- Page 1 INSTALLATION INSTRUCTIONS ISTRUZIONI D’INSTALLAZIONE NOTICE D’INSTALLATION AEI1G65EMX AEI1G65EMX3PH Split air conditioner system Condizionatore d’aria split system Climatiseur split 37.4255.190.01 02/2022...
-
Page 2: Table Of Contents
CONTENTS 1 - Installation site selection..............4 2 - System wiring diagram ..............4 3 - Wires’ size and delayed fuse ............6 4 - Additional material required for installation (not supplied) .....6 5 - Operating limits and models combination ........7 6 - Tubing length and elevation difference limits .........8 7 - Accessories supplied with the unit ..........8 8 - Tools required for installation (not supplied) ........8 9 - Dimensions, weight and tubes connection ........9... - Page 3 WARNING When wiring ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH. ONLY A QUALIFIED, EXPERIENCED ELECTRICIANS SHOULD ATTEMPT TO WIRE THIS SYSTEM. • Do not supply power to the unit until all wiring and tubing are completed or reconnected and checked, to ensure the grounding.
-
Page 4: 1 - Installation Site Selection
1 - INSTALLATION SITE SELECTION AVOID • Heat sources, exhaust fans. • Direct sunlight. • Damp, humid or uneven locations. • To make holes in areas where electrical wiring or conduits are located. • Choose places as cool as possible and well ventilated. •... - Page 5 3 INDOOR UNITS 1 PHASE POWER SUPPLY AC 380-415V 1 INDOOR UNIT 3PHASE 50Hz 3 PHASE POWER SUPPLY AC 380-415V 3PHASE 50Hz 2 INDOOR UNITS 3 PHASE...
-
Page 6: Wires' Size And Delayed Fuse
3 - WIRES’ SIZE AND DELAYED FUSE Max. electric input MODEL S ( mm S ( mm S ( mm kW / A AEI1G65EMX 2,8 / 12,7 16 A 0,75 AEI1G65EMX3PH 2,8 / 4,7 12,5 A Supply power wire A: Multipolar electric wire;... -
Page 7: Operating Limits And Models Combination
5 - OPERATING LIMITS AND MODELS COMBINATION OPERATING LIMITS ■ Heating Maximum conditions ■ Cooling Maximum conditions Outdoor temperature : 43°C D.B. Outdoor temperature : 24°C D.B. / 18°C W.B. Room temperature : 27°C D.B. Room temperature : 32°C D.B. / 23°C W.B. ■... -
Page 8: Tubing Length And Elevation Difference Limits
6 - TUBING LENGTH AND ELEVATION DIFFERENCE LIMITS AT SHIPMENT ADDITIONAL REFRIGERANT L Tot. (m) L n (m) L Tot. (m) L n (m) MONO SPLIT AEI1G65 DUAL SPLIT TRIAL SPLIT L Tot. = Total tubing length (L1 + L2 + L3...) Ln = Maximum tubing length of a single indoor unit (n=1,2,3...) REQUIRED AMOUNT OF ADDITIONAL REFRIGERANT... -
Page 9: Dimensions, Weight And Tubes Connection
9 - DIMENSIONS, WEIGHT AND TUBES CONNECTION Weight: 64 kg Unit: mm For TUBES CONNECTION see section at the end of this manual (page 20). -
Page 10: Installation Procedure
10 - INSTALLATION PROCEDURE Heat pump version. Minimum operation and maintenance area. Use, if necessary, the accessories supplied. Remove the side cover, then connect the power line Use insulated copper tube. Cut approximate 30-50 and interconnecting wires to outdoor unit on the cm. - Page 11 A good flare has the following characteristics: Tighten connections using a spanner and a torque - inside surface is glossy and smooth wrench; apply specified torque (see table). - edge is smooth - tapered sides are of uniform length. Apply refrigerant lubricant to the matching surface of the flare and union before connecting them together.
