S902 User Guide
Document: S902-2
S902 User Guide
4x2 UHD Quad View Processor with Seamless switcher
4x HDMI 2.0 input and dual UHD outputs
Maximum input: 4096*2160 @60Hz, 4:4:4 chroma sampling
with the same or different display Windows in each output
Multiple display windows with flexible image size, cropping, location and overlap
Seamless switching in single or multi-view display modes.
Image fade in, fade out, dissolve, and wipe
True 10-bit processing and up/down scaling.
Sales & Technical support
Website : www.VigilLink.com
E-mail :
info@vigillink.com
Version:1.02
Tel : +949-701-4742
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GeoBox S902 and is the answer not in the manual?

Questions and answers

Related Manuals for VigilLink GeoBox S902

Summary of Contents for VigilLink GeoBox S902

  • Page 1 Multiple display windows with flexible image size, cropping, location and overlap Seamless switching in single or multi-view display modes. Image fade in, fade out, dissolve, and wipe True 10-bit processing and up/down scaling. Sales & Technical support Website : www.VigilLink.com E-mail : info@vigillink.com Version:1.02 Tel : +949-701-4742...

  • Page 2: Table Of Contents

    S902 User Guide Document: S902-2 Table of Contents Introduction ........................Outlook Front panel…………………………………………………………………………………………….. Back panel ............................5 System Connection ..................... Content in the packing box ..................User Guide 1. How to use IR Remote Controller ............... 1.1. P-100 Controller for User Preset Modes Recall ................7 1.2.
  • Page 3 S902 User Guide Document: S902-2 WINDOW SETUP ................... 6.2. INPUT SELECTION ........................ 15 SCALING ..........................15 WINDOW ..........................15 PICTURE ..........................15 COLOR………………………………………………………………………………………….. DE-INTERLACING…………………………………………………………………………….. NOISE REDUCTION ....................... 19 MISCELLANEOUS ......................... 19 SYSTEM 6.3. ………………………………………………………………………………………. PROFILE….…………………………………………………………………………………….. EDID ............................20 OSD ............................20 STANDBY ..........................

  • Page 4: Introduction

    S902 User Guide Document: S902-2 Introduction The S902 is a 4x2 UHD Quad-View processor that allows users to display up to four 4k/60 sources simultaneously on one or two UHD displays. This device offers a highly flexible and cost-effective solution for routing up to four 4k/60 sources to two separate displays simultaneously.

  • Page 5: Front Panel

    S902 User Guide Document: S902-2 Outlook Front panel Three functions Seamless input selection OSD function key after activate OSD menu Hotkey to load Preset-1 Quad / Single Profile SAVE/RECALL Index # keys Custom Profile Preset-2 display hotkey Input LED IR Receiver Hotkey to save Output LED INFO key...

  • Page 6: Back Panel

    S902 User Guide Document: S902-2 Back panel User can connect signal source to any of the input ports for two output ports. System control: Analog audio RH/LH Reset Hole RS232, USB, Ethernet output IR Extender Video Outputs DC 12V/2A HDMI 2.0 input source SPDIF Audio connector connector...

  • Page 7: System Connection

    S902 User Guide Document: S902-2 System Connection Each display Window can select signal from any input port. Each output can display up to 4 windows. Each window can be located at any position with flexible resizing, cropping, aspect ratio, color correction and overlap priority setting. Output ports configuration ...

  • Page 8: Content In The Packing Box

    S902 User Guide Document: S902-2 Content in the packing box The S902 Quad View Processor  1x RC-902 IR Controller  1x IR Extending Receiver with 1.8m cable  1x AC to DC Power supply unit with Power Cord  Mounting bracket with screw (Option) ...

  • Page 9: Rc-902 Controller For System Setup

    S902 User Guide Document: S902-2 1.2. RC-902 Controller for system Setup Input signal information Custom Profile Recall Menu hotkey (#1-#20) Select display window with full screen display Select Preset modes OSD Menu operation Activate OSD Menu Select Input port Select Output resolution Custom Profile One window display Recall keys...

  • Page 10: Limitation In Osd Operation

    S902 User Guide Document: S902-2 1.3. Limitation in OSD Operation OSD Menu can only show in Output-1 channel.  Window-1 and Window-2 will have full function OSD menu. “De-Interlacing” and “Noise Reduction”  OSD menu will only be available in Window-1 and Window-2. User can select audio source for each output HDMI, SPDIF and Analog R/L output independently.

  • Page 11: System Structure

    S902 User Guide Document: S902-2 2. System structure 2.1 OSD Menu location OSD will only display on Output-1. OSD menu is location at top left corner. 2.2 Display Window One output can display up to 4 Windows. Each Window can select signal source from any HDMI input port. Each Window has independent color correction and settings.

  • Page 12: System Control

    S902 User Guide Document: S902-2 4. System Control 4.1. Control method User can control S902 through IR controller, front panel keypads, USB, RS232 and Ethernet. S902 control tool is available for USB control and WebUI is embedded in S902 for Ethernet control. 4.2.

  • Page 13: Osd Menu Structure

    S902 User Guide Document: S902-2 6. OSD Menu structure 6.1. OUTPUT SETUP Below is the menu under OUTPUT SETUP:  OUTPUT MODE 12 output modes can be selected, including single Window full screen display and Quad Window display.  INPUT SELECT Each HDMI input signal can be assigned to any display Window.

  • Page 14: Transition / Duration

    S902 User Guide Document: S902-2  TRANSITION / DURATION 18 transition effects are built in the processor. It includes Quick Seamless, Fade in/Fade out, Dissolve and Wipe. Transition effect only implemented during input source or display mode change. Each effect can select different duration. User can save Transition setting in Custom Profile mode together with input selection and Window configuration.

