AVGear AVG-UHMS66PRO User Manual

4k hdbaset 6x6 matrix swither
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AVG-UHMS66PRO
The AVG-UHMS66PRO 4K HDBaseT 6x6
Matrix Switcher is a professional 6x6
HDBaseT Matrix Switcher that accommodates
6 HDMI IN (HDMI 1.4 & HDCP 2.2 compliant)
& 6 IR IN.
Features
6 HDMI Inputs supporting HDMI 1.4 &
HDCP 2.2, and compliant with lower
standards, able to transmit 4Kx2K@60Hz
& 1080p 3D
Supports manual input HDCP auto-
detection and manual output HDCP
management
3 HDMI Outputs supporting HDMI 1.4 &
HDCP 1.4, transmits 4Kx2K signal for 8m
6 HDBaseT outputs for easy extension
up to 70m at 1080p and 40m at 4Kx2K
over single CAT5e/6 cable, supports PoC
LCD screen shows real-time I/O
connection status, switching status,
HDCP status, and output resolution.
Controllable via front panel, TCP/IP, and
bi-directional IR & RS232
Built-in GUI for TCP/IP control
Powerful EDID management
Supports memory off function for reliable
operation
Convenient firmware upgrades through
Micro USB port
Easy installation with rack-mounting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVG-UHMS66PRO and is the answer not in the manual?

Questions and answers

Related Manuals for AVGear AVG-UHMS66PRO

Summary of Contents for AVGear AVG-UHMS66PRO

  • Page 1 70m at 1080p and 40m at 4Kx2K over single CAT5e/6 cable, supports PoC LCD screen shows real-time I/O connection status, switching status, The AVG-UHMS66PRO 4K HDBaseT 6x6 HDCP status, and output resolution. Matrix Switcher is a professional 6x6 Controllable via front panel, TCP/IP, and HDBaseT Matrix Switcher that accommodates bi-directional IR &...
  • Page 2 AVG-UHMS66PRO PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is for operation instruction only, and not to be used in a maintenance capacity. The functions described in this version are current as at November 2015. Any changes of functions and operational parameters will be updated in future manual versions.
  • Page 3 AVG-UHMS66PRO SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.

  • Page 4: Table Of Contents

    Introduction ......................1 Introduction to the AVG-UHMS66PRO ............1.1 Features ....................... 1.2 What’s in the Box ..……………………………………………………………………2 Product Appearance of the AVG-UHMS66PRO ............. 3 Front Panel ....................3.1 Rear Panel ....................3.2 System Connection ....................4 System Applications ..................4.1 Usage Precautions ..................

  • Page 5: Introduction

    AVG-UHMS66PRO 1. Introduction 1.1. Introduction to the AVG-UHMS66PRO The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher is a professional 6x6 HDBaseT Matrix Switcher that accommodates 6 HDMI IN (HDMI 1.4 & HDCP 2.2 compliant) & 6 IR IN. Select HDMI inputs using front panel buttons, IR, RS232, or GUI. The selected source is delivered to HDMI Output 1~3 (switched synchronously with HDBaseT output 1~3) &...
  • Page 6 AVG-UHMS66PRO 2. Package List 1 x AVG-UHMS66PRO HDBaseT 6x6 Matrix Switcher 1 x RS232 cable 4 x Rubber Feet (4 x Screws) 1 x Power cord 2 x Mounting ears (6 x Screws) 1 x IR Receiver 1 x IR remote...

  • Page 7: Product Appearance Of The Avg-Uhms66Pro

    AVG-UHMS66PRO 3. Product Appearance of the AVG-UHMS66PRO 3.1. Front Panel Name Description Firmware Micro USB port for firmware updating ① Power Illuminates red when power is on, yellow when in standby ② Indicator mode In-built IR sensor, receives IR signals sent from IR remote.
  • Page 8 AVG-UHMS66PRO ENTER: Confirm operation Press for 3 seconds to enter into Query mode. Note: Pictures shown in this manual are for reference only.

  • Page 9: Rear Panel

    AVG-UHMS66PRO 3.2. Rear Panel Description Name a. IR OUT: connect with IR emitters, making up an IR matrix with the IR IN sockets on the far-end receivers. IR signal can be switched synchronously with the AV signal, or separately. ①...
  • Page 10 AVG-UHMS66PRO TCP/IP TCP/IP port for unit control ⑤ GROUND Connect to ground ⑥ Power: Press the button to power on/off the matrix. The ⑦ Power indicator turns red when power on. Power port: Insert AC 100V~240V power adapter here. Note: Pictures shown in this manual are for reference only.

  • Page 11: System Connection

    AVG-UHMS66PRO 4. System Connection 4.1. System Applications Reliable performance for control and transmission makes the AVG-UHMS66PRO ideal in the IT computer realm, signal monitoring, big screen displays, conference systems, television broadcast, education, banking and security institutions etc. 4.2. Usage Precautions 1.

  • Page 12: Connection Procedure

    Note: IR receivers connected to IR IN should have a modulator carrier. If not, send command %0900. or %0901.to activate native carrier mode or force carrier mode in the IR matrix to launch between the AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher and far-end receivers.

