- Page 1 MODEL: S3123XD-B Version: 1.2 Pressure Balanced Shower System with Digital Temperature Display MODEL FINISH S3123CD-B CHROME S3123ND-B BRUSHED NICEKL...
- Page 2 Dear Valued Customer, SUMERAIN would like to take this opportunity to thank you for purchasing SUMERAIN products. It is our sincere hope that you are completely satisfied with your new purchase. All SUMERAIN products are carefully engineered, and factory tested to provide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated instructions.
- Page 3 This warranty covers only your SUMERAIN manufactured product. SUMERAIN warrants this product against defects in material or workmanship as follows: SUMERAIN will repair at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance.
- Page 4 Faucet type Shower System Feature Digital Temperature Display, Concealed box Theme Modern, Contemporary Mounting type Wall mount Number of Handles Metal Handles Material Lever Handle style Shower Arm Reach 154mm [6-1/6 Inch] Showerhead Width 195mm [7-11/16 Inch] Showerhead Length 195mm [7-11/16 Inch] Valve Type Pressure Balance Valve...
- Page 5 FRONT VIEW OF SHOWER...
-
Page 7: Before Proceeding
1. BEFORE PROCEEDING WARNING: Read all the instructions completely before proceeding.SUMERAIN recommends calling a professional if you are uncertain about installing this product!, this product should be installed in accordance with all local and state plumbing and building codes. 2. SHUT OFF WATER SUPPLY Locate water supply inlets and shut off the water supply valves. - Page 8 B3123008 Screen washer 1 PCS If any of these items are missing, please contact SUMERAIN consumer service at +86-750-2731579 or email to: supports@sumerain.com 4. PLANNING AND INSTALLATION INSTRUCTIONS Attentions: The shower has to be installed, rinsed and checked in compliance with the applicable regulations in order to guarantee proper shower function! The dimensions of the shower set-up must be individually.
- Page 9 5. CONCEALED BOX ASSEMBLY INSTALLATION 5.1 Make a mounting rack (normally use woods as materials) for preparing install the concealed box assembly .the mounting board’s face should be Min 63mm[2-15/32"] and Max 85mm[3-11/32"] behind the finish wall surface.
- Page 10 Secure the concealed box assembly to the mounting rack with screws and anchor. 6. VALVE TRIM INSTALLATION 6.1 Turn on your shut-off valve for cleaning the hot and cold water supply pipe before connect to the valve body, allow the water flush 3~5 minutes to flush out dirt and debris.
- Page 11 6.2 Apply Teflon tape on the thread of pipe inlet and then connect to valve inlet with elbow [hot left, cold right]. Mixer Valve Connecting thread for Hot&Cold water inlet: G1/2” [1/2 BSPP], US, CA customers may require NPT cover to BSPP adapter for connecting.
- Page 12 6.3 Remove the valve sleeve by Phillips screwdriver. Turn on hold and cold water supply and check all connection for leaks Please shut off your hot and cold water supply again if no leaking. 6.4 Drill the mounting holes exactly according to mixer valve and elbow position, done the finish wall. Cut the plaster shield around the finish wall surface and seal the wall around the plaster shield with waterproof sealant WARNING: Failure to seal the wall can lead to possible water damage.
- Page 13 6.5 Remove the valve sleeve by Phillips screwdriver and hold the screw for next step (fastening battery box).
- Page 14 6.6 Attach the battery to the concealed box and fasten with screw. 6.7 Connect the battery’s power wire to the circuit board for power supplying.
- Page 15 6.8 Connect and secure the temperature sensor’s data wire to the circuit board for inspecting mixing water’s temperature. The LCD display module starts to running and display current temperature of valve body, If Error code display, please referring to below error code define or contact SUMERAIN service support center supports@sumerain.com Error code “E10”...
- Page 16 6.10 Battery charging inspects. Please make sure the charging sign (3) active on LCD screen when connect to AC/DC USB recharger which have been plugged. LCD SCREEN DEFINED...
- Page 17 6.11 Take off the escutcheon and the temperature limit ring. 6.12 Turn on and adjusting the cartridge to achieve desired shower water’s maximum temperature.
- Page 18 6.13 Attach the temperature limit ring to cartridge for locking the maximum temperature. Attach the escutcheon to the bonnet too. 6.14 Seal the wall around the plaster shield with waterproof sealant...
- Page 19 6.15 Attach handle onto the valve stem and tighten set screws by the Allen wrench that is provided. Please don’t over tighten. Done the same procedure on diverter knob. Finally press-in the screw cover. 6.16 Valve trim install finish.
-
Page 20: Showerhead Installation
7. SHOWERHEAD INSTALLATION 7.1 Attach Shower arm escutcheon to the shower arm and apply Teflon tape on the thread of shower arm, Secure the shower arm into the pipe elbow inside the wall by rotating clockwise. US, CA customers may require NPT cover to BSPP adapter for connecting. - Page 21 7.2 Put the screen washer into the connector of showerhead and secure the showerhead on the shower head arm by hand rotating anticlockwise. Missing the screen washer might lead to shower invalid. 8. HAND SHOWER INSTALLATION 8.1 Apply Teflon tape on the thread of elbow and insert the thread through elbow escutcheon. Screw the thread into the pipe elbow inside the wall.
- Page 22 8.2. Connect the hand shower to the elbow with flexible hose.
-
Page 23: Function Inspection
9. INSPECTION 9.1 Turn on hold and cold water supply and check all connection for ensuring no leaking anywhere. 10. FUNCTION INSPECTION 10.1 Turn on the handle, the water outflow from the showerhead, the LCD screen display the real-time shower water’s temperature. The LCD backlight only be activated when the water’s temperature more than the predefined threshold value (Initial threshold :35 ºC [95 ºF] ), the light color will display according to predefined as below. - Page 24 Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for faucets and showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 25 . Drying the sensor connector if water resided. LCD display error code “E20” . Drying the circuit board if water resided . Hardware or Software Original authorization Invalid, contact SUMERAIN technical LCD display error code “E30” support center. . the shower water’s temperature is less than predefined threshold value LCD backlight doesn’t activated...
