User Manual RANGE HOOD | VETRO 90 PROFESSIONALE 1. ADVICE AND SUGGESTIONS ..............3 2. SCHEMATIC DESIGN OF THE PRODUCT ..........5 3. INSTALLATION ..................... 5 4. CIRCUIT CONTROLS AND SCHEMES ............8 5. CIRCUIT DIAGRAM ..................9 6. MAINTENANCE .................... 9 7. -
Page 3: Advice And Suggestions
User Manual RANGE HOOD | VETRO 90 PROFESSIONALE ADVICE AND SUGGESTIONS Instructions for use apply to various models of this appliance. Therefore, you can find descriptions of individual characteristics that do not belong to your particular device. The manufacturer is not liable for damage caused by installation or improper use. - Page 4 User Manual RANGE HOOD | VETRO 90 PROFESSIONALE The fat extractor is designed exclusively for domestic use, to eliminate odors from the kitchen. • Never use the extractor for purposes other than those for which it was designed. • Never leave high flame under the extractor when it is in operation.
-
Page 5: Schematic Design Of The Product
User Manual RANGE HOOD | VETRO 90 PROFESSIONALE SCHEMATIC DESIGN OF THE PRODUCT INSTALLATION • Installation position The grease extractor should be installed by centering it on the cooking surface. The reference distance between the extractor and the cooking surface is 30”=75cm •... - Page 6 User Manual RANGE HOOD | VETRO 90 PROFESSIONALE Fixing the suspension hook. Drill into the wall 3 holes of 8mm and depth 50mm and insert into the holes three expansion plugs. Use 3 ST5x50 screws to attach the suspension hook to the wall...
- Page 7 User Manual RANGE HOOD | VETRO 90 PROFESSIONALE • Installation of the chimney Installation of the lower chimney Use 2 M4x10 screws to secure the lower chimney to flange B, and then use 2 M4x10 screws to secure the lower chimney to the wall mounted extractor.
-
Page 8: Circuit Controls And Schemes
User Manual RANGE HOOD | VETRO 90 PROFESSIONALE CIRCUIT CONTROLS AND SCHEMES Using the electronic controls... -
Page 9: Circuit Diagram
User Manual RANGE HOOD | VETRO 90 PROFESSIONALE CIRCUIT DIAGRAM MAINTENANCE To ensure the best performance and durability of the fat extractor, regular maintenance is required. Note: Disconnect the power cord before any maintenance operation and press the "on / off"... -
Page 10: Troubleshooting
User Manual RANGE HOOD | VETRO 90 PROFESSIONALE TROUBLESHOOTING Issue Cause Solution The indicator light is on The rotor is clogged. Remove the cause of the but not, but the engine obstruction. does not work. The capacitor is Replace condenser. - Page 11 User Manual RANGE HOOD | VETRO 90 PROFESSIONALE appliances having a single air outlet in the room). There is a fire hazard if cleaning is not performed according to the instructions, do not flambé under the grease remover. • WARNING: accessible parts can become very hot during the use of cooking...