  • Page 13: Connection With Hdbt Receiver

    AVG-UHMS66PRO 4.5. Connection with HDBT Receiver The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher boasts 6 HDBaseT output ports which support PoC solution, through which AV signal, IR & RS232 control signals, as well as power are transmitted on single CAT5e/6.

  • Page 14: System Operation

    AVG-UHMS66PRO 5. System Operation 5.1. Front Panel Button Control Introduction to the system operations. 5.1.1. Switching I/O connection 1. To route one input to an output: Operation: “input”+“output”+“ENTER” Example: input 1 to output 2 Note: In default status, the 6 IR OUT sockets correspond with the 6 HDMI INPUTS.

  • Page 15: Edid Management

    AVG-UHMS66PRO 5.1.2. EDID Management The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher features EDID management to maintain compatibility between all devices. It can be controlled via EDID learning and EDID invoking. EDID Learning (from output): One input port learns the EDID data of one output port Operation: Press “EDID”, “INPUTS”+“OUTPUTS”+“ENTER”.

  • Page 16: Query

    AVG-UHMS66PRO Format: Press and hold “EDID” for 3 seconds, “INPUTS”+“OUTPUTS”+“ENTER”. Operations: Set EDID data for one input Operation: Press “EDID” (hold for 3 seconds to enter in EDID setting status), “INPUTS”+“OUTPUTS”+“ENTER”. Example: Set the EDID data of INPUT 4 to the forth type of embedded EDID data:...

  • Page 17: Clear Operation

    1~3 have HDMI outputs also. Note: With this IR remote, the AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher can be controlled by the built-in IR, the extended IR receiver connected to the “IR EYE”/”IR ALL IN” or an IR receiver on the far-end receiver balun.

  • Page 18: Controlling A Far-End Device Locally

    AVG-UHMS66PRO 5.2.2. Controlling a Far-end Device locally Connect an IR receiver to IR IN/ IR ALL IN on the switcher, and use the IR Remote of far-end device to control the device locally. 1 to 1: (through IR IN) Connect an IR receiver with carrier to the IR IN port of 4K HDBaseT 6x6 Matrix Switcher, users can control a far-end output display via its IR remote locally.

  • Page 19: Control A Local Device Remotely

    AVG-UHMS66PRO Note: Send command “%0901.” to enter infrared carrier enforcing mode if the IR Receiver connected to the IR ALL IN does not have carrier. 5.2.3. Control a Local Device Remotely Connect IR receiver(s) to IR IN on far-end HDBT receiver(s), and IR Emitter(s) to IR OUT port of the switcher, and use the IR Remote of the local source to control the device remotely.
  • Page 20 AVG-UHMS66PRO Multiple to Multiple: (IR Matrix) The 6 “IR OUT” ports and the 6 “IR IN” ports on the far-end receivers make up an 6x6 IR matrix. IR Transmitter IR OUT IR OUT IR OUT IR IN IR IN IR IN...

  • Page 21: Rs232 Control

    AVG-UHMS66PRO 5.3. RS232 Control 5.3.1. Connection with the RS232 Communication Port The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher boasts a 3-pin pluggable terminal block for serial control. The pins definition is listed in the table below. Function Unused Transmit Receive...

  • Page 22: Control Through The 3-Pin Rs232 Port

    HDMI OUT IR IN IR OUT RS23 2 Control the AVG-UHMS66PRO remotely Connect the RS232 (3-pin pluggable terminal block) port in any zone to controlled device (3rd party device), and connect PC to the corresponding (same zone as controlled device) receiver.

  • Page 23: Installation/Removal Of The Rs232 Control Software

    Removal Delete all the control software files in corresponding file path. 5.3.5. Basic Settings Firstly, connect the AVG-UHMS66PRO with an input device and an output device. Then, connect it with a computer which is installed with RS232 control software. Double-click the software icon to run the software.

  • Page 24: Rs232 Communication Commands

    AVG-UHMS66PRO 5.3.6. RS232 Communication Commands Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Command Function Feedback Example System Commands /*Type; Query the models information. UHMS66PRO Lock the front panel buttons on the /%Lock; System Locked! Matrix.
  • Page 25 AVG-UHMS66PRO Command Function Feedback Example Transfer signals from the input channel [x]All. X To All. (X=1~6) [x] to all output channels Transfer input signals All#. corresponding output channels All Through. respectively like 1->1, 2->2… All$. Switch off all the output channels.
  • Page 26 AVG-UHMS66PRO Command Function Feedback Example Recall From Recall[Y]. Recall the preset command [Y]. (Y=0-9) Clear FY (Y=0- Clear[Y]. Clear the preset command [Y]. PWON. Work in normal mode. PWON Enter into standby mode and cut off the PWOFF. PWOFF power supply to HDBaseT receivers.
  • Page 27 AVG-UHMS66PRO Command Function Feedback Example Set communication between a PC and HDBaseT receiver. Y is for RS232 port (connect with RS232 port of HDBaseT receiver) a. Y = 1~6, send this command to the corresponding HDBaseT receiver to control far-end device.
  • Page 28 AVG-UHMS66PRO Command Function Feedback Example Upgrade EDID data via the RS232 port. [x] is the input port, when the value of X is 9, it will upgrade all the input ports. When switcher receives Please send EDIDUpgrade[x]. command, it will show a message to EDID file prompt you to send the EDID file (.bin...
  • Page 29 AVG-UHMS66PRO Command Function Feedback Example Check the command sent by port 1 Port 1:data when %9951. when PWON. PWON Check the command sent by port 2 Port 2:data when %9952. when PWON. PWON Check the command sent by port 3 Port 3:data when %9953.
  • Page 30 AVG-UHMS66PRO Command Function Feedback Example 1 2 3 4 Check the connection status of the Connect N Y Y Y %9971. inputs. Connect N Y 1 2 3 4 Check the connection status of the Connect N Y Y Y %9972.

