Argo AEG35PIH Installation Manual

Dc inverter single-split air conditioner, outdoor/indoor units
Hide thumbs Also See for AEG35PIH:

Advertisement

Quick Links

INSTALLATION MANUAL
DC Inverter Single-Split Air Conditioner
OUTDOOR UNITS
AEG35PIH
AEG50PIH
AEG70PIH
AEG83PIH
AEG100PIH
AEG140PIH
AEG140PIH
AEG100PIH3
AEG140PIH3
AEG160PIH3
Please read this manual carefully before installing and using the air conditioner, and
retain for future reference.
INDOOR UNITS
ASG35PH
ASG50PH
ASG70PH
ASG83PH
ASG100PH
ASG140PH
ASG160PH
V 03/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEG35PIH and is the answer not in the manual?

Questions and answers

Summary of Contents for Argo AEG35PIH

  • Page 1 INSTALLATION MANUAL DC Inverter Single-Split Air Conditioner OUTDOOR UNITS INDOOR UNITS AEG35PIH ASG35PH AEG50PIH ASG50PH AEG70PIH ASG70PH AEG83PIH ASG83PH AEG100PIH ASG100PH AEG140PIH AEG140PIH ASG140PH AEG100PIH3 ASG160PH AEG140PIH3 AEG160PIH3 Please read this manual carefully before installing and using the air conditioner, and retain for future reference.
  • Page 2: Table Of Contents

    Contents 1 Safety Precautions ..................1 2 Outline of the Unit and Main Parts..............3 3 Preparative for Installation ................4 3.1 Standard Accessory Parts ................4 3.2 Selection of the Installation Location ............5 3.3 Connection Pipe Requirement ..............7 3.4 Electrical Requirement ................
  • Page 3: Safety Precautions

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 1 Safety Precautions This mark indicates procedures which, if improperly performed, might lead to the WARNING! death or serious injury of the user. This mark indicates procedures which, if improperly performed, might possibly result CAUTION! in personal harm to the user, or damage to property.
  • Page 4 DC Inverter Single-Split Air Conditioner Cassette Type Unit (14). During installation, attach the refrigerant piping securely before running the compressor. If the compressor is not attached and the stop valve is open during pump-down, air will be sucked in when the compressor is run, causing abnormal pressure in the freezer cycle which will lead to breakage and even injury.
  • Page 5: Outline Of The Unit And Main Parts

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 2 Outline of the Unit and Main Parts Indoor 1. Drainage device 2. Drainage pipe 3. Air flow flap Outdoor 4. Connection pipe Air inlet 5. Wired Controller 6. Wireless Controller 7. Big handle 8.
  • Page 6: Preparative For Installation

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 3 Preparative for Installation 3.1 Standard Accessory Parts The standard accessory parts listed below are furnished and should be used as required. Table 1 Indoor Unit Accessories Name Appearance Q'ty Usage To connect with the hard PVC drain Drain Hose pipe To fix the hook on the cabinet of the...
  • Page 7: Selection Of The Installation Location

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 3.2 Selection of the Installation Location WARNING! The unit must be installed where strong enough to withstand the weight of the unit and fixed securely, otherwise the unit would topple or fall off. CAUTION! ①...
  • Page 8 DC Inverter Single-Split Air Conditioner Cassette Type Unit Table 3 Models H(mm) ASG83PH ASG100PH ASG140PH ASG160PH Fig.2 3.2.2 Outdoor Unit WARNING! ① . Install the unit where it will not be tilted by more than 5°. ② . During installation, if the outdoor unit has to be exposed to strong wind, it must be fixed securely. If possible, do not install the unit where it will be exposed to direct sunlight.
  • Page 9: Connection Pipe Requirement

    Pipe Difference between pipe(Outer Diameter × wall Length Indoor Unit and Model Liquid Outdoor Unit (m) thickness) (mm) ASG35PH AEG35PIH ASG50PH AEG50PIH ASG70PH AEG70PIH ASG83PH AEG83PIH ASG100PH AEG100PIH ASG140PH AEG140PIH Φ25×1.5 ASG100PH AEG100PIH3 ASG140PH ASG160PH AEG160PIH3 The connection pipe should be insulated with proper water-proof insulating material.
  • Page 10 DC Inverter Single-Split Air Conditioner Cassette Type Unit Table 6 Minimum Sectional Area of Power Capability of Air Model Power Cable and Earth line Supply Switch(A) AEG35PIH AEG50PIH AEG70PIH 220-240V~ 50Hz AEG83PIH AEG100PIH AEG140PIH AEG100PIH3 AEG140PIH3 380-415V 3N~ 50Hz AEG160PIH3 Notes: The fuse is located on the main board.
  • Page 11: Installation Of The Unit

