Dacor ILb10 Planning Manual

030106
IsomETrIC vIEw

ovErALL DImENsIoNs froNT vIEw

NOTE:
1. The ILB8 and ILB10 inline blowers are only
approved in updraft (hood) applications.
Model "A" Overall
No. Chassis Width Chassis Height
ILB8 10 5/8" (270mm) 10 1/2" (267mm)
ILB10 12 5/8" (321mm) 12 1/2" (318mm)
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
ILb8, ILb10

Inline remote blowers

"A"
"B"
Attachment
Surface
"C" Overall
"B" Overall Chassis
Length
5" (127mm)
Dedicated
"D" Duct Circuit
Diameter Required
8" (203mm)
Refer to
Ventilator

Specifications

10" (254mm)
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
1/1
Electrical
Access Panel
85829 P/N DACOR
AIRFLOW
ROTATION
"C"

ovErALL DImENsIoNs sIDE vIEw

ToP vIEw
Total
Maximum Connected
Duct Length Load
0.1kW (1A)
Max. 60
Equivalent
Straight Feet
0.2kW (2A)
GUIDE
"D"
Attachment
Surface
Approximate
Blower Shipping
Rating Weight
600 CFM 12 lbs.
1100
16 lbs.
CFM
9.5
