- Page 1 MODEL: S6132P- ES-XX Version: 1.5 INSTALLATION GUIDE PULL-DOWN KITCHEN SINK FAUCET MODEL FINISH S6132P-ES-SB Stainless Steel Brushed S6132P-ES-BN Brushed Nickel S6132P-ES-MB Matte Black S6132P-ES-BG Brushed Gold S6132P-ES-MG Matte Black and Gold HOT LINE: +1-866-203-0866...
-
Page 2: Before Proceeding
THANK YOU Dear Valued Customer, Thank you for choosing SUMERAIN products. We would like to take this opportunity to express our sincere gratitude for your recent purchase. We hope you are completely satisfied with your new product. Rest assured, we meticulously engineer all SUMERAIN products and put them through rigorous factory tests to ensure their prolonged, trouble-free use under normal conditions. -
Page 3: Limited Lifetime Consumer Warranty
LENGTH OF WARRANTY As stated in the following, any replacement or repaired parts of the product will be covered for the duration of this warranty, which SUMERAIN provides for a period of 1 year from the original date of purchase. -
Page 4: Functions & Specifications
FUNCTIONS & SPECIFICATIONS Kitchen Faucet Faucet Type Feature Pull-Down Kitchen Faucet Theme Modern ,Contemporary Stainless Steel Brushed/Brushed Nickel/Brushed Gold/Matte Black Finish Installation Holes Lever Handle Style Pullout Direction Down Pullout Spray Sensor Sprayer Mounting Type Single Hole Number Of Handles Ceramic Disc Valve Type Height... - Page 5 DIMENSION FRONT VIEW SIDE VIEW...
-
Page 6: Installation Steps
3. CHECK THE COMPONENTS OF THE BOX Upon opening the box, check to ensure that all the following items are included. If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com ITEM NAME MATERIAL PART NO. - Page 7 4. INSTALLATION HOLES INSPECTION Before installation, please ensure that the specifications of the faucet mounting hole on your sink and the thickness of the deck fall within the effective range shown in the diagram below. We recommend an optimal mounting hole diameter of 1-1/4 inches (32 mm) and a maximum deck thickness of 1.0 inches (25.5 mm).
- Page 8 5.2 To remove the mounting components from the faucet, hold it steady with one hand and twist the components counterclockwise with the other hand until they are detached. 5.3 Connect the red hose to the hot inlet and the blue hose to the cold inlet. Tighten by hand first, then use a wrench to secure them but don't over-tighten.
- Page 9 5.4 Place deck escutcheon over mounting holes of the deck and attach mounting hardware and tighten from below. Insert the sprayer hose connector into the outlet connector at the bottom of the faucet. Then, hold the weight and use a Phillips screwdriver to open the weight.
- Page 10 5.6 Connect the faucet's hot and cold water inlet hoses to their respective hot and cold water supply valves. Then, use a wrench to tighten the mounting nuts. 6. Spray Head Usage Guide The spray head features three water output modes: Stream Mode, Sheet Spray, and Shower Spray. There are two buttons on the spray head for toggling between these modes: (1) Circular Button: Located above the oval button.
- Page 11 Address: 1226 NORTH KING ST NUM 522 WILMINGTON, DE 19801 United States Tel: +1(866)203-0866 Web: http://www.sumerain.com E-mail: supports@sumerain.us HONGKONG SUMERAIN SANITARY INDUSTRY CO., LIMITED Address: FLAT/RM 3B 3/F BANK TOWER NOS.351&353 KING'S ROAD NORTH POINT Tel: +86-750-2731579 E-mail: supports@sumerain.com SUMERAIN EUROPE SUPPORT Address: Flottwellstr.
