AVGear AVG-PRO44-150 KIT User Manual

18gbps 4x4 hdbaset matrix (150m)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AVG-PRO44-150 KIT
18Gbps 4x4 HDBaseT
Matrix (150m)
All Rights Reserved
Version: AVG-PRO44-150 KIT_2024V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVG-PRO44-150 KIT and is the answer not in the manual?

Questions and answers

Related Manuals for AVGear AVG-PRO44-150 KIT

Summary of Contents for AVGear AVG-PRO44-150 KIT

  • Page 1 AVG-PRO44-150 KIT 18Gbps 4x4 HDBaseT Matrix (150m) All Rights Reserved Version: AVG-PRO44-150 KIT_2024V1.0...
  • Page 2 AVG-PRO44-150 KIT PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operational instruction only, and not to be used for maintenance. The functions described in this version are current as at April 2024. Any changes of functions and operation- al parameters will be updated in future manual versions.
  • Page 3 AVG-PRO44-150 KIT SAFETY OPERATION GUIDE To guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: The system must be earthed properly. Please do not use two blade plugs and ensure the alternating power supply ranges from 100v to 240v and from 50Hz to 60Hz.

  • Page 4: Table Of Contents

    AVG-PRO44-150 KIT Table of Contents 1. Introduction........................1 2. Features........................... 1 3. Package Contents......................2 4. Specifications........................2 5. Operation Controls and Functions................4 5.1. Matrix Panel......................4 5.2. HDBaseT Receiver Panel..................6 6.

  • Page 5: Introduction

    AVG-PRO44-150 KIT 1. Introduction The 18Gbps 4x4 HDBaseT(150M) Matrix can connect four HDMI sources to eight displays. It features four HDMI outputs and each HDMI output is mirrored to provide a CAT-Cable output which runs simultaneously. HDBaseT output can extend video transmission distance up to 492ft / 150m via a single Cat 5e/6/7 cable and the resolution is up to 4K2K@60Hz 4:4:4.

  • Page 6: Package Contents

    AVG-PRO44-150 KIT 3. Package Contents ① 1 × 18Gbps 4x4 HDBaseT(150M) Matrix ② 4 × HDBaseT Receiver ③ 1 × Matrix IR Remote ④ 1 × 100~240V AC 50/60Hz Power cable ⑤ 1 × RS-232 serial cable (1.5 meters, male to female head) ⑥...
  • Page 7 AVG-PRO44-150 KIT Connection Inputs: 4 × HDMI Type A [19-pin female] Outputs: 4 × HDMI Type A [19-pin female] 4 × HDBaseT port [RJ45] 4 × Coaxial audio [3.5mm Stereo Mini-jack] 4 × balanced analog audio [5-pin Phoenix Matrix connector] Controls: 5 ×...

  • Page 8: Operation Controls And Functions

    AVG-PRO44-150 KIT 5. Operation Controls and Functions 5.1 Matrix Panel Front Panel MENU POWER OUTPUT INPUT ENTER DOWN LOCK Name Function Description Display matrix switching status, input / output port, EDID, Baud rate, OLED screen IP Address. The LED will illuminate in green when the product is working normally, and Power LED red when the product is on standby.
  • Page 9 AVG-PRO44-150 KIT Rear Panel AUDIO OUT IR IN ALL IR OUT COAX 1 COAX 2 COAX 3 COAX 4 OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 TCP/IP RS-232 100-240V AC 50/60HZ INPUT HDMI HDBT HDMI HDBT HDMI HDBT HDMI...

  • Page 10: Hdbaset Receiver Panel

    AVG-PRO44-150 KIT 5.2 HDBaseT Receiver Panel SERVICE HDMI OUT AUDIO OUT IR IN IR OUT 5 4 6 Name Function Description Power LED Red LED will be on when the receiver is powered on. SERVICE port Firmware update port. DC 24V/1A power supply input port.

  • Page 11: Ir Remote

    AVG-PRO44-150 KIT 6. IR Remote ① Power on or Standby: Power on the Matrix or set it to standby mode. ② Output 1: Press 1\2\3\4 button to select input source to HDMI OUTPUT 1. ③ Output 2: Press 1\2\3\4 button to select input source to HDMI OUTPUT 2.

  • Page 12: Ir Control System

    AVG-PRO44-150 KIT 7. IR Control System The product is not only a matrix switch but also an extender. It supports bi-directional IR control. When Matrix is connected to HDBaseT Receiver through Cat 5e/6/7 cable, you can control remote display device (HDBaseT) or input source device (Matrix) through IR signal transmission.
  • Page 13 AVG-PRO44-150 KIT At HDBaseT receiver (Remote end): IR signal follows video switch to change. For example, the HDMI output signal on the HDBaseT Receiver 1 is from the HDMI INPUT 2 port, so IR input signal of the HDBaseT Receiver 1 will emit to IR OUT 2 port of the Matrix. The HDMI output signal on the HDBaseT Receiver 3 is from the HDMI INPUT 4 port.

