PCI-2602U
Series Card User Manual
Multi-Function Boards
S
UPPORTS
Board includes PCI-2602U
W
ARRANTY
All products manufactured by ICP DAS are warranted against defective materials
for a period of one year from the date of delivery to the original purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent to the use of this product.
ICP DAS reserves the right to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate and reliable. However,
no responsibility is assumed by ICP DAS for its use, nor for any infringements of
patents or other rights of third parties resulting from its use.
C
OPYRIGHT
Copyright © 2014 by ICP DAS. All rights are reserved.
T
RADEMARK
Names are used for identification only and may be registered trademarks of their
respective companies.
C
ONTACT
If you have any question, please feel to contact us. We will give you quick
response within 2 workdays.
Email: service@icpdas.com, service.icpdas@gmail.com
U
S
Version 1.0, Feb. 2014
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-2602U Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ICP DAS USA PCI-2602U Series

  • Page 1 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru PCI-2602U Series Card User Manual Multi-Function Boards Version 1.0, Feb. 2014 UPPORTS Board includes PCI-2602U ARRANTY All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser.
  • Page 2: Table Of Contents

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card ABLE OF ONTENTS Packing List ..........................4 Related Information ........................4 Introduction ........................5 1.1. General Description ....................... 5 1.2. Features ..........................6 1.3.
  • Page 3 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Verifying the Installation ..................... 31 5.3.1 How do I get into Windows Device Manager? ................31 5.3.2 Check that the Installation ......................33 Testing PCI-2602U Card....................
  • Page 4: Packing List

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Packing List The shipping package includes the following items: One multi-function card as follows: Note: PCI-2602U Series If any of these items is missing or damaged, contact the dealer from whom you purchased the product.
  • Page 5: Introduction

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 1. Introduction The PCI-2602U card provides 1MHz 16/16-ch 16-bit Analog Input, 2-ch 16-bit Analog Output with 32-ch programmable Digital Input/Output 1.1. General Description The PCI-2602U is a powerful multifunction card with 1M/s sampling rate and 16-bit resolution converter to suitable for most industrial application.
  • Page 6: Features

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 1.2. Features The following is a list of general features for the PCI-2602U. Check section 1.3 for more details.  Interface ...
  • Page 7: Specifications

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 1.3. Specifications Model Name PCI-2602U Analog Input Channels 16 single-ended/8 differential A/D Converter 16-bit, 1 µs conversion time Sampling Rate 1 MS/s...
  • Page 8: Applications

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Digital Output Compatibility 5 V/CMOS Output Voltage Logic 0: 0.4 V (max.)/Logic 1: 2.4 V (min.) Output Capability Sink: 6 mA @ 0.33 V/Source: 6 mA @ 4.77 V...
  • Page 9: Hardware Configuration

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2. Hardware Configuration 2.1. Board Layout : Dip Switch for Board ID : AGND for AD Calibration, Black : 10 V for AD Calibration, Red...
  • Page 10: Jumper/Programmable Setting

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.2. Jumper/Programmable Setting 2.2.1. JP1 EEPROM Write Protection JP is used to sele t the EEPROM Write Prote tio . To sele t the LOCK, the EEPROM does ’t write the data, otherwise EEPROM can write the data.
  • Page 11: Analog Input Type Setting

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.2.3. Analog Input Type Setting This option is used to select the Analog Input type. For single-ended inputs, select the Single Ended. For differential inputs, select Differential. How to use the advanced configuration tool in the Windows Device Manager to settings the Analog Input type, the detail configuration is illustrated in the figure below.
  • Page 12: Digital Input/Output Mode Setting

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.2.4. Digital Input/Output Mode Setting This option is used to select the Digital Input/Output mode for digital output port. For Input mode, select the Digital Input. For output mode, select Digital output. How to use the advanced configuration tool in the Windows Device Manager to settings the Digital I/O Ports, the detail configuration is illustrated in the figure below.
  • Page 13: System Block Diagram

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.3. System Block Diagram The block diagram of PCI-2602 is given as follows: PCI Bus EEPROM(Calibration Interface Sync_O Sync_I Trigger Local System Controller...
  • Page 14: Analog Input Signal Connections

