Argo ADG35PH Installation Manual

Dc inverter single-split air conditioner

Advertisement

Quick Links

INSTALLATION MANUAL
DC Inverter Single-Split Air Conditioner
OUTDOOR UNITS
AEG35PIH
AEG50PIH
AEG70PIH
AEG83PIH
AEG100PIH
AEG100PIH3
AEG140PIH
AEG140PIH3
AEG160PIH3
Please read this manual carefully before installing and using the air conditioner, and
retain for future reference.
INDOOR UNITS
ADG35PH
ADG50PH
ADG70PH
ADG83PH
ADG100PH
ADG140PH
ADG160PH
V 07/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADG35PH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argo ADG35PH

  • Page 1 INSTALLATION MANUAL DC Inverter Single-Split Air Conditioner OUTDOOR UNITS INDOOR UNITS AEG35PIH ADG35PH AEG50PIH ADG50PH AEG70PIH ADG70PH ADG83PH AEG83PIH ADG100PH AEG100PIH ADG140PH AEG100PIH3 ADG160PH AEG140PIH AEG140PIH3 AEG160PIH3 Please read this manual carefully before installing and using the air conditioner, and retain for future reference.
  • Page 2: Table Of Contents

    Contents 1 Safety Precautions ..................1 2 Outline of the Unit and Main Parts..............2 3 Preparative for Installation ................3 3.1 Standard Accessory Parts ................3 3.2 Selection of the Installation Location ............4 3.3 Connection Pipe Requirement ..............5 3.4 Electrical Requirement ................
  • Page 3: Safety Precautions

    DC Inverter U-match Series Duct Type Unit 1 Safety Precautions This mark indicates procedures which, if improperly performed, might lead to the WARNING! death or serious injury of the user. This mark indicates procedures which, if improperly performed, might possibly CAUTION! result in personal harm to the user, or damage to property.
  • Page 4: Outline Of The Unit And Main Parts

    DC Inverter U-match Series Duct Type Unit 2 Outline of the Unit and Main Parts Indoor Air outlet Air inlet 1. power Cord 2. Electric Box 3. Wired controller Outdoor 4. Wireless Controller Air inlet 5. Binding tape 6. Drain Pipe 7.
  • Page 5: Preparative For Installation

    DC Inverter U-match Series Duct Type Unit 3 Preparative for Installation 3.1 Standard Accessory Parts The standard accessory parts listed below are furnished and should be used as required. Table 1 Indoor Unit Accessories Name Appearance Q'ty Usage Wired Controller To control the indoor unit Hanger To fix the indoor unit...
  • Page 6: Selection Of The Installation Location

    DC Inverter U-match Series Duct Type Unit Table 2 Outdoor Unit Accessories Name Appearance Q'ty Usage Drain Plug To plug the unused drain hole. To connect with the hard PVC Drainage Connecter drain pipe 3.2 Selection of the Installation Location WARNING! The unit must be installed where strong enough to withstand the weight of the unit and fixed securely, otherwise the unit would topple or fall off.
  • Page 7: Connection Pipe Requirement

    DC Inverter U-match Series Duct Type Unit 3.2.2 Outdoor Unit WARNING! Install the unit where it will not be tilted by more than 5°. ① . During installation, if the outdoor unit has to be exposed to strong wind, it must be fixed ②...
  • Page 8: Electrical Requirement

    Max. Max. Height Drainage Pipe(Inch) Pipe Difference between pipe(Outer Item Length Indoor Unit and Diameter × wall Liquid Model Outdoor Unit (m) thickness) (mm) ADG35PH AEG35PIH Φ30X1.5 ADG50PH AEG50PIH Φ30X1.5 ADG70PH AEG70PIH Φ20X1.2 ADG83PH AEG83PIH Φ20X1.2 ADG100PH AEG100PIH Φ20X1.2 ADG100PH AEG100PIH3 Φ20X1.2...
  • Page 9: Installation Of The Unit