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 4 Installation of the Unit 4.1 Installation of the Indoor Unit 4.1.1 Indoor unit dimension Fig.4 Table 7 Item Model ASG35PH ASG50PH ASG83PH ASG100PH ASG140PH 1040 ASG160PH 4.1.2 Installing the Main Body Unit Fig.5...
  • Page 12: Installation Of The Outdoor Unit

    DC Inverter Single-Split Air Conditioner Cassette Type Unit (1). Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
  • Page 13 DC Inverter Single-Split Air Conditioner Cassette Type Unit 4.2.1 Outdoor unit dimension Fig.10 Table 8 Unit: mm Item Model AEG35PIH AEG50PIH AEG70PIH AEG83PIH AEG100PIH 1107 1100 AEG100PIH3 AEG140PIH 1349 AEG141PIH3 AEG160PIH3 1085 1365 4.2.2 Condensate Drainage of the Outdoor Unit(Only for the heat pump unit) (Fig.11) (1).
  • Page 14: Installation Of The Connection Pipe

    DC Inverter Single-Split Air Conditioner Cassette Type Unit Bottom Drain cap Drain pipe mounting hole Fig.11 4.3 Installation of the Connection Pipe 4.3.1 Flare Processing (1). Cut the connection pipe with the pipe cutter and remove the burrs. (2). Hold the pipe downward to prevent cuttings from entering the pipe. (3).
  • Page 15 DC Inverter Single-Split Air Conditioner Cassette Type Unit CAUTION! ① . To prevent breaking of the pipe, avoid sharp bends. Bend the pipe with a radius of curvature of 150 mm or over. ② . If the pipe is bent repeatedly at the same place, it will break. 4.3.3 Connecting the Pipe at the Indoor Unit Side Detach the caps and plugs from the pipes.
  • Page 16 DC Inverter Single-Split Air Conditioner Cassette Type Unit Table 9 Flare nut tightening torque Pipe Diameter Tightening Torque 1/4˝(Inch) 15-30 (N·m) 3/8˝(Inch) 35-40 (N·m) 5/8˝(Inch) 60-65 (N·m) 1/2˝(Inch) 45-50 (N·m) 3/4˝(Inch) 70-75 (N·m) 7/8˝(Inch) 80-85 (N·m) CAUTION! Be sure to connect the gas pipe after connecting the liquid pipe completely. 4.3.4 Connecting the Pipe at the Outdoor Side Unit Tighten the flare nut of the connection pipe at the outdoor unit valve connector.
  • Page 17: Vacuum And Gas Leakage Inspection

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 4.3.7Liquid Pipe and Drain Pipe Sealed If the outdoor unit is installed lower than the indoor unit (See Fig.18) Saddle (1). A drain pipe should be above ground and the end of the pipe does not dip into water.
  • Page 18 DC Inverter Single-Split Air Conditioner Cassette Type Unit (5). The evacuation duration depends on the unit’s capacity, generally, 15 minutes for the 12K units, 20 minutes for the 18K units, 30 minutes for the 24/30/36K units, 45 minutes for the 42/48/60 units.
  • Page 19: Installation Of The Drain Hose

    DC Inverter Single-Split Air Conditioner Cassette Type Unit When the height difference between the indoor unit and outdoor unit is larger than 10 meters, an oil bend should be employed for every 6 meters. Outdoor Oil bend Indoor Oil bend Fig.21 4.5 Installation of the Drain Hose 4.5.1 Installationof Drain Piping...
  • Page 20 DC Inverter Single-Split Air Conditioner Cassette Type Unit Tighten the clamp until the screw head is less Insulate the pipe clamp and the drain hose using heat then 4mm from the hose. insulation sponge. Metal clamp Metal clamp (accessory) Drain hose (accessory) Insulation sponge (accessory) Grey tape (accessory) (3).
  • Page 21 DC Inverter Single-Split Air Conditioner Cassette Type Unit 3-way connection Connection of drain elbow of drainage pipe joint Connection of horizontal pipe Fig.27 Fig.28 Fig.29 4.5.3 Precautions When Doing Riser Piping Work (1). Make sure that heat insulation work is executed on the following 2 spots to prevent any possible water leakage due to dew condensation.
  • Page 22: The Panel Installation

    DC Inverter Single-Split Air Conditioner Cassette Type Unit Drain hose(attachment) Fig.32 4.5.4 Testing of Drain Piping After piping work is finished, check if drainage flows smoothly. Shown in the Fig.33, Add approximately 1liter of water slowly into the drain pan and check drainage flow during COOL running.
  • Page 23 DC Inverter Single-Split Air Conditioner Cassette Type Unit (2). Improper screwing of the screws may cause the troubles shown in Fig.35. Condensate Fig.35 (3). If gap still exists between ceiling and decoration panel after tightening the screws, readjust the height of the indoor unit. (Fig.36) Fig.36 (4).
  • Page 24: Electrical Wiring

