Commercial Stream Video Recorder (ADC-CSVR2108P/ADC-
CSVR2116P) - Installation Guide
English
English
Pre-installation checklist
• Pro Series CSVR (included)
• A display with an HDMI input (optional)
• An HDMI cable (optional)
• A display with a VGA input (optional)
• A VGA cable (optional)
• Power cord (included)
• An Ethernet Cat5e cable (included)
• USB Keyboard and Mouse (required)
• Rack mount ears and screws (included, for rack installations)
• Dedicated network switch (optional)
• Ethernet connection to broadband internet (Cable, DSL or Fiber Optic)
• Alarm.com customer account with a service package that supports the Pro Series CSVR
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(...
Updated: Fri, 06 Sep 2024 22:06:09 GMT
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADC-CSVR2108P and is the answer not in the manual?

Questions and answers

Related Manuals for Alarm.Com ADC-CSVR2108P

Summary of Contents for Alarm.Com ADC-CSVR2108P

  • Page 1 • Rack mount ears and screws (included, for rack installations) • Dedicated network switch (optional) • Ethernet connection to broadband internet (Cable, DSL or Fiber Optic) • Alarm.com customer account with a service package that supports the Pro Series CSVR https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 2 • Login and password for the Alarm.com account to which you will add the Pro Series CSVR Note: The Alarm.com Pro Series CSVR is compliant with Section 889 of the NDAA and is not produced by any entity identified on the FCC’s Covered List.
  • Page 3 Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 4 Recommended networking diagram for CSVR2108P/CSVR2116P Note: To optimize performance, Alarm.com recommends using our Pro Series PoE Cameras with the Pro Series CSVR. Adding the device to the Alarm.com account 1. Using an Ethernet cable, connect the device to the network.

  • Page 5: Mounting The Device To A Rack

    To add the device to the customer account, please use one of the following methods: Using the customer website: 1. Using a web browser, enter the following URL: www.alarm.com/addcamera. You will need the customer’s username and password to log in to the customer website.
  • Page 6 2. Using the included screws and brackets, attach a bracket to each side of the device. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 7 3. Using server rack screws (not included), attach the brackets to each side of the server rack. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...

  • Page 8: Led Guide

    4. Ensure that there is at least 10 in (25 cm) behind the device for proper airflow LED guide Network LED LED pattern Description Blinking green Client uplink active https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 9 LED pattern Description Not illuminated Client uplink inactive Power LED LED pattern Description Solid green Powered on Not illuminated Booting or powered off https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 10 Status LED LED pattern Description Solid green Connected to Alarm.com Blinking green Local network connection Solid red No connection Not illuminated Booting or powered off https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...

  • Page 11: Fcc Statements

    • Verify that all maintenance and repair work is handled by qualified personnel such as electrical engineers or network specialists. • Connect the system to an earthed main outlet. Important: The total power budget for the ADC-CSVR2108P POE ports is 120W, ADC-CSVR2116P POE ports is 200W. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(…...
  • Page 12 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Rated: • ADC-CSVR2108P - 100-240Vac, 60-50Hz, 3.5A, 190W • ADC-CSVR2116P - 100-240Vac, 60-50Hz, 6-3A, 280W Español Lista de verificación previa a la configuración •...

  • Page 13: Descripción General

    • Cuenta de cliente de Alarm.com con un paquete de servicios compatible con la grabadora de video comercial Pro Series • Usuario y contraseña de la cuenta de Alarm.com a la cual se agregará la grabadora de video comercial Pro Series Descripción general 1.
  • Page 14 Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 15 Diagrama de red recomendado para los modelos CSVR2108P/CSVR2116P Nota: para optimizar el rendimiento, Alarm.com recomienda usar nuestras cámaras PoE Pro Series con la grabadora de video comercial Pro Series. Agregar el dispositivo a la cuenta de Alarm.com 1. Utilizando un cable de Ethernet, conecte el dispositivo a la red.
  • Page 16 Para agregar el dispositivo a la cuenta de customer account, utilice uno de los siguientes métodos: Método 1: customer website 1. En un navegador web, ingrese la siguiente dirección URL: www.alarm.com/addcamera. Necesitará el nombre de usuario y la contraseña del cliente para acceder al customer website.
  • Page 17 2. Utilizando los tornillos y soportes incluidos, fije un soporte a cada lado del dispositivo. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 18 3. Con tornillos para estantes de servidor (no incluidos), fije los soportes a cada lado del estante de servidor. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 19 4. Asegúrese de dejar al menos 25 cm (10 pulgadas) detrás del dispositivo para permitir un flujo de aire adecuado. Guía de referencia de indicadores LED LED de red Patrón de LED Descripción Verde intermitente Transmisión al cliente activa https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 20 Patrón de LED Descripción LED apagado Transmisión al cliente no activa LED de encendido Patrón de LED Descripción Verde continuo Dispositivo encendido LED apagado Arranque en curso, o dispositivo apagado https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 21 LED de estado Patrón de LED Descripción Verde continuo Dispositivo conectado a Alarm.com Verde intermitente Conexión de red local Rojo continuo Sin conexión LED apagado Inicio en curso o dispositivo apagado https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 22 Clasificación: • ADC-CSVR2108P - 100-240 VCA, 60-50 Hz, 3.5 A, 190 W • ADC-CSVR2116P - 100-240 VCA, 60-50 Hz, 6-3 A, 280 W La grabadora de video comercial sólo debe conectarse a redes PoE sin enrutamiento a plantas exteriores. Asegúrese de que todo el trabajo de mantenimiento y reparación sea realizado por personal calificado, como ingenieros eléctricos...
  • Page 23 Importante: la capacidad total de energía de los puertos PoE del modelo ADC-CSVR2108P es de 120 W, y de 200 W en los puertos PoE del modelo ADC-CSVR2116P. La potencia de salida máxima de cada puerto es de 30 W. Si un dispositivo PoE consume más de 30 W, se desactivará...

