Auslock T11 User Manual

Smart dead lock
Hide thumbs Also See for T11:

Advertisement

Quick Links

Download this manual
User Manual
Smart Dead Lock
Special Attention:
1. Please keep override keys out side of premises just in case you need to use them.
(lock also has a power bank override on the front panel in case locks are inside)
2. Please replace batteries immediately once receiving any notification via lock or
app.
3. Read this manual carefully before installation, and keep it for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the T11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Auslock T11

Summary of Contents for Auslock T11

  • Page 1 User Manual Smart Dead Lock Special Attention: 1. Please keep override keys out side of premises just in case you need to use them. (lock also has a power bank override on the front panel in case locks are inside) 2.
  • Page 2 1. Introduction 1.1. Lock DimensionsD i m f s D D i m 1.2. In the box Please refer to the bellow list to see whether all the parts has come in the box. Name Name Front Panel Screw Stubs:M4*30mm Screw Stubs:M4*40mm Back Panel Mortise Screws:M4*25mm...

  • Page 3: Specifications

    1.3. Specifications Suitable for Doors Applicable Wooden door Models Materials Zinc Alloy 4x AA Batteries Batteries 2.0KG 35-90mm Lock Weight Door Thickness to Fit Bluetooth Fingerprint：200 Fingerprint Password Password：150 Ways to unlock Data Capacity Card Card：200 WI-FI (Requires Gateway) Mechanical key Silver/Black Temperature it -10℃-55℃...

  • Page 4: System Reset

    1.4. System Reset Open the cover of the battery. Then hold the "Reset" button as shown on the image for 5s. After that press “000#” on the touch pad to complete the system reset. Reset Button Tip: How to open the key cover? Push the edge on the top of the circular plate in for it to pop out.
  • Page 5 How to set Right direction How to set Left direction Please always keep the spindle horizontal. Please ensure that the bolt is inside when installing. Please ensure that the direction of the deadbolt is pointing in according to the direction of the door opening.

  • Page 6: Installation Diagram

    2.2. Installation Diagram Step 2: Screw in the casing as shown below then Step 1: Insert the deadbolt into the door connect the rubber to the back of the front panel. Connect the weather rubber to the back Step 3: Install the front panel Step 4: panel.

  • Page 7: Operation

    3.3. How to add a smart lock to the Auslock App? Auslock supports multiple types of Smart locks. To add a Auslock smart lock you must first select the large '+' sign as shown on image 1 below. Please select 'Door Lock' as shown on image 2. After that the lock should show on screen as shown on image 3.

  • Page 8: User Management

    3.4.3. Send e-Key The Auslock app allows you to send E-Keys ' ' to other users that also have a Auslock account. The E- Key allows the receiver to unlock/lock the smart lock via the app by tapping the ' ' icon as shown on image '2 - 3'.

  • Page 9: Add Fingerprint

    3.4.4. Add a RFID card RFID cards are another smart feature to access your home. You simply select the ' ' as shown in the image next to T11B this text. Upon selecting ' ' you will have the option to set up one the of the following: ...
  • Page 10 3.4.9. Gateway management(Optional) The Auslock smart lock uses Bluetooth to connect to the app. In order to operate the lock remotely using Internet you will need a Gateway. The gateway is a bridge that connects smart locks and the home WIFI network. The Gateway Bluetooth connects to the WI-FI router and to the smart lock (please ensure that the gateway is within 15m of open space to the router and the smart lock).
  • Page 11 4. FAQ 1) How to check who and when the smart In the Records page on the main page lock was used ? of the lock. Please refer to 3.4.8. 2) Why can’t I unlock my smart lock after The passage until you first unlock the smart lock using any of the registered smart features.
  • Page 12 Guarantee Please fill the details in the form below then email the form to admin@auslock.net within 30 days or else full services may not be offered. ： Customer Full Name ： Customer Contact No. ： Place of Purchase ： Purchase Date ：...
