- Page 1 FZ6 Microscope User’s Manual FZ6-AA, FZ6-BB, FZ6-BMSQ, FZ6-ILS2, FZ6-TS Fein info@feinoptic.com...
-
Page 2: Microscope Components
Microscope Components: Articulated Arm Stand Safety Collar Focusing Knob Arbor Focusing Holder FZ6-AASQ (Articulated Arm Stand) Eyepieces Microscope Head Stage Plate Focusing Knob Focusing Knob Focusing FZ6-TS Holder (Track Stand) Ball Bearing Boom Stand FZ6-BBSQ (Ball Bearing Boom Stand) Fein... - Page 3 Microscope Components: Trinocular Port Boom Stand Beam Splitter FZ6T-BMSQ (Boom Stand) Zoom Adjustment Focusing Knob Rheostat Light Reflected LED Controls Light Transmitted LED Light FZ6-ILS2 (LED Stand) Fein...
- Page 4 Stage Clips Stage Plate Note: When assembling FZ6 microscopes on articulated arm or boom stand, assembly is similar to the top part of the diagram shown above. Microscope body fits into focusing holder and focusing holder is attached with arbor or pin mount to the stand.
-
Page 5: Before Use
85%. When moving the microscope use both hands, holding by the base and the back of the microscope. FZ6-ILS2 For a clear image, ensure you do not leave fingerprints on the eyepieces or auxiliary lenses. Do not adjust the right and left focusing knob in opposite directions simultaneously. -
Page 6: Microscope Operation
Microscope Operation: Using Black/White Stage Plate: For the FZ6-TS or the FZ6-LPS a black/white stage plate may be used. Typically the white side of the stage plate faces upward. If the sample is a white or a bright color, place the black side up. To remove the stage plate press the supporting point shown at right. - Page 7 Using an Auxiliary Lens: The auxiliary lens screws onto the bottom of the body of the FZ6 and will change both magnification and working distance. Using the C-Mount Adapter: Screw the video tube (1) into the trinocular port. Loosen the set screw (2) on the tube to remove the c-mount threads (3).
- Page 8 FZ6 Microscope Magnification Options: 10x Eyepieces 15x Eyepieces 20x Eyepieces Auxiliary Working Lens Distance Zoom Mag Field Size Zoom Mag Field Size Zoom Mag Field Size 32.8mm - 23.9mm - 17.9mm - 1x (None) 100mm 6.7x - 45x 10.1x - 67.5x 13.4x - 90x...
-
Page 9: Troubleshooting
Troubleshooting: Optical Troubleshooting Problem Cause Solution LED light is too bright or too dark. Rheostat control is not set properly. Adjust rheostat control. Dirt or dust on sample. Clean sample. Dirt or dust on eyepiece. Clean eyepiece. Spots in field of view. Dirt or dust on objective lens. - Page 10 Troubleshooting: Electrical & Focusing Troubleshooting Problem Cause Solution Rheostat is turned all the way down. Adjust rheostat control. Bulb is burned out. Replace bulb. Bulb does not work. Fuse is burned out. Replace fuse. Dirt on the stage is blocking light path. Clean stage.
