- Page 1 Libretto Istruzioni Instruction Manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Stilo/3...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
• The extractor hood has been designed exclusively for domestic use to eliminate kitchen smells. • Never use the hood for purposes other than for which it has ben designed. • Never leave high naked flames under the hood when it is in operation. - Page 4 CHARACTERISTICS Dimensions Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Reducer Flange ø 150-120 mm 14.1 Air Outlet Connection Extension Air Outlet Connection Ref. Q.ty Installation Components 7.2.1...
-
Page 5: Installation
• Mark the wall at the centres of the holes in the bracket. • Place bracket 7.2.1 on the wall as shown at X mm below the first bracket (X = height of the upper chimney section supplied), aligning the centre (notch) with the vertical line. -
Page 6: Mounting The Hood Body
ø 150 or 120 mm, the choice of which is left to the installer. • Ensure that the activated charcoal filters have been inserted. ELECTRICAL CONNECTION • Connect the hood to the mains through a two-pole switch having a contact gap of at least 3 mm. -
Page 7: Flue Assembly
Switches the lighting system on and off. Motor running led. Motor Switches the extractor motor on and off at low speed. Used to provide a contin- uos and silent air change in the presence of light cooking vapours. Speed Medium speed, suitable for most operating conditions given the optimum treated air flox/noise level ratio. -
Page 8: Maintenance
• The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. • Remove the filters one at a time by pushing them towards the back of the group and pulling down at the same time. -
Page 9: Light Replacement
Lighting LIGHT REPLACEMENT 40 W incandescent light. • Remove the screw fixing the Lighting support. • Extract the lamp and replace with another of the same type. • Replace the lighting support. 20 W halogen light. • Remove the 2 Screws fixing the Lighting support, and pull it out of from the Hood. - Page 10 336/CEE on Electromagnetic Compatibility and Directive 93/68/CEE regarding CE Marking. Cet appareil est conforme à la norme européenne en matière de basse tension C.E.E. 73/23 de sécurité électrique ainsi qu’aux normes européennes : C.E.E. 89/336 en matière de compatibilité électromagnétique et C.E.E. 93/68 en matière de label CE.
