific important equipment.
- Page 3 Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions. Keep unauthorized personnel away from batteries. When replacing batteries, replace with the same type and number of the sealed lead-acid batteries. ...
-
Page 4: Product Introduction
1. Product Introduction The PowerWalker VFD series provides comprehensive protection in a small and economic package. The UPS is more compact and offers greater comprehensive power protection against surges and spikes. This UPS will continue providing stable power to connected equipment and enable to shutdown PC safely during power failure. -
Page 5: Product Overview
3. Product Overview Front Panel: Power Switch UPS status indicator Fault/Battery status indicator (Check the Indicator & Alarm Table for the details.) Back Panel: IEC Type Schuko Type French Type AC input Output receptacles Circuit breaker... -
Page 6: Installation And Initial Startup
4. Installation and Initial Startup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. I: Placement & Storage Conditions Install the UPS in a protected area that is free of excessive dust and has adequate air flow. Please place the UPS away from other units at least 20 cm to avoid interference. -
Page 7: Troubleshooting
5. Indicators & Alarm Table for Operation Conditions Visual Indicator Alarm AC Mode Green LED lighting Battery Mode Green LED flashing every 10 Sounding every 10 seconds seconds Low battery at battery Green LED flashing every second Sounding every mode and Red LED lighting second Fault... -
Page 8: Specifications
7. Specifications Model Power Walker VFD Power Walker VFD Power Walker VFD CAPACITY 400 VA / 240 W 600 VA / 360 W 800 VA / 480 W INPUT Voltage 230 VAC Voltage Range 180~270 VAC Frequency 50 Hz OUTPUT Voltage Regulation +/-10% Transfer Time...