    DC Inverter U-match Series Duct Type Unit Note: The fuse is located on the main board. ① . Install the disconnect device with a contact gap of at least 3mm in all poles nearby the units ② . (Both indoor unit and outdoor unit).The appliance must be positioned so that the plug is accessible.
  • Page 10 DC Inverter U-match Series Duct Type Unit For the units: 12~18K Air intake For the units: 24~36K Liquid Pipe Gas Pipe Air Intake Drainage Pipe Electric Box...
  • Page 11 DC Inverter U-match Series Duct Type Unit For the units: 48k,60k Fig.4 Table 6 Item Model ADG35PH 1037 ADG50PH ADG70PH 1101 1159 1279 1002 ADG83PH ADG100PH 1011 1115 1226 ADG140PH 1177 1150 1340 ADG160PH...
  • Page 12 DC Inverter U-match Series Duct Type Unit 4.1.2 Drilling Holes for Bolts and Installing the Bolts Using the installation template, drill holes for bolts (four holes). (Fig. 5) 4.1.3 Installing the Suspension Bolts (1). Install the bolts to the ceiling at a place strong enough to hang the unit. Mark the bolt positions from the installation template.
  • Page 13: Installation Of The Outdoor Unit

    DC Inverter U-match Series Duct Type Unit 4.1.4 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. Horizontal tester Fig.10 4.2 Installation of the Outdoor Unit WARNING Install the unit where it will not be tilted by more than 5°.
  • Page 14: Installation Of The Connection Pipe

    DC Inverter U-match Series Duct Type Unit AEG70PIH AEG83PIH AEG100PIH 1107 1100 AEG100PIH3 AEG140PIH 1349 AEG140PIH3 AEG160PIH3 1085 1365 4.2.2 Condensate Drainage of the Outdoor Unit(Only for the heat pump unit) (Fig.12) (1). It is required to install a drain pipe for the outdoor unit to drain out the condensate water during heating operation.
  • Page 15 DC Inverter U-match Series Duct Type Unit 4.3.2 Bending Pipes (1). The pipes are shaped by your hands. Be careful not to collapse them. √ × Fig.14 (2). Do not bend the pipes in an angle more than 90°. (3). When pipes are repeatedly bent or stretched, the material will harden, making it difficult to bend or stretch them any more.
  • Page 16 DC Inverter U-match Series Duct Type Unit When the flare nut is tightened properly by your hand, use a torque wrench to finally tighten it. Fig.16 Fig.17 Table 7 Flare nut tightening torque Pipe Diameter Tightening Torque 1/4˝(Inch) 15-30 (N·m) 3/8˝(Inch) 35-40 (N·m) 5/8˝(Inch)
  • Page 17 DC Inverter U-match Series Duct Type Unit Fig.19 4.3.7 Liquid Pipe and Drain Pipe Sealed If the outdoor unit is installed lower than the indoor unit (See Fig.20) Saddle (1). A drain pipe should be above ground and the end of the pipe does not dip into water.
  • Page 18: Vacuum And Gas Leakage Inspection

    DC Inverter U-match Series Duct Type Unit 4.4 Vacuum and Gas Leakage Inspection CAUTION! Do not purge the air with refrigerants but use a vacuum pump to vacuum the installation! There is no extra refrigerant in the outdoor unit for air purging! 4.4.1 Vacuum (1).
  • Page 19: Installation Of The Drain Hose

    DC Inverter U-match Series Duct Type Unit During evacuation, it is available to connect two hoses of the manifold valve assembly to two service ports to quicken the evacuating speed. 4.4.2 Additional Charge Refrigerant suitable for a piping length of 5m is charged in the 09~42K outdoor unit at the factory, and for 48~60K outdoor unit refrigerant is charged for a piping length of 7.5m.
  • Page 20 DC Inverter U-match Series Duct Type Unit √ × Fig.23 Fig.24 Fig.25 Condensate Drainpipe As the inside of the unit is in the negative pressure status, it is required to set up a backwater elbow. The Enlarged View requirements is: Condensate Drainpipe A=B ≥...
  • Page 21 DC Inverter U-match Series Duct Type Unit (5). Use a suitable drain hose, and see Table 3 for its size. (6). There is a drain port on both the left and right sides. Select the drain port to match the local conditions.(Fig.25) (7).
  • Page 22: Installation Of The Duct

    DC Inverter U-match Series Duct Type Unit the drain port to withstand additional force. Fig.31 b. When multiple drain hoses are used, their installation should be performed as shown in the figure below. Fig.32 4.5.2 Testing of Drain Piping After piping work is finished, check if drainage flows smoothly.
  • Page 23 DC Inverter U-match Series Duct Type Unit Fig.35 Return Air Inlet Table 9 Supply Air Outlet Return Air Inlet Item Model ADG35PH ADG50PH ADG70PH ADG83PH ADG100PH 1000 ADG140PH ADG160PH 4.6.2 Installation of the Supply Air Duct (1). Installation of the Rectangular Duct.
  • Page 24 DC Inverter U-match Series Duct Type Unit (2). The default installation location of the rectangular flange is at the back, as shown in Fig.37. Rectangular Flange Rear Return Air Bottom Return Air Return Air Cover Plate Fig.37 (3). If the bottom return air is desired, just change the place of the rectangular flange and the return air cover plate.
  • Page 25: Electrical Wiring

