OCTOPACK

Troubleshooting

SYMPTOM
NO POWER LED INDICATION
NOTE: If the power supply voltage drops too low for normal operation, the LCD on the receivers will display a
"Low Battery" warning every few seconds. When the voltage drops to 5.5 volts, the LCD will dim and the audio
output level of the receivers will decrease.
SHORT OPERATING RANGE, DROPOUTS
OR WEAK OVERALL RF LEVEL
(RF level with receiver LCD)

Specifications

RF Bandwidth (3 versions):
RF Gain
Output Third Order Intercept:
1 dB Compression:
Antenna Inputs:
Antenna Power:
Receiver RF feeds:
External Power Requirement:
Power Consumption:
Dimensions:
Weight: Assembly only:
With 4-SR/5P receivers:
14
Low: 470 to 691 MHz
Mid: 537 to 768 MHz (export) High: 640 to 862 MHz (export)
0 to 2.0 dB across bandwidth
+41 dBm
+22 dBm
Standard 50 ohm BNC jacks
Voltage is passed through from main power source; 300 mApolyfuse in each BNC output
50 ohm right angle SMAjacks
8 to 18 VDC
1500 mA max. with 10 VDC (both antenna power supplies on)
H 2.75 in. x W10.00 in. x D 6.50 in. H 70 mm x W254 mm x D 165 mm
2 lbs., 9 ozs. (1.16 kg)
4 lbs., 6 ozs. (1.98 kg)
Specifications subject to change without notice
POSSIBLE CAUSE
1) Power switch in the OFF position.
2) Batteries low or dead
3) External DC source too low or disconnected
1) Passbands of Octopack and antennas may be different; (check
frequency of transmitter must be inside of both passbands
2) Antenna power switched off when external RF amplifiers are
being used
3) Antenna power interrupted by polyfuse; current consumption of
remote amplifier must be less than 300 mA on each BNC
4) Coaxial cable runs too long for the cable type