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.4. Analog Input Signal Connections The PCI-2602U can measure single-ended or differential-type analog inputs signal. Some analog signals can be measured in both modes. However, some analog signals only can be measured in one or the other.
  • Page 15 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Figure 2.4-1 Connecting to grounding source input (Right way) AI0 + PCI-2602U Es 1 AI0 - AI_GND AIn + Es n AIn - AI_GND Figure 2.4-2 Ground loop input (Wrong way)
  • Page 16 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Figure 2.4-3 Connecting to single-ended input configuration AI_GND Figure 2.4-4 Connecting to thermocouple configuration AI0 + AI0 - Ain + Ain -...
  • Page 17 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Figure 2.4-5 Connecting to floating source configuration A/D CH 0 HI PCI-2602U Es 1 A/D CH 0 LO 100 kΩ ~ 10 MΩ...
  • Page 18: Analog Output Signal Connections

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.5. Analog Output Signal Connections PCI-2602U provides two DA output channels, AO0 and AO1. You may use the PCI-2602U internally-provided precision -5 V (-10 V) reference to generate 0 V to +5 V (+10 V) DA output range.
  • Page 19: Pin Assignments

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 2.6. Pin Assignments Note: AI0 ~ AI15 : single-ended (AI0+,AI0-) ~ (AI7+,AI7-) : differential User Manual/Ver. 1.0/Apr. 2014/PMH-0028...
  • Page 20 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card I/O Connector Signal Description AI0 ~ AI15 Analog Input Channels 0 through 15. Each channel AI0+ ~ AI7+ AI_GND Input pair, AIx+, AIx-(x = 0 to 7), can be configured as either AI0- ~ AI7- two single-ended inputs or one differential input.
  • Page 21: Operation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 3. Operation 3.1. AD Operation The block diagram of AD system is given as follows: CON1 Polling Buffer Single- Interrupt Ended FIFO...
  • Page 22 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card There are 5 trigger modes are given as follows: Description Trigger Mode There is no trigger signal. The AD operations are started Software Trigger by software program.
  • Page 23 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card The clock signal is generated to get one AD data. This data is saved to the buffer or FIFO. There are 2 clock sources, software clock and pacer clock, are provided.
  • Page 24: Dio Operation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 3.2. DIO Operation There are 4 groups, PA, PB, PC and PD, provided in this board. There are 8 channels provided in every group. All groups are configured to DI he the PC is first o . The user’s progra can re-configure all 4 groups to DI or DO independently.
  • Page 25: Con1 I/O Operation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 3.3. CON1 I/O Operation The CK0 at CON1 can be used as a event counter or a pulse output. The designed as a Board Synchronization Interface.
  • Page 26: Hardware Installation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 4. Hardware Installation Note: As certain operating systems, such as Windows 2000/XP may require the computer to be restarted after a new driver is installed, it is recommended that the driver is installed first, which will reduce the installation time.
  • Page 27 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Step 3: Correctly shut down and power off your computer, and then disconnect power supply. Step 4: Remove the cover from the computer.
  • Page 28 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Step 6: Remove the screw holding the cover for the PCI slot in place and then remove the slot cover from the PC. Ensure that you do not misplace the screw.
  • Page 29 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Step 9: Screw the mounting bracket screw removed in step 5 into the new PCI card bracket to secure the card in place.
  • Page 30: Software Installation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 5. Software Installation This chapter provides a detailed description of the process for installing the PCI-2602U driver and how to verify whether the PCI-2602U was properly installed. PCI-2602U card can be used on Windows 2000 and 32-/64-bit XP/2003/2008/Vista/7/8 based systems, and the drivers are fully Plug &Play (PnP) compliant for easy installation.
  • Page 31: Pnp Driver Installation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 5.2 PnP Driver Installation Power off the computer and install the PCI-2602U card. Turn on the computer and Windows 2000 and 32-/64-bit Windows XP/2003/2008/Vista/7/8 should automatically defect the new PCI device(s) and then ask for the location of the driver files for the hardware.
  • Page 32 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card  Microsoft Windows 2003/2008 “tart  point to Ad i istrative Tools , and then click Co puter Step 1: Click Ma age e t .
  • Page 33: Check That The Installation

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card  Microsoft Windows 8 Step 1: To display the Start screen icon from the desktop view, simply hover the mouse cursor over the bottom-left corner of screen.
  • Page 34: Testing Pci-2602U Card

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 6. Testing PCI-2602U Card This chapter can give you the detail steps about self-test. In this way, user can confirm that PIO-D96 series cards well or not. Before the self-test, you must complete the hardware and driver installation.
  • Page 35: Execute The Test Program

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Analog Input/Output Test Wiring: Step 2: Open the advanced configuration tool in the Windows Device Manager to configuration the Analog Input type for Single-Ended input, refer to section 2.2.3 Analog...
  • Page 36 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Step 2: Get Analog Input/Output function test result. Click Analog Output tab Click this button Select the Port 0 Select the Type the Voltage value...
  • Page 37: I/O Register Address

