Security Gateway Manual

Netgate-2100

Aug 15, 2024

Table of Contents

Need help?

Do you have a question about the Netgate-2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Netgate Netgate-2100

Page 2: Table Of Contents
2 Initial Configuration 3 pfSense Plus Software Overview 4 Input and Output Ports 5 Safety and Legal 6 Netgate 2100 Wall Mount 7 Connecting to the USB Console Port 8 Reinstalling pfSense Plus Software 9 Optional M.2 SATA Installation 10 Configuring the Switch Ports...
Page 3 Security Gateway Manual Netgate-2100 This Quick Start Guide covers the first time connection procedures for the Netgate® 2100 Firewall Appliance. It will provide the information needed to keep the appliance up and running. Tip: Before getting started, a good practice is to download the...
Page 4: Getting Started
CHAPTER GETTING STARTED The basic firewall configuration begins with connecting the Netgate® appliance to the Internet. The Netgate appliance should be unplugged at this time. Connect one end of an Ethernet cable to the WAN port (shown in the section) of the Netgate Input and Output Ports appliance.
Page 5 Connecting to the USB Console Port. Warning: The default IP Address on the LAN subnet on the Netgate firewall is 192.168.1.1/24. The same subnet cannot be used on both WAN and LAN, so if the default IP address on the ISP-supplied modem is also 192.168.1.1/24, disconnect the WAN interface until the LAN interface on the firewall has been renumbered to...
Page 6: Initial Configuration
Allow 4 or 5 minutes to boot up completely. Warning: If the ISP Customer Premise Equipment (CPE) on WAN (e.g. Fiber or Cable Router) has a default IP Address of 192.168.1.1, disconnect the Ethernet cable from the WAN port on the Netgate 2100 Security Gateway before proceeding.
Page 8 1. Click Next to start the Setup Wizard. Fig. 3: Setup Wizard starting page 2. Click Next after reading the information on Netgate Global Support. 3. Use the following items as a guide to configure the options on the General Information page: Hostname Any desired hostname name can be entered to identify the firewall.
Page 9 Security Gateway Manual Netgate-2100 DNS Servers For purposes of this setup guide, use the Google public DNS servers (8.8.8.8 and 8.8.4.4). Note: The firewall defaults to acting as a resolver and clients will not utilize these forwarding DNS servers. However, these servers give the firewall itself a way to ensure it has working DNS if resolving the default way does not work properly.
Page 10 Plus dashboard, click Finish. Note: This step of the wizard also contains several useful links to Netgate resources and methods of obtaining assistance with the product. Be sure to read through the items on this page before finishing the wizard.
Page 13: Pfsense Plus Software Overview
® Fig. 1: The pfSense Plus Dashboard Section 1 Important system information such as the model, Serial Number, and Netgate Device ID for this Netgate firewall. Section 2 ® Identifies what version of pfSense Plus software is installed, and if an update is available.
Page 14 Click Download configuration as XML and save a copy of the firewall configuration to the computer connected to the Netgate firewall. This backup (or any backup) can be restored from the same screen by choosing the backed up file under Restore Configuration.
Page 16 See also: Port. Cable is required. Connecting to the USB Console Tip: To learn more about getting the most out of a Netgate appliance, sign up for a pfSense Plus Software Training course or browse the extensive Resource Library.
Page 17: Input And Output Ports
CHAPTER FOUR INPUT AND OUTPUT PORTS 4.1 Rear Side Fig. 1: Rear view of the Netgate 2100 Firewall Appliance The items in this image are described by entries in Ethernet, and Routed Ethernet, Switched Other Ports. 4.1.1 Routed Ethernet The WAN Combo-Port is shared between an RJ-45 port and an SFP port. Only one port can be used.
Page 18 Security Gateway Manual Netgate-2100 4.1.2 Switched Ethernet Interface Name Port Name LAN1 mvneta1 LAN2 mvneta1 LAN3 mvneta1 LAN4 mvneta1 The four LAN Ethernet ports are switched ports. By default all of these ports act as a single switch uplinked to the LAN interface on the firewall.
