Summary of Contents for RAB Lighting SMARTBULLET SMSBULLET2X12NW
- Page 1 SMARTBULLET SMSBULLET2X12 Installation Manual...
- Page 2 Contents: SMSBULLET2X12 Wire Nuts (3) Adjustment Lens Mask Tool Sensor Specifications: Relay On/Off Model: Built for Severe Conditions: 500 Watts Incandescent Double weatherproofing for long life. 100 Watts Fluorescent at 120 Volts Photoelectric Control: 500W LED BULLET12 at 120 Volts Deactivates lights during daylight.
- Page 3 Why RAB Sensors are BEST for You? Smaller is better! Mini Sensor uses state-of-the-art surface mount technology (SMT), just like cellular phones and beepers. SMT gives you more reliability, greater RF immunity, and a compact sensor that can fit neatly where others cannot. Wider is better! The wide 180º...
- Page 4 Caution Assembly and Wiring • All wiring MUST comply with local electrical codes and should be installed by qualified electrician. • Read entire Installation Manual before proceeding. TURN OFF POWER BY REMOVING Two BULLET12 heads come pre-wired POWER FUSE OR TURNING OFF CIRCUIT and assembled along with SMS500 BREAKER BEFORE INSTALLATION.
- Page 5 Mounting Junction Box (not supplied). Screws CU4 Plate Gasket Plug Center Screw Finishing Universal Hanging Metal Mounting Hook Surface O-Ring Gasket Plate Attach the Universal Mounting Bar with the screws provided to the Junction Box. In case of surface mount junction box, use with the Metal Surface Plate. For proper weatherproof seal, apply weatherproof silicone sealant around the edge of the Junction Box.
- Page 6 Wiring Diagrams To override sensor with a manual switch To switch more than rated load Multiple sensors: Wiring more than one sensor together is recommended only for the experienced installer because it becomes difficult to troubleshoot. Single sensors that control their own lights pinpoint movement more accurately and operate better.
- Page 7 How Does RAB’s Mini Sensor Work? How are the Time, Sensitivity and The Mini Sensor infrared sensor “sees” Photocell adjusted? small temperature changes caused by the motion of people or cars within TimeControl: Sets the time that lights its detection zone and turns on lights will remain on after the Detection Zone automatically.
- Page 8 Picking A Location Location Considerations: Detection Pattern: • Choose a location from which the • The sensor has a “Double Look Down” sensor can “see” all the paths of Lens with one “Look Out” zone and movement that will be illuminated by two “Look Down”...
- Page 9 Aiming and Walk Testing Test Period: 3. To reduce range, use the lens masks provided or tilt sensor down.Repeat The sensor has a 3 minute Test Period steps #2 and #3 until you are satisfied which allows it to be aimed and walk with the coverage.
- Page 10 Technical Tips: Lights Do Not Turn Off 1. Make sure sensor is not aimed at Problem: Passing cars activate sensor. something that would move or change temperature such as waving branches, water, air conditioners, windows or heating vents - even on neighboring property.
- Page 11 Technical Tips: Range appears limited 1. Check that the sensor is level from 4. Check that movement is not directly side to side and pointed at the area towards sensor. Sensor will see you desire. If unit is tilted, part of the movement across its pattern more Detection Zone may be high in the air quickly.
- Page 12 Technical Tips: Lights Turn Off Lights Do Not Turn On Too Quickly 1. Check that lamps and fixtures work. 1. Check if sensor is being “tricked” by Compare wiring to the Wiring reflected light. If lights shine or reflect Diagram in this manual. Check that into the photocell, (located behind the the power is on.
- Page 13 Technical Tips: Lights Turn On and Off Incorrectly 5.Make sure lights are not visible from or 1. Make sure the sensor is installed reflecting back into sensor. Check for on its own dedicated circuit free of white or reflective surfaces close to the motor loads such as HVAC equipment, kitchen appliances or garage door sensor.
- Page 14 12 &13. your sensor (freight prepaid and insured) directly to us (at RAB Lighting Inc. 170 Ludlow Ave. Northvale, NJ 07647) with a check for $50.00 made payable to RAB Lighting Inc. We...
- Page 15 RAB Lighting Product Warranties The following warranties apply to RAB Lighting, Inc. (“RAB”) York and buyer agrees that such courts are a convenient products that meet all of the following conditions: (a) the forum for adjudication. In the event that suit is necessary...
- Page 16 Easy Installation & Product Help Tech Help Line rabweb.com email ©2014 RAB LIGHTING Inc. Call our experts 888 RAB-1000 Visit our website for product info Answered promptly sales@rabweb.com Northvale, New Jersey 07647 USA SMSBULLET2X12-IN-0314...