    DC Inverter U-match Series Duct Type Unit 4.7 Electrical Wiring 4.7.1 Wiring Precautions WARNING ! Before obtaining access to terminals, all supply circuits must be disconnected. ① . The rated voltage of the unit is as shown as table 4 and Table 5 ②...
  • Page 26 DC Inverter U-match Series Duct Type Unit 2). Using a screwdriver, remove the terminal screw (s) on the terminal board. 3). Using a round terminal fastener or pliers, securely clamp a round terminal to each stripped wire end. 4). Position the round terminal wire, and replace and tighten the terminal screw with a screwdriver.(Fig.40) Fig.39 Fig.40...
  • Page 27 DC Inverter U-match Series Duct Type Unit (4). Electric wiring between the indoor and outdoor units Single-phase units (12K~30K) AEG35PIH+ADG35PH AEG50PIH+ADG50PH ① . Power cord 3×1.5mm (H07RN-F) ② . Power cord 3×1.0mm (H05RN-F) ③ . Communication Cords 2×0.75mm (H05RN-F) AEG70PIH+ADG70PH AEG83PH+ADG83PH ①...
  • Page 28 DC Inverter U-match Series Duct Type Unit (5). Electric wiring of indoor unit side Remove the electric box cover from the electric box sub-assy and then connect the wire. Fig.43 The F, C, O connect to the COMMOM, CLOSE and OPEN terminal of the fresh air valve respectively.
  • Page 29 DC Inverter U-match Series Duct Type Unit Single phase: 09K~12K 18K~30K 36K~48K Fig.44 Three-phase: 36K~60K Fig.45 Routing of External Power Lines Power lines should go along the right side plate and be fixed to the fixation hook with binding wires to keep no contact with pipelines.
  • Page 30: Installation Of Controllers

    DC Inverter U-match Series Duct Type Unit 5 Installation of Controllers Refer to the Installation Manual of the controller for more details. 6 Test Running 6.1 Trial Operation and Testing (1). The meaning of error codes as shown below: Table 11 Number Error code Error...
  • Page 31: Working Temperature Range

    DC Inverter U-match Series Duct Type Unit Drive current error Sensor connecting protection Temperature drift protection Bus low voltage protection Bus high voltage protection Charge loop error Input voltage abnormality Drive memory chip error Note: When the unit is connected with the wired controller, the error code will be simultaneously shown on it.
  • Page 32: Unit Function

    DC Inverter U-match Series Duct Type Unit 7 Unit Function 7.1 Setting of Double Indoor Room Sensors This series of ducted air-conditioning unit has two indoor room sensors. One is located at the air intake of the indoor unit and the other one is located inside the wire controller. User can select one from the two indoor room sensors on the basis of the engineering requirement.
  • Page 33: Fresh Air Control

    DC Inverter U-match Series Duct Type Unit 7.3 Fresh Air Control 11-levels control can be realized for the amount of fresh air taken in. The function not only facilitates the health of users, but also controls the electricity consumption loss because of taking in fresh air.
  • Page 34: Troubleshooting And Maintenance

    DC Inverter U-match Series Duct Type Unit 8 Troubleshooting and Maintenance 8.1 Troubleshooting If your air-conditioning unit suffers from abnormal operation or failure, please first check the following points before repair: Failure Possible Reasons The power supply is not connected. ①...
  • Page 35 DC Inverter U-match Series Duct Type Unit otherwise it would cause discoloration and deformation of the unit. Do not wet the indoor unit in case of electric shock or fire hazard. ④ . Increase the frequency of cleaning if the unit is installed in a room where the air is extremely contaminated.(As a yardstick for yourself, consider cleaning the filter once a half year.) If dirt becomes impossible to clean, change the air filter.
  • Page 36 REGULATION (EU) No. 517/2014 - F-GAS The unit contains R410A, a fluorinated greenhouse gas with a global warming potential (GWP) of 2087.50. Do not release R410A into the atmosphere. AEG35PIH - Kg. 1,2 = 2,51 Tonn CO equiv. AEG50PIH - Kg. 1,4 = 2,92 Tonn CO equiv.