Page 19 For example, UPS/Battery Backups, Cellular modems, GPS units, and storage devices. Though the operating system also supports wired and wireless network devices, these are not ideal and should be avoided. 4.2 Front Side Fig. 2: Front view of the Netgate 2100 Firewall Appliance 4.2.1 LED Patterns Description...
Page 20: Safety And Legal
CHAPTER FIVE SAFETY AND LEGAL 5.1 Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. Warning: Do not use this product in location that can be submerged by water. Warning: Do not use this product during an electrical storm to avoid electrical shock.
Page 21 (UPS) or a combination of those devices. Failure to take such precautions could result in premature failure, and/or damage to your Netgate appliance, which is not covered under the product warranty. Such an event may also present the risk of electric shock, fire, or explosion.
Page 22 Security Gateway Manual Netgate-2100 more detailed information about the disposal of your old equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product. 5.7.2 Deutsch Die Europäische Richtlinie 2002/96/EC verlangt, dass technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeindeabfall entsorgt werden darf.
Page 23 Netgate-2100 5.8 Declaration of Conformity 5.8.1 Česky[Czech] NETGATE tímto prohla uje, e tento NETGATE device, je ve shod se základními po adavky a dal ími p íslu n mi ustanoveními sm rnice 1999/5/ES. 5.8.2 Dansk [Danish] Undertegnede NETGATE erklærer herved, at følgende udstyr NETGATE device, overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Page 24 Alulírott, NETGATE nyilatkozom, hogy a NETGATE device, megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. 5.8.10 Íslenska [Icelandic] Hér me l sir NETGATE yfir ví a NETGATE device, er í samræmi vi grunnkröfur og a rar kröfur, sem ger ar eru í tilskipun 1999/5/EC. 5.8.11 Italiano [Italian] Con la presente NETGATE dichiara che questo NETGATE device, è...
Page 25 Security Gateway Manual Netgate-2100 5.8.16 Slovensky [Slovak] NETGATE t mto vyhlasuje, e NETGATE device, sp a základné po iadavky a v etky príslu né ustanovenia Smernice 1999/5/ES. 5.8.17 Svenska [Swedish] Härmed intygar NETGATE att denna NETGATE device, står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Page 26 Security Gateway Manual Netgate-2100 4616 West Howard Lane, Suite 900 Austin, Texas 78728 legal@netgate.com The arbitration will be conducted by the American Arbitration Association (AAA) under its rules. The AAA’s rules are available at www.adr.org. Payment of all filing, administration and arbitrator fees will be governed by the AAA’s rules.
Page 27 Security Gateway Manual Netgate-2100 5.13 Limited Warranty DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY THE PRODUCTS/SERVICES AND ALL INFORMATION, CONTENT, MATERIALS, PRODUCTS (INCLUD- ING SOFTWARE) AND OTHER SERVICES INCLUDED ON OR OTHERWISE MADE AVAILABLE TO YOU THROUGH THE PRODUCTS/SERVICES ARE PROVIDED BY US ON AN “AS IS” AND “AS AVAILABLE” BA- SIS, UNLESS OTHERWISE SPECIFIED IN WRITING.
Page 28: Netgate 2100 Wall Mount
CHAPTER NETGATE 2100 WALL MOUNT The Netgate 2100 has built in wall-mount keyholes on the bottom of the appliance. This page provides an overview and a PDF template for attaching the system to the wall.
Page 29 Netgate-2100 The Netgate 2100 can be mounted vertically or horizontally. If mounted horizontally, the ports and cables should face up to reduce the pull from the weight of the cables on the ports. Click on the button below to download the Wall Mount Template.
Page 31: Connecting To The Usb Console Port
CHAPTER SEVEN CONNECTING TO THE USB CONSOLE PORT This guide shows how to access the serial console which can be used for troubleshooting and diagnostics tasks as well as some basic configuration. There are times when directly accessing the console is required. Perhaps GUI or SSH access has been locked out, or the password has been lost or forgotten.
Page 32 Security Gateway Manual Netgate-2100 7.2 Connect a USB Cable Next, locate an appropriate USB cable that has a USB Mini-B (5-pin) connector on one end and a regular USB Type A plug on the other end. These cables are commonly used with smaller USB peripherals such as GPS units, cameras, and so on.