-
Page 12: Basic Functions Of The Service Valves
With vacuum pump still running close the low pressure knob on valve manifold. Then stop vacuum pump. Using an hexagonal key, open the service valve on small tube, then close it after 10 seconds. Check tightness of all joints using liquid soap. Turn the service valves stem in counterclockwise to fully open the valves. -
Page 13: Pump Down Procedure
Complete insulation of refrigerant tubes; wrap with armoning tape. Fix and support tubes with brackets. Seal hole in the wall, if necessary. 12 - PUMP DOWN PROCEDURE Connect a valve manifold to the charge port on a Turn on the unit’s operating switch and start wide tube service valve, partially open it (1/4 turn). -
Page 14: Outdoor/Indoor Unit Refrigerant Circuit Address
13 - OUTDOOR/INDOOR UNIT REFRIGERANT CIRCUIT ADDRESS BEFORE STARTING THE SYSTEM, IT IS NECESSARY TO SET THE REFRIGERANT CIRCUIT ADDRESSES. CAUTION THE SETTING HAS TO BE MADE ON THE INDOOR UNITS AND FOR EACH INDOOR UNIT OF THE SYSTEM. FOR THE SETTING, SEE THE INSTALLATION MANUAL OF THE SPECIFIC INDOOR UNIT. -
Page 15: Auto-Diagnosis Table
15 - AUTO-DIAGNOSIS TABLE CAUTION Disconnect power and wait that all LEDs are OFF before servicing on the electrical box. X LED OFF O LED ON LED BLINKING LEDs ON BOARD DESCRIPTION COD. TEST MODE ERROR WRONG OUTDOOR-INDOOR UNITS COMBINATION COMPRESSOR TOP SHELL PROBE DAMAGED OR NOT CONNECTED NTTC PROBE DAMAGED OR NOT CONNECTED WTTC PROBE DAMAGED OR NOT CONNECTED... -
Page 16: Electrical Wiring Diagram
16 - ELECTRICAL WIRING DIAGRAM • SCHEMA ELETTRICO • SCHÉMA ÉLECTRIQUE COLOURS BLACK NERO NOIR SCHWARZ NEGRO PRETO BLUE BLEU BLAU AZUL AZUL BROWN MARRONE MARRON BRAUN MARRÓN CASTANHO GRN / YEL - G / Y GREEN / YELLOW VERDE / GIALLO VERT / JAUNE GRÜN / GELB VERDE / AMARILLO VERDE / AMARELO... - Page 17 SYMBOL CONTROL BOARD SCHEDA CONTROLLO CARTE DE COMMANDE 2V EXPANSION BOARD SCHEDA ESPANSIONE 2V CARTE D’EXPANSION 2V 4V EXPANSION BOARD SCHEDA ESPANSIONE 4V CARTE D’EXPANSION 4V DC BUS 3PH CONDERSER CONDENSATORE DC BUS 3PH CONDENSATEUR DC BUS 3PH CCH1 COMPRESSOR CRANK CASE HEATER RESISTENZA COMPRESSORE RESISTANCE DU COMPRESSEUR CCH2...
-
Page 18: Refrigerant Circuit
17 - REFRIGERANT CIRCUIT • CIRCUITO FROGORIFERO • CIRCUIT RÉFRIGÉRANT... - Page 19 SYMBOL COMPRESSOR COMPRESSORE COMPRESSEUR 4 WAY INVERSION VALVE VALVOLA INVERSIONE 4 VIE VANNE D’INVERSION 4 VOIES DEFROST VALVE VALVOLA DEFROST SOUPAPE DE DÉGIVRAGE EXPANSION VALVE A-B-C-D-E-F VALVOLA DI ESPANSIONE A-B-C-D-E-F VANNE RÉVERSIBLE A-B-C-D-E-F COMPRESSOR DISCHARGE SENSOR SONDA TEMP. MANDATA COMPRESS. CAPTEUR DECHARGE COMPRESSEUR COMPR.
- Page 20 TUBES CONNECTION • CONNESSIONE TUBI • CONNEXION DES TUBES SYSTEM CONFIGURATION EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL SYSTEM CONFIGURATION EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL...
- Page 21 SYSTEM CONFIGURATION EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL EMIX PORT: SEE EMIX UNIT OR EMIX TANK INSTALLATION MANUAL...
- Page 22 Società a socio unico Via Alfeno Varo, 35 - 25020 Alfianello - BS - Italy Tel. +39 030 7285700 www.argoclima.com...