  • Page 31: Tcp/Ip Control

    2 devices, users are able to control the device via web-based GUI or purpose designed TCP/IP communication software. 5.4.1. Control Modes The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher can be controlled by PC without Ethernet access or PC(s) within a LAN. Controlled by PC without Ethernet access Connect a computer to the TCP/IP port of the 4K HDBaseT 6x6 Matrix Switcher, and set its network subnet to the same as the 4K HDBaseT 6x6 Matrix Switcher’s.
  • Page 32 PCs to setup a LAN (as shown in the following figure). Set the network segment of the AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher to the same as the router’s, then PCs within the LAN are able to control 4K HDBaseT 6x6 Matrix Switcher.

  • Page 33: Control Via Tcp/Ip Communication Software

    AVG-UHMS66PRO 5.4.2. Control via TCP/IP Communication Software 1. Connect a computer and a 4K HDBaseT 6x6 Matrix Switcher to the same network. Open the TCPUDP software (or any other TCP/IP communication software) and create a connection, enter the IP address and port of the 4K HDBaseT 6x6 Matrix Switcher (default IP: 192.168.0.178, port:8080):...

  • Page 34: Gui For Tcp/Ip Control

    AVG-UHMS66PRO 5.4.3. GUI for TCP/IP Control The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher has a built-in GUI for convenient TCP/IP control. The GUI allows users to interact with 4K HDBaseT 6x6 Matrix Switcher through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in interface as shown as below: There are 2 types of accounts to log in to.
  • Page 35 AVG-UHMS66PRO The button matrix displays every possible connection between every input and output, users can control the connections by clicking corresponding button. Buttons 1~9 at the right-bottom corner provides quick saving and recall for overall connection status.
  • Page 36 AVG-UHMS66PRO Users: Display or modify credential settings, front panel lock, and GUI version. If there is any modification, press Save to store the settings, or press Cancel to go back. Interface: Set title bar label, LCD readout, and button labels, press Save to save the...
  • Page 37 AVG-UHMS66PRO Configuration: Set HDCP Compliance status for every input, and manage EDID. See the screenshot below: Network: Query and configure network settings including MAC address, IP address, subnet mask, and Gateway. Note: Log in as user to access main interface.

  • Page 38: Port Management

    -> Start upgrading. Reboot the device after upgrading. 5.5. Firmware Update via USB Firmware Update via USB The AVG-UHMS66PRO 4K HDBaseT 6x6 Matrix Switcher boasts a USB port for online firmware upgrade on the front panel. Follow these steps to upgrade the firmware: Step 1.
  • Page 39 AVG-UHMS66PRO The upgrade interface will be shown as below: Step 4. Click Connect USB. Step 5. Click Open to load the upgrade file, then click Update to start firmware upgrading. Note: To ensure control is possible, the COM number of the PC should be 1~9.

  • Page 40: Specification

    AVG-UHMS66PRO 6. Specifications Video Input Video Output 3 HDMI Input 6 HDMI Output 6 HDBaseT Female HDMI Input Output Female HDMI Female RJ45 (with LED Connector Connector indicators) T.M.D.S. Input Level Output Level T.M.D.S. 2.9V~3.3V 2.9V~3.3V Output 100Ω ( Differential)
  • Page 41 AVG-UHMS66PRO Control 6 IR OUT (green and red) 6 IR IN (black) 1 IR EYE (black) 1 IR ALL IN (black) Control Panel Front panel buttons 1 TCP/IP (female Ports Control RJ45) 1 RS232 (9 pin female) 6 RS232s (3-pin...

  • Page 42: Panel Drawing

    AVG-UHMS66PRO 7. Panel Drawing...

  • Page 43: Troubleshooting & Maintenance

    AVG-UHMS66PRO 8. Troubleshooting & Maintenance Problems Causes Solutions The Connection of the Check whether the cables cabling may be incorrect are connected correctly Color loss or no video or faulty and in working condition. signal output Make sure the connection...
  • Page 44 AVG-UHMS66PRO Problems Causes Solutions Check to ensure correct Wrong connection connection between the control device and the unit Type in correct RS232 Cannot control the device Wrong RS232 communication with control system (e.g. a communication parameters: Baud PC) through the RS232 parameters rate:9600;...