Page 33 Security Gateway Manual Netgate-2100 macOS The device associated with the system console is likely to show up as, or start with, /dev/cu.usbserial-<id>. Run ls -l /dev/cu.* from a Terminal prompt to see a list of available USB serial devices and locate the appropriate one for the hardware.
Page 34 Security Gateway Manual Netgate-2100 7.5 Launch a Terminal Program Use a terminal program to connect to the system console port. Some choices of terminal programs: Windows For Windows the best practice is to run or SecureCRT. An example of how to configure PuTTY is PuTTY in Windows below.
Page 36 Security Gateway Manual Netgate-2100 Fig. 2: An example of using PuTTY in Linux GNU screen In many cases screen may be invoked simply by using the proper command line, where <console-port> is the console port that was located above. sudo screen <console-port>...
Page 37 Security Gateway Manual Netgate-2100 7.5.2 Terminal Settings The settings to use within the terminal program are: Speed 115200 baud, the speed of the BIOS Data bits Parity None Stop bits Flow Control Off or XON/OFF. Warning: Hardware flow control (RTS/CTS) must be disabled.
Page 38 Some devices expose multiple ports, so using the incorrect port may lead to no output or unexpected output. Hardware Failure There could be a hardware failure preventing the serial console from working. Contact Netgate TAC for assis- tance. © Copyright 2024 Rubicon Communications LLC...
Page 39 Security Gateway Manual Netgate-2100 7.7.2 No Serial Output If there is no output at all, check the following items: USB Cable Not Plugged In For USB consoles, the USB cable may not be fully engaged on both ends. Gently, but firmly, ensure the cable has a good connection on both sides.
Page 40 Security Gateway Manual Netgate-2100 7.7.4 Garbled Serial Output If the serial output appears to be garbled, missing characters, binary, or random characters check the following items: Flow Control In some cases flow control can interfere with serial communication, causing dropped characters or other issues.
Page 41: Reinstalling Pfsense Plus Software
Plus software on a Netgate 2100 device. ® Note: pfSense Plus is preinstalled on Netgate appliances. It is optimally tuned for Netgate hardware and contains features that cannot be found elsewhere, such as ZFS Boot Environments, OpenVPN DCO, Built-in IPFIX Export, and AWS VPC Wizard.
Page 42 Security Gateway Manual Netgate-2100 8.4 Boot the Installation Media 1. Insert the memstick into the USB port and boot the system. Tip: The best practice is to connect to the console, turn off the device gracefully by using the Halt system option from the console and removing power once the shutdown procedure completes, then insert the USB memstick and boot the device.
Page 43 Netgate-2100 8.6 Install pfSense Plus Software The installer will automatically launch and present several options. On Netgate appliances, choosing Enter for the default options will complete the installation process in most cases. Tip: There are options on the Welcome screen of the installer which can recover configuration data from a previous installation or from a USB drive.
Page 44 Security Gateway Manual Netgate-2100 In some cases it is possible to adjust the BIOS boot order to prefer the new disk, but the best practice is to wipe the old disk to remove any chance of the previous installation causing boot issues or conflicts.
Page 45: Optional M.2 Sata Installation
CHAPTER NINE OPTIONAL M.2 SATA INSTALLATION The Netgate® 2100 has built-in onboard eMMC storage. Optionally, a M.2 SATA drive could be installed as an upgrade or to bypass the onboard eMMC flash memory. Warning: Before proceeding: 1. Backup the configuration file, if possible.
Page 46 Security Gateway Manual Netgate-2100 Fig. 1: Removing the Netgate 2100 Case Screws 2. Turn system upright and carefully remove the cover. Set the cover off to the side and keep it upright so the top is not scratched. Identify where the M.2 SATA drive slot is located and remove the screw from the standoff.
Page 47 4. Gently push down the M.2 SATA card and replace the screw into the standoff. 5. Place the cover back on and turn the Netgate 2100 over. Replace the four (4) T10 Torx case screws. Be careful not to crossthread the screws or overtighten them.
Page 50: Configuring The Switch Ports
This optional guide shows the steps required to configure the 4 switched Ethernet ports as discrete ports. The following attributes are used in this configuration guide but can be changed to suit other requirements: • Netgate 2100 Ethernet Port: LAN4 • IP Address Assignment: 192.168.100.1/24 •...
