Summary of Contents for Spypoint FORCE-48
- Page 1 SPYPOINT FORCE-48 USER MANUAL v.1.1...
- Page 2 THANK YOU FOR CHOOSING A SPYPOINT PRODUCT The SPYPOINT FORCE-48 provides incredibly high-resolution images and This User Manual will introduce you to the features of your new FORCE-48 and 720p videos from the field for game scouting, wildlife tracking, and property will guide you through the acquisition of its functionalities so that you can use management.
-
Page 3: Table Of Contents
Table Of Content SPYPOINT FORCE-48 Components ..................4 Features ....................6 Power ......................7 Memory Card ..................8 Setup ...................... 10 Installation and Updates .............. 16 Transferring Files to a Computer ..........17 Offered Accessories ................ 18 Troubleshooting ................19 Warranty and Reparation............. 23... -
Page 4: Components
Components SPYPOINT FORCE-48 30 MP 01:35:20 (00016/02121) Menu press OK SETTUP OFF: The camera is OFF SETUP: View and manage camera settings ON: Camera is in detection mode Red light will ash for 30 s to allow you to move away. - Page 5 Components SPYPOINT FORCE-48 LOW GLOW FLASH SCREW-THREAD FOR STANDARD ¼”-20 Night lighting to obtain black-and-white photos and videos. Allows you to attach a standard tripod from ¼“-20. RED LED INDICATOR LCD SCREEN When the button is in the SETUP position and you’re done adjusting Allows the user to access the camera's settings menu.
-
Page 6: Features
Movement detector Infrared Date, time, temperature (°C/°F), moon Info bar Detection angle 40° phase, SPYPOINT logo, and camera model Detection range Up to 21 meters/70 feet Capture mode Colors by day, black and white by night Trigger speed 0.5 seconds... -
Page 7: Power
Power SPYPOINT FORCE-48 BATTERY LEVEL ICON FOR BEST RESULTS AND NO LEAKAGE The battery level is shown in the top right corner • Use only new alkaline or lithium batteries. of the screen when the camera is in SETUP • Do not mix new and old batteries. -
Page 8: Memory Card
Memory Card SPYPOINT FORCE-48 INSTALLING A MEMORY CARD PHOTOS RESOLUTIONS The use of a memory card is necessary for the operation of the camera. 16MP 30MP 48MP It allows you to save photos and videos. For better performance, we 8 GB... - Page 9 Before inserting the SD card into your camera, it must be formatted via a computer to ensure proper operations. Visit www.spypoint.com/en/support if you need help formatting your SD card. • Make sure the camera is turned OFF to prevent any loss or damage to photos already saved on the memory card.
-
Page 10: Setup
Setup SPYPOINT FORCE-48 GENERAL SETTINGS SETUP Use the buttons to switch to the LCD display or to change options, and press OK to select. Several setup pages will be displayed. 1. To turn the camera ON/OFF, use the ON/SETUP/OFF switch. - Page 11 SETUP SPYPOINT FORCE-48 ADJUST THE SETTINGS FOR THE 4 MODES OF OPERATION PHOTO MODE 1. Camera icon showing the Photo mode. 2. The number of mega pixels selected. 3. Battery power level icon. 4. Time. 5. Number of shots available on the SD card (photos taken so far/number of shots left).
- Page 12 SETUP SPYPOINT FORCE-48 HYBRID MODE 1. Camera icon showing the Hybrid mode. 2. The number of mega pixels selected. 3. Battery power level icon. 4. Time. 5. Number of shots available on the SD card (photos taken so far/number of shots left).
- Page 13 SETUP SPYPOINT FORCE-48 VIDEO MODE 1. Icon showing the Video mode. 2. Battery power level icon. 3. Time. 4. Approximate video time available for recording. 5. Press OK to access the settings. Allows you to choose the period of time to wait before the camera detects again and records the next video.
- Page 14 SETUP SPYPOINT FORCE-48 TIME-LAPSE MODE 1. Camera icon showing the Time-lapse mode. 2. Battery power level icon. 3. Time. 4. Number of shots available on the SD card (photos taken so far/number of shots left). 5. Press OK to access the settings.
- Page 15 RECYCLE The oldest photos on the SD card will be erased to allow the new photo to be saved. Displays the date, time, temperature, moon phase, SPYPOINT logo, and camera model on each photo. INFORMATION ON THE PHOTOS New moon...
-
Page 16: Installation And Updates
SPYPOINT FORCE-48 CAMERA SOFTWARE UPDATES INSTALLING YOUR CAMERA Go to www.spypoint.com/en/support for instructions on how to perform 1. To install the camera, loop the installation strap through the intended slot camera software updates. (see diagram). 2. Choose a solid tree that does not move in the wind, as movement will cause false detections. -
Page 17: Transferring Files To A Computer
• The computer will recognize the SD card. There may be two different disks folder to open it. In the “Home” tab, choose “Paste” (or click simultaneously on recognized, this is normal after use in the FORCE-48. the “Ctrl” and “V” keys). The photos and videos will be copied in the new folder. -
Page 18: Offered Accessories
16 GB SDHC UHS-1 memory card. 10-year warranty. Ultra high speed class 10. STEEL SECURITY BOX FOR 48 LEDS AND UP CAMERAS #SD-16GB Fits all 48 LEDs and up SPYPOINT cameras. For more information about other available accessories, #SB-400S go to www.spypoint.com. -
Page 19: Troubleshooting
1. Check if there are batteries in the camera. 2. Check if the batteries are correctly installed. IMPOSSIBLE TO TURN THE CAMERA ON 3. Install the latest update (available on www.spypoint.com under the SUPPORT section). 4. Replace the batteries. THE CAMERA'S SCREEN SHUTS OFF Turn OFF the camera and turn it ON again. - Page 20 SPYPOINT FORCE-48 PROBLEMS POSSIBLE SOLUTIONS 1. Make sure the camera is not pointing the sunrise or sunset, which could cause false detections. 2. At night, the motion detector can detect beyond the range of the infrared LEDs. Reduce camera sensitivity.
- Page 21 SPYPOINT FORCE-48 MESSAGES DISPLAYED ON THE SCREEN DESCRIPTIONS / SOLUTIONS A memory card is required to save videos and photos. Make sure the camera is turned OFF, NO CARD then insert the SD memory card and turn the camera back ON.
- Page 22 SPYPOINT FORCE-48 MESSAGES DISPLAYED ON THE SCREEN DESCRIPTIONS / SOLUTIONS 1. Try reformatting your SD card. FORMATTING ERROR 2. Replace your SD card. 1. Free up memory space on your SD card by backing up your photos and videos externally.
-
Page 23: Warranty And Reparation
FORCE-48 LIMITED WARRANTY This SPYPOINT product is covered by a 2-year warranty that also covers parts and workmanship from the purchase date. The electronic cash register receipt is a proof of purchase and must be presented to confirm that the warranty is applicable. -
Page 24: Regulation
SPYPOINT FORCE-48 | Made in China Distribution Center 3000 Gannett Avenue, Des Moines IA 50321 • USA SPYPOINT 330 de la Jacques-Cartier, Victoriaville QC G6T 1Y3 • Canada EUROHUNT GmbH Harzblick 25,99768 Harztor OT Ilfeld • Germany...