  • Page 24: Vue D'ensemble

    10. Port RJ45 pour client 11. Port RJ45 pour caméra 12. Ports RJ45 pour alimentation électrique par Ethernet (PoE) Pour plus d'informations sur l’état des voyants, reportez-vous à la section Guide des voyants. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 25 Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 26 Diagramme de mise en réseau recommandée pour les appareils CSVR2108P/CSVR2116P Remarque : Pour optimiser le rendement des appareils, Alarm.com recommande l’utilisation de nos caméras PoE de série Pro avec l’enregistreur CSVR de série Pro. Ajout de l’appareil au compte de Alarm.com 1.
  • Page 27 Pour ajouter l’appareil au compte customer account, veuillez utiliser l’une des méthodes suivantes : Méthode 1 : customer website 1. Entrez l’adresse URL www.alarm.com/addcamera dans un navigateur Web. Vous aurez besoin du nom d’utilisateur et du mot de passe du client pour ouvrir une session sur customer website.
  • Page 28 2. À l’aide des vis et des supports fournis, fixez un support de chaque côté de l’appareil. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 29 3. À l’aide de vis pour bâti de serveur (non incluses), fixez les supports de chaque côté du bâti. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 30 4. Assurez-vous de laisser au moins 25 cm (10 po) derrière l’appareil pour garantir une bonne circulation d’air. Guide des voyants Voyant du réseau État des voyants Description Vert clignotant Liaison montante active du client https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 31 État des voyants Description Éteint Liaison montante inactive du client Voyant d’alimentation État des voyants Description Vert fixe Sous tension et allumé Éteint En cours de démarrage ou hors tension https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 32 Voyant d’état État des voyants Description Vert fixe Connecté à Alarm.com Vert clignotant Connexion au réseau local Rouge fixe Aucune connexion Éteint En cours de démarrage ou hors tension https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 33 à ses propres frais. Classement : • ADC-CSVR2108P - 100 à 240 V c.a., 60 à 50 Hz, 3,5 A, 190 W • ADC-CSVR2116P - 100 à 240 V c.a., 60 à 50 Hz, 6 à 3 A, 280 W L’enregistreur CSVR ne doit être connecté...
  • Page 34 Attention : Risque d’explosion si la pile est remplacée par une pile de type inapproprié. Éliminez les piles usagées conformément aux instructions. Important : Le budget énergétique total pour les ports PoE du modèle ADC-CSVR2108P est de 120 W et de 200 W pour les ports PoE de modèle ADC-CSVR2116P.

  • Page 35: Visão Geral

    • Login e senha da conta Alarm.com à qual você adicionará o CSVR Pro Series Visão geral 1. LED de rede 2. LED de status 3. LED de alimentação 4. Porta USB 3.0 5. Entrada de alimentação 6. Switch de alimentação 7.
  • Page 36 Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 37 Diagrama de rede recomendado para CSVR2108P/CSVR2116P Observação: para otimizar o desempenho, Alarm.com recomenda o uso de nossas câmeras PoE Pro Series com o CSVR Pro Series. Como adicionar o dispositivo à conta Alarm.com 1. Use um cabo Ethernet para conectar o dispositivo à rede.
  • Page 38 Para adicionar o dispositivo à conta customer account, use um dos seguintes métodos: Método 1: customer website 1. Em um navegador, acesse: www.alarm.com/addcamera. Você precisará do nome de usuário e da senha do cliente para fazer login no site customer website.
  • Page 39 2. Usando os parafusos e suportes fornecidos, prenda um suporte em cada lado do dispositivo. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 40 3. Usando parafusos para rack de servidor (não fornecido), prenda os suportes em cada lado do rack de servidor. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 41 4. Verifique se há pelo menos 25 cm (10 pol.) de espaço livre atrás do dispositivo para garantir o fluxo de ar adequado. Legenda dos LEDs https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 42 Padrão do LED Descrição Pisca em verde Uplink do cliente ativo Permanece apagado Uplink do cliente inativo LED de alimentação Padrão do LED Descrição Permanece aceso em verde Ligado Permanece apagado Inicializando ou desligado https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 43 LED de status Padrão do LED Descrição Permanece aceso em verde Conexão a Alarm.com Pisca em verde Conexão à rede local Permanece aceso em vermelho Sem conexão Permanece apagado Inicializando ou desligado https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(… Updated: Fri, 06 Sep 2024 22:06:09 GMT...
  • Page 44 às suas próprias custas. Classificação: • ADC-CSVR2108P – 100-240 VCA, 60-50 Hz, 3,5 A, 190 W • ADC-CSVR2116P – 100-240 VCA, 60-50 Hz, 6-3 A, 280 W O CSVR deve ser conectada apenas a redes PoE sem roteamento para instalações externas. Certifique-se de que todos os trabalhos de manutenção e reparo sejam executados por pessoal qualificado, como engenheiros eletricistas...
  • Page 45 Importante: A alimentação total destinada às portas POE do ADC-CSVR2108P é de 120 W; para as portas POE do ADC-CSVR2116P, esse total é de 200 W. A saída máxima para cada porta é 30 W. Caso um dispositivo PoE consuma mais de 30 W, a alimentação PoE será...