  • Page 15: Window Setup

    S902 User Guide Document: S902-2 6.2. WINDOW SETUP WINDOW-1/WINDOW-2: with full function of OSD menu. WINDOW-3/WINDOW-4: No DE-INTEERLACING and NOISE REDUCTION OSD Menu.

  • Page 16: Input Selection

    S902 User Guide Document: S902-2  INPUT SELECTION Each Window can select any input signal source from HDMI-1 to HDMI-4. Each HDMI input signal can be assigned to multiple Windows.  SCALING RATIO: FULL: To show image with full Window. ASPECT: To show image with source original aspect ratio.

  • Page 17: Color

    S902 User Guide Document: S902-2  COLOR Color adjustment for Chromaticity color gain, Hue, Color Temperature (6500k/9300k) GAMMA1 MODE: input signal gamma curve selection. GAMMA2 MODE: output signal gamma curve selection. The vision feeling change in low brightness image will be more obvious. COLOR CORRECTION: Blue, Adjust color gain in Blue, Green and Skin Tone.
  • Page 18 S902 User Guide Document: S902-2 Motion picture field pairing (2:3/2:2 Pull Down): 24 frames/second film transferred to 60/50 frames video: o 2:3 Pull-Down: 1 frame2 frames, 2 Frame3 frames, 2 5, 24 60 o 2:2 Pull Down: increase film speed to 25 frames/second, then each frame transferred to 2 frames video.
  • Page 19 S902 User Guide Document: S902-2 Diagonal Processing: Without Diagonal Correction With Diagonal Correction With correct cadence Without correct cadence pairing PS. Usually, the default is to turn on all functions under DE-INTERLACING. In some Lab, user can turn on/off some functions to verify the type of the video source (such as the video is 3:2 or 2:2 Pulldown) for further video editing.

  • Page 20: Noise Reduction

    S902 User Guide Document: S902-2  NOISE REDUCTION The video content may come from different signal sources, such as PC, video camera, DVD, broadcasting, de-compressed video, de-compressed image… Each signal source may preserve different types of noise. S902 allows user to select different reduction type to execute the best noise reduction effect based on different video content.

  • Page 21: System

    S902 User Guide Document: S902-2 6.3. SYSTEM Below are OSD structure under SYSTEM.  PROFILE LOAD: Load custom Profile from PROFILE 1 - PROFILE 20. SAVE: Save custom Profile to PROFILE 1 - PROFILE 20.  EDID Each input port can select different EDID. 12 preset EDID can be selected for each input port.

  • Page 22: Standby

    S902 User Guide Document: S902-2  STANDBY When no input signal, S902 will turn off output signal and get into sleeping mode. Once input signal is detected, the system will turn on automatically. The time to get into sleeping mode is from 0-300 seconds. When select “0”, the system will maintain active without turn off output signal.

  • Page 23: S902 Control Tool (Sct) & Web Ui

    S902 User Guide Document: S902-2 7. S902 Control Tool (SCT) & Web UI  S902 can be controlled through SCT through USB. The PC needs to support Web HID interface. Below is the compatibility list at this moment. Chrome/Edge/Opera can fully support it. (Document from MDN Web Docs) ...
  • Page 24 S902 User Guide Document: S902-2 Please change IPV4 setting to get the same Network segment and input S902 IP address for the connection. User will see WebUI control Window for further operation. Apple Mac and iPad can also be used in WebUI control tool. 7.2.
  • Page 25 S902 User Guide Document: S902-2 7.3. When click PROFILE button, user will see below window and SAVE or LOAD custom Preset Mode in Index-1 to Index-20. The Index will be highlighted when it has been stored with Profile Data. 7.4. WINDOW SETUP allows user to select input source, set overlap priority and set Window position, size and aspect ratio freely.
  • Page 26 S902 User Guide Document: S902-2 7.5. SYSTEM: allows user to reset the system and system DATA Backup/Restore in PC. RESET: ALL RESET: Reset all settings except Custom Profile data. FACTORY RESET: Reset all settings including Custom Profile Data to factory default. BACKUP/RESTORE: SAVE: To save system data in PC DOWNLOAD Folder.

  • Page 27: Call For Technical Support

    Apart from what is detailed in User Guide, maintenance should be carried out by competent technician assigned by VIGILLINK. If S902 is physically damaged, it should be returned for repair using VIGILLINK RMA procedures. If the unit is opened by user, it will lose the right for warranty protection.

  • Page 28: Warranty And Rma Policy

    S902 User Guide Document: S902-2 10. Warranty and RMA policy 10.1. Warranty This device is designed and tested to the highest standards and backed by two years’ parts and labor warranty. Warranties are effective upon the first delivery date to the end customer and are non- transferable.

  • Page 29: Specifications

    S902 User Guide Document: S902-2 Specifications Input ports: 4x HDMI 2.0. Max. input resolution: 4096*2160 @60Hz.  Supports interleaved and progressive input signals with 4:2:0/4:2:2/4:4:4, 8/10-bit color.  Supports CEA standard video timings with high end scaling up and down up to 600 MHz. ...

  • Page 30: Disclaimer/Copyright Statement

    S902 User Guide Document: S902-2 Disclaimer/Copyright Statement Copyright 2024, VNS Inc. All Right Reserved This information contained in this document is protected by copyright. All rights are reserved by VNS Inc. VNS Inc. reserves the right to modify this document without any obligation to notify any person or entity of such revision.

  • Page 31: Revision History

    S902 User Guide Document: S902-2 Revision History Revision Date Originator Comments V1.00 2024-0305 Steve Wang First version V1.01 2024-0315 Steve Wang Add WebUI user guide V1.02 2024-0322 Steve Wang Content update...