Page 51 Security Gateway Manual Netgate-2100 4. In the lower right-hand corner of the screen, click + Add. 5. Choose mvneta1 (MAC Address) - lan from the Parent Interface drop-down menu. 6. Set the VLAN Tag to 4084. Type Lan port 4 as the Description. Click Save.
Page 52 Security Gateway Manual Netgate-2100 Click on + Add. 9. Click on OPT1. This is the Interface that matches the new VLAN being created. 10. Check the Enable Interface check-box. 11. Change the IPv4 Configuration Type from None to Static IPv4.
Page 53 Security Gateway Manual Netgate-2100 13. Click Save. 14. Click Apply Changes. 15. Go to Interfaces > Switches. 16. Go to the VLANs tab. Click in the Enable 802.1q VLAN mode check-box and click Save. The table will change to reflect the new mode.
Page 54 Security Gateway Manual Netgate-2100 18. Type 4084 for the VLAN Tag and 4 for Member(s). This represents LAN4 (port 4) and tagged should be unchecked. 19. Click + Add Member to add the LAN Uplink, 5. This member should be tagged as shown.
Page 55 25. Click on Port VID 1 beside LAN4. Backspace through 1 and insert 4084, the new VLAN ID. 26. Click Save. This completes the configuration of a discrete port on the Netgate 2100. By default all traffic is blocked. Create the appropriate firewall rules to allow the traffic.
Page 56: Configuring An Opt Interface As An Additional Wan
CHAPTER ELEVEN CONFIGURING AN OPT INTERFACE AS AN ADDITIONAL WAN Note: By default the Netgate 2100 is not configured with OPT interfaces. To reconfigure one or more of the LAN switch ports as an OPT interface, see Switch Overview. This guide configures an OPT port as an additional WAN type interface. These interfaces connect to upstream networks providing connectivity to the Internet or other remote destinations.
Page 57 Security Gateway Manual Netgate-2100 11.1 Requirements • This guide assumes the underlying interface is already present (e.g. physical port, VLAN, etc). • The WAN configuration type and settings must be known before starting. For example, this might be an IP address, subnet mask, and gateway value for static addresses or credentials for PPPoE.
Page 58 Security Gateway Manual Netgate-2100 Gateway IPv4 The IPv4 address of the gateway inside the same subnet. Description Optional text describing the purpose of the gateway. – Click – Ensure the new gateway is selected as the IPv4 Upstream Gateway • Check Block private networks This will block private network traffic on the interface, though if the firewall rules for this WAN are not permis- sive, this may be unnecessary.
Page 59 Security Gateway Manual Netgate-2100 11.4.2 Manual Outbound NAT If the mode is set to Manual, create a new rule or set of rules to cover the new WAN. If there are existing rules in the Mappings table, they can be copied and adjusted to use the new WAN. Otherwise, create them manually: •...
Page 60 Security Gateway Manual Netgate-2100 11.6 Gateway Groups Gateway Groups do not control traffic directly, but can be used in other places, such as firewall rules and service bindings, to influence how those areas use gateways. For most scenarios it helps to create three gateway groups to start with: PreferWAN, PreferWAN2, and LoadBalance: •...
Page 61 Security Gateway Manual Netgate-2100 Now set the default gateway to a failover group: • Navigate to System > Routing, Gateways tab • Set Default gateway IPv4 to PreferWAN • Click Save • Click Apply Changes Note: This is important for failover from the firewall itself so it always has outbound access. While this also enables basic failover for client traffic, it’s better to use policy routing rules to control client traffic behavior.
Page 62 Security Gateway Manual Netgate-2100 This will tell the firewall to use the DNS servers entered on this page and to ignore servers provided by dynamic WANs such as DHCP or PPPoE. Occasionally these providers may push conflicting DNS server information so the best practice is to assign the DNS servers manually.
Page 63 Security Gateway Manual Netgate-2100 • Click Save • Click Apply Changes 11.9 Dynamic DNS Dynamic DNS provides several benefits for multiple WANs, particularly with VPNs. If the firewall does not already have one or more Dynamic DNS hostnames configured, consider signing up with a provider and creating one or more.