  • Page 14: Ir Cable Pin Assignment

    AVG-PRO44-150 KIT 8. IR Cable Pin Assignment IR BLASTER IR RECEIVER 9. EDID Management This Matrix has 21 factory defined EDID settings, 2 user-defined EDID modes and 8 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through on-panel button, RS-232 control or Web GUI.
  • Page 15 AVG-PRO44-150 KIT The defined EDID setting list of the product is shown as below: EDID Mode EDID Description 1080p, Stereo Audio 2.0 1080p, Dolby/DTS 5.1 1080p, HD Audio 7.1 1080i, Stereo Audio 2.0 1080i, Dolby/DTS 5.1 1080i, HD Audio 7.1 3D, Stereo Audio 2.0...

  • Page 16: Web Gui User Guide

    AVG-PRO44-150 KIT 10. Web GUI User Guide The Matrix can be controlled by Web GUI. The operation method is shown as below: Step 1: Get the current IP Address. The default IP address is 192.168.1.100. You can get the current Matrix IP address in two ways: The first way: You can get the IP address via panel buttons.
  • Page 17 AVG-PRO44-150 KIT After entering the Web GUI page, there will be a Login page, as shown below: Select the Username from the list and enter the password. The default passwords are: Username User Admin Password user admin After entering the password, click the “LOGIN” button and the following Status page will appear.
  • Page 18 AVG-PRO44-150 KIT ■ Video Page You can do the following operations on the Video page: ① Output: The current device’s OUTPUT port. You can select signal source for it. ② Input: You can click the drop-down menu to select signal source for the corresponding OUTPUT port .
  • Page 19 AVG-PRO44-150 KIT Set EDID for the User Click the “Browse” button, then select the bin file. If you select the wrong EDID file, there will be a prompt, as shown in the following figure: Make sure to select the correct file, then you can check the name of the selected file. Select “User 1”...
  • Page 20 AVG-PRO44-150 KIT ■ CEC Page You can perform CEC management on this page: ① Input Control: You can control the operation of each input source by pressing the icons on the page. (You can control multiple inputs simultaneously.) ② Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching.
  • Page 21 AVG-PRO44-150 KIT Click “OK” to search the IP Address again, as shown in the following figure: After searching is completed, it will switch to the login page, the default network setting is completed. Modify User Password Click the “User” button, enter the correct Old Password, New Password, and Confirm Password, then click “Save”.
  • Page 22 AVG-PRO44-150 KIT Modify Network Setting Modify the Mode/IP Address/Gateway/Subnet Mask/Telnet Port as required, click “Save” to save the settings, then it will come into effect. After modification, if the Mode is “Static”, it will switch to the corresponding IP Address;...

  • Page 23: Rs-232 Control Command

    AVG-PRO44-150 KIT 11. RS-232 Control Command The product also supports RS-232 control. You need a serial cable with RS-232 male head and DB9 transfer USB male head. The RS-232 head of the serial cable is connected to the RS-232 control port with DB 9 at the rear of the Matrix, and the USB head of the serial cable is connected to a PC.
  • Page 24 AVG-PRO44-150 KIT Default Setting Example Command Code Function Description Feedback Get the connection status of the r link in x! r link in 1! hdmi input 1: connect x input port，x=0~4(0=all) Get the connection status of the hdmi output 1: connect...
  • Page 25 AVG-PRO44-150 KIT Default Setting Command Code Function Description Example Feedback enable hdbt output 1 stream Set hdbt output y stream on/off, s hdbt 1 stream 1! disable hdbt output 1 stream y=0~4(0=all) s hdbt y stream z! enable s hdbt 0 stream 1!
  • Page 26 AVG-PRO44-150 KIT Function Description Example Default Setting Feedback Command Code Get the EDID data of the hdmi r edid data hdmi 1! EDID: 00 FF FF FF FF r edid data hdmi y! FF FF 00 ……… output y port，y=1~4...
  • Page 27 AVG-PRO44-150 KIT Command Code Example Function Description Feedback Default Setting Network Setting IP Mode: Static IP: 192.168.1.72 Subnet Mask: 255.255.255.0 r ipconfig! Get the Current IP Configuration r ipconfig! Gateway: 192.168.1.1 TCP/IP port=8000 Telnet port=10 Mac address: 00:1C:91:03:80:01 Mac address:...
  • Page 28 AVG-PRO44-150 KIT Example Command Code Function Description Feedback Default Setting Network reboot… IP Mode: Static IP: 192.168.1.72 Subnet Mask: 255.255.255.0 s net reboot! Reboot network modules s net reboot! Gateway: 192.168.1.1 TCP/IP port=8000 Telnet port=10 Mac address: 00:1C:91:03:80:01 Set the data length of x hdbt uart,...

  • Page 29: Application Example

    AVG-PRO44-150 KIT 12. Application Example Amplifier 2.0 Speakers Power Supply AUDIO OUT IR IN ALL IR OUT COAX 1 COAX 2 COAX 3 COAX 4 OUTPUT 3 OUTPUT 1 OUTPUT 2 OUTPUT 4 TCP/IP RS-232 100-240V AC 50/60HZ HDMI HDBT...