    DC Inverter Single-Split Air Conditioner Cassette Type Unit (4). Adjust the panel along the direction indicated by the arrow as shown in Fig.38. (5). Tighten the screws until the thickness of the sealing material between the panel and the indoor unit reduces to 5-8cm. Fig.38 4.7 Electrical Wiring 4.7.1 Wiring Precautions...
  • Page 25 DC Inverter Single-Split Air Conditioner Cassette Type Unit ⑤ . Use a special branch circuit breaker and receptacle matched to the capacity of the air conditioner. ⑥ . The special branch circuit breaker is installed in the permanent wiring. Always use a circuit that can trip all the poles of the wiring and has an isolation distance of at least 3mm between the contacts of each pole.
  • Page 26 ⑤ . Always fasten the outside covering of the connection cord with cord clamps. (If the insulator is not clamped, electric leakage may occur.) ⑥ . Always connect the ground wire. (4). Electric wiring between the indoor and outdoor units Single-phase units(12K~30K) AEG35PIH+ASG35PH AEG50PIH+ASG50PH ① . Power cord 3×1.5mm (H07RN-F) ② . Power cord 3×1.0mm (H05RN-F) ③...
  • Page 27 DC Inverter Single-Split Air Conditioner Cassette Type Unit Single-phase units(36K~48K) AEG100PIH+ASG100PH ① . Power cord 3×2.5mm (H07RN-F) ② . Power cord 3×1.0mm (H05RN-F) ③ . Communication Cords 2×0.75mm (H05RN-F) AEG140PIH+ASG140PH ① . Power cord 3×6.0mm (H07RN-F) (H05RN-F) ② . Power cord 3×1.0mm ③...
  • Page 28 DC Inverter Single-Split Air Conditioner Cassette Type Unit CAUTION! ① . The power cord and the wire of the fresh air valve are high-voltage, while the communication cord and connection wire of the wired controller are low-voltage. They should run separately against electromagnetic interference.
  • Page 29: Installation Of Controllers

    DC Inverter Single-Split Air Conditioner Cassette Type Unit Three-phase: 36K~60K Fig.45 Routing of External Power Lines Power lines should go along the right side plate and be fixed to the fixation hook with binding wires to keep no contact with pipelines. Communication lines between indoor and outdoor units also should go along the right side plate and keep away from power lines.
  • Page 30 DC Inverter Single-Split Air Conditioner Cassette Type Unit Indoor fan motor error Full water protection Indoor ambient temperature sensor error Evaporator temperature sensor error Condenser temperature sensor error Outdoor ambient temperature sensor error Discharge temperature sensor error Temperature sensor error of wired controller Capacity code error Outdoor memory chip error Electric box sensor error...
  • Page 31: Working Temperature Range

    DC Inverter Single-Split Air Conditioner Cassette Type Unit (2). Instructions to the Error Indicating Lamps on the Panel of the Cassette Type Unit. Receiver "88" Dispaly "Auto" Button Power Timer "Test" Button Indicating Lamp Indicating Lamp Fig.47 Power and ON/OFF Indicating Lamp: ◆...
  • Page 32: Troubleshooting And Maintenance

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 7 Troubleshooting and Maintenance 7.1 Troubleshooting If your air-conditioning unit suffers from abnormal operation or failure, please first check the following points before repair: Table 13 Failure Possible Reasons The power supply is not connected. ①...
  • Page 33: Routine Maintenance

    DC Inverter Single-Split Air Conditioner Cassette Type Unit 7.2 Routine Maintenance Only a qualified service person is allowed to perform maintenance. Before accessing to terminal devices, all power supply circuits must be disconnected. Do not use water or air of 50°C or higher for cleaning air filters and outside panels. Notes: Do not operate the air conditioner with the filter uninstalled, otherwise dust would come into ①...
  • Page 34 DC Inverter Single-Split Air Conditioner Cassette Type Unit 2. Disassemble the air inlet grille Open the air inlet grille at 45°, raise it and remove the grille. 3. Disassemble the filter screen Draw out the filter screen and remove it. Filter screen 4.
  • Page 36 REGOLAMENTO (UE) N. 517/2014 - F-GAS L’unità contiene R410A, un gas fluorurato a effetto serra, con potenziale di riscaldamento globale (GWP) = 2087,50. Non disperdere R410A nell’ambiente. AEG35PIH - Kg. 1,2 = 2,51 Tonn CO equiv. AEG50PIH - Kg. 1,4 = 2,92 Tonn CO equiv.