Page 64: Configuring An Opt Interface As An Additional Lan
CHAPTER TWELVE CONFIGURING AN OPT INTERFACE AS AN ADDITIONAL LAN Note: By default the Netgate 2100 is not configured with OPT interfaces. To reconfigure one or more of the LAN switch ports as an OPT interface, see Switch Overview. This guide configures an OPT port as an additional LAN type interface. These local interfaces can perform a variety of tasks, such as being a guest network, DMZ, IOT isolation, wireless segment, lab network, and more.
Page 65 Security Gateway Manual Netgate-2100 12.2 Assign the Interface The first step is to assign an OPT interface. • Navigate to Interfaces > Assignments Look at list of current assignments. If the interface in question is already assigned, there is nothing to do. Skip ahead to the interface configuration.
Page 66 Security Gateway Manual Netgate-2100 See also: Interface Configuration 12.4 DHCP Server Next, configure DHCP service for this local interface. This is a convenient and easy way assign addresses for clients on the interface, but is optional if clients will be statically addressed instead.
Page 67 Security Gateway Manual Netgate-2100 Address Family IPv4 Protocol Source Either choose OPTx Subnets, which will automatically reference the new interface, or choose Network or Alias and manually fill in the new subnet, e.g. 192.168.2.0/24. Destination Translation Address WAN Address (or the customized name matching the WAN/egress interface) Description Text describing the rule, e.g.
Page 68 Security Gateway Manual Netgate-2100 Destination Description Text describing the rule, e.g. Default allow all from OPTx • Click Save • Click Apply Changes 12.6.2 Isolated In an isolated local network, hosts on the network cannot contact hosts on other networks unless explicitly allowed in the rules.
Page 69 Security Gateway Manual Netgate-2100 Add Firewall Rules With the alias in place, the next task is to create firewall rules for the interface. • Navigate to Firewall > Rules, on the OPTx tab (or the custom name) Allow DNS Add rule to allow DNS requests from local clients to the firewall itself or other DNS servers.
Page 70 Security Gateway Manual Netgate-2100 ICMP Subtype Tip: While ICMP is useful, some network administrators prefer to limit the allowed ICMP types to Echo Request only. This allows devices to use ICMP ping for diagnostic purposes, but no other types of ICMP traffic.
Page 71 Security Gateway Manual Netgate-2100 Reject Private Traffic Add rule to reject traffic from this network to all other private networks. • Click to add a new rule at the bottom of the list. • Configure the rule as follows: Action...
Page 72 Security Gateway Manual Netgate-2100 Apply Changes With the rules all in place, click Apply Changes to finish and activate the new rules. The rules should look similar to the following figure: Fig. 1: Example firewall rules for isolated LAN type segment Tip: Rule separators are useful for documenting a ruleset in place.
Page 73: Factory Reset Procedure
CHAPTER THIRTEEN FACTORY RESET PROCEDURE This procedure performs a factory reset using the hardware button on the Netgate 2100. See also: • See to locate the reset button for the device. Input and Output Ports • Factory Reset Video •...
Page 74: Switch Overview
14.1 Interface Links The four LAN ports on the Netgate 2100 are connected internally to a switch. In addition to the four physical ports there is also an internal switch port (Port 5) which acts as an uplink, and the mvneta1 interface which is the corresponding operating system interface for the switch uplink.
Page 75 Security Gateway Manual Netgate-2100 14.3 802.1q VLAN Mode It is also possible to enable 802.1q VLAN mode instead of the default port mode. Using VLANs, these four switch ports are customizable and each can be configured to act as independent interfaces.
Page 76: Additional Resources
Netgate training has got you covered. https://www.netgate.com/training 15.2 Resource Library To learn more about how to use Netgate appliances and for other helpful resources, make sure to browse the Netgate Resource Library. https://www.netgate.com/resources 15.3 Professional Services Support does not cover more complex tasks such as CARP configuration for redundancy on multiple firewalls or circuits, ®...
Page 77: Warranty And Support
CHAPTER SIXTEEN WARRANTY AND SUPPORT • One year manufacturer’s warranty. • Please contact Netgate for warranty information or view the Product Lifecycle page. • All Specifications subject to change without notice For support information, view support plans offered by Netgate.