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7. I/O Register Address 7.1. Find the I/O Address on DOS The Plug&Play BIOS assigns a proper I/O address to every PCI-2602U card in the power-on stage.
  • Page 38 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Here’s the sa ple progra sour e ode for DOS: // Step1: Detect all PCI-2602U cards first wRetVal=P2602_DriverInit(&wTotalBoards); printf("Threr are %d PCI-2602U Cards in this PC\n",wBoards);...
  • Page 39: The I/O Address Map

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.2. The I/O Address Map The list of PCI-2602U registers is given below. The address of each register is found by simply adding the offset to the base address of the corresponding section.
  • Page 40 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register Function Script Bar No. Offset Read Write 2A0H Read AI FIFO Data 2A4H AI FIFO Status 2A8H AI Data Acquisition Size...
  • Page 41: Bar 1

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.3. Bar 1 7.3.1 PLX Control/Status registers  (Write/Read)wBase+0x68 Read/Write interrupt Control/Status The detail information, please refer the PLX9054 document. http://www.plxtech.com/products/io/pci9054#technicaldocumentation ...
  • Page 42: Bar 3

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.4. Bar 3 7.4.1 Interrupt and Initialize Control/Status Registers Register 7.4.1-1wBase+0x200 Initialize Control/Status Description Write Reset AI Mode. Write a 1 and Write a 0 to resets AI Mode.
  • Page 43 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.1-3 wBase+0x204 Interrupt Clear/Status Description Read Write AI Pacer Done Int. Reading a 1 indicates an analog input pacer is complete. Reading a 0 indicates a pacer is not complete. Write a 1 and write a 0 to clear AI Pacer Down interrupt.
  • Page 44 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.1-4 wBase+0x224 Interrupt Mode Control/Status Description Read Write Enable AI Pacer Done Interrupt. Write a 1 enables interrupt when analog input pacer is done.
  • Page 45: Digital I/O Registers

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.4.2 Digital I/O Registers Register 7.4.2-1 wBase+0x210 DIO Mode Control/Status Description Read Write PA DIO Mode. Write a 1 indicates a PA is DO mode. Write a 0 indicates a PA is DI mode.
  • Page 46 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.2-3 wBase+0x214 Read DIO Port Description Read PA Read. Read the digital input data to specified digital I/O Port-PA, When PA is digital input mode.
  • Page 47: Analog Input Registers

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.4.3 Analog Input Registers Register 7.4.3-1 wBase+0x22C AI Scan Mode Control/Status Description Read Write Enable AI Scan. Writing a 1 enables MagicScan Mode to scan analog input channel.
  • Page 48 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.3-4 wBase+0x294 AI Software Trigger Control Description Read Write Software Trigger Start. Writing a 0 causes the analog input channel to measure analog input data.
  • Page 49 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.3-8 wBase+0x2F0 Save AI Configuration Data Description Read Write Save AI Configuration Data. Writing a 0 indicates to save configuration data.
  • Page 50: Analog Output Registers

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 7.4.4 Analog output registers Register 7.4.4-1 wBase+0x2B0 AO Configuration Control/Status Description Read Write Channel 0 Enable. Writing a 1 enables channel to output data. Writing a 0 disables the channel.
  • Page 51 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Register 7.4.4-2 wBase+0x2B4 Write AO Channel 0 Data Description Read Write 0:15 AO Channel 0 Write. Writing the analog output data to channel 0.
  • Page 52: Calibration

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 8. Calibration 8.1. Calibration Introduction The PCI-2602 is already fully calibrated when shipped from the factory including the calibration coefficients which are stored in the EEPROM on board. For more precise...
  • Page 53: Calibration Step-By-Step

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 8.2. Calibration Step-by-Step Connect voltage meter to (TP2,TP1) get the 10V Ref value. Connect voltage meter to (TP3,TP1) and get the 5V Ref value.
  • Page 54: Pci-2602U Windows Api Function

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card 9. PCI-2602U Windows API Function Please refer to software user manual of the UniDAQ SDK, download link from the CD:\NAPDOS\PCI\UniDAQ\Manuql http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/unidaq/manual/ User Manual/Ver. 1.0/Apr. 2014/PMH-0028...
  • Page 55: Appendix: Daughter Board

    ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Multi-Function Boards PCI-2602U Series Card Appendix: Daughter Board A1. DB-68A The DB-68A is a general-purpose daughter board for D-sub 68 pins. It is designed for easy wire connection.
