12 Advanced functions
12.1 TV channels search
To perform a channel scan, press the MENU key and access the Channels menu, from which you will have
to define the Country where the TV is installed should it be a different one than the one chosen during the
initial installation (section 3), and choose the Antenna Type desired between:
1. Digital terrestrial: to search for channels broadcast in terrestrial digital (DVB-T / T2),
2. DVB-C: to search for channels broadcast by cable (DVB-C),
3. Digital SAT: to search for satellite broadcast channels (DVB-S / S2).
Depending on the Antenna Type selected, the Channels menu items change and then the corresponding
channel search procedure as described in the following paragraphs.
WARNINGS
Make sure that the chosen antenna cable is properly connected to the corresponding antenna input of the
TV. If you re-scan automatic channels, the list of previously memorized channels will be totally eliminated
and replaced by the one generated by the new search.
12.1.1 Terrestrial/Wire
From the Channel menu, select Terrestrial Digital as the Antenna Type. Subsequently, to perform an
automatic channel search move to the Automatic scan submenu and confirm the start with the ENTER key
on the Start scan item. Instead, to scan on a single frequency, go to the Manual Scan submenu, define the
desired search parameters (channel/frequency) and confirm the start of the scan by pressing the ENTER key
on the Start scan item.
Following similar steps to those described above, it is possible to search for digital channels transmitted by
cable choosing DVB-C as Antenna type in the Channel menu.
NOTE
At any time, you can press EXIT to finish the search in progress.
Cable transmission (DVB-C) is not normally used in Italy. Therefore, avoid selecting it when searching for
channels with a digital terrestrial antenna system.
12.1.2 Satellite
To activate the reception/viewing mode of the digital satellite channels, activate the corresponding TV
mode: press MENU, select the CHANNEL sub-menu and select Digital SAT.
If the satellite channels have not already been memorized, you must first configure the parameters of the
satellite antenna system in use (see section 5.1.2.1), then proceed to the channel scan (see section 5.1.2.2).
12.1.2.1 Antenna system configuration
The factory settings provide that the satellite system can receive signals simultaneously from 2 satellites via
DiSEqC switch, HotBird 13° East in first position and Astra 19.2° East in second position. If the system does
not correspond to the settings indicated, it is necessary to modify the default settings to make them
consistent with the satellite dish used.
