Instructions of use and assembly
1. Unpack the product and the accessories, remove all packaging. Check the
content for completeness or damage caused by transportation. Keep children away
from the packaging.
2. Only place on a rigid surface of non-flammable material that can bear the weight
of the product.
The appliance weighs approx.20kg depending on the different product appearance
(NOT including the fuel).
3. Only install in a location which is protected against cross-aeration/air draft.
4. Carefully read the warnings in the manual as well as the warning on the product if
any.
5. If something is broken or damaged, do not use the appliance and return the
appliance to the retail er immediately.
6. Follow the steps below to install the tipping restraint strip.
NOTE: This tipping restraint strip is pre-assembled with fireplace, it must be
attached to wall stud using the screw provided.
(1) Measure the fireplace height from the floor using a tape measure. Measure
additional 2.5~5cm height above the fireplace height, mark on the wall where the
fireplace will stand against with a pencil. At the marked location on the wall, drill the
appropriate holes for the anchors provided and gently punch the anchors into the
wall using a hammer. Attach the bracket to the wall with screw (M4x40) using
Phillips screwdriver and tighten clockwise (see Figure 1).
(2) Place the fireplace into position so both mounting brackets are vertical in line.
NOTE: two adults are required to move the fireplace.
Figure 1
(3) Flip the lock on the tipping restraint strip, pull out the strip completely (see
Figure 2).
(4) Lace the strip through the hole of bracket mounted on the wall, bring both ends
together and draw it through until all slack is removed (see Figure 3).
(5) Confirm that the strip is securely laced and locked.
Figure 2
Tipping
restraint strip
Figure 3
Lock
Anchor
4
Bracket
Screw (M4x40)
Wall stud
Tipping
restraint strip
