- Page 1 1406CA Model Rev 0 Created Aug 21, 2023(wr) INSTRUCTION & PARTS LIST 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 2 Technical Manual & Part List...
-
Page 3: Atlanta Attachment Company, Inc
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials. -
Page 4: Table Of Contents
Technical Manual & Part List Table of Contents ATLANTA ATTACHMENT COMPANY, INC..........................2 CONFIDENTIAL AND PROPRIETARY INFORMATION ........................2 IMPORTANT SAFETY INSTRUCTION .............................. 5 MANDATORY INFORMATION ..............................5 SCOPE OF THE INSTRUCTION MATERIAL ............................5 INTENDED USE ..................................... 5 EXCLUSION OF MISUSE ................................ - Page 5 Technical Manual & Part List PNEUMATIC CONNECTION ................................. 12 MAINTENANCE ..................................12 GENERAL SAFETY INSTRUCTIONS ............................... 12 MAINTENANCE, CARE, ADJUSTMENT ............................13 WASTE, DISASSEMBLY, DISPOSAL .............................. 13 REPAIR ....................................... 13 REPLACEMENT PARTS ................................13 REPAIR, ELECTRICAL ................................... 13 VENTILATION/HAZARDOUS GASES ............................14 HYDRAULIC AND PNEUMATIC SYSTEMS ............................
-
Page 6: Important Safety Instruction
Technical Manual & Part List Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with your machine and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident. -
Page 7: Exclusion Of Misuse
Technical Manual & Part List Exclusion of Misuse Non-conforming uses include, for example, using the equipment for something other than it was designed for, as well as operation without duly installed safety equipment. The risk rests exclusively with the end user. Conforming use of the machine includes compliance with the technical data, information and regulations in all parts of the complete Instruction Material, as well as compliance with the maintenance regulations. -
Page 8: Training
Technical Manual & Part List machine should only be carried out by skilled personnel, under the management and supervision of a duly qualified engineer. This not only applies when the machine is used for production, but also for special work associated with its operation (start-up and maintenance), especially when it concerns work on the pneumatic or electrical systems, as well as on the software/serial bus system. -
Page 9: Damage
Technical Manual & Part List Damage If any changes capable of impairing safety are observed in the machine or its mode of operation, such as malfunctions, faults or changes in the machine or tools, appropriate steps must be taken immediately, the machine switched off and a proper lockout tagout procedure followed. -
Page 10: Smoking, Fire, Explosion Hazard
Technical Manual & Part List No Smoking, Fire, Explosion Hazard Smoking and open flame (e.g. welding work) should be prohibited in the production area due to the risk of fire and explosions. Workplace A clear working area without any obstructions whatsoever is essential for safe operation of the machine. The floor should be level and clean, without any waste. -
Page 11: Electrical Power Supply
Technical Manual & Part List oils, lubricants, plastics and coatings on the machine can give off gases and vapors that may be harmful to your health. A qualified person should be consulted to repair the damage after a fire. Electrical Power Supply Before undertaking any maintenance or repair work on the machine, switch off the electrical power to the machine at the main source and secure it with a padlock so that it cannot be switched on again without authorization. -
Page 12: Transport Damage
Technical Manual & Part List Transport Damage The packaging and machine must immediately be examined for signs of damage in transit. Such damage must be reported to the shipper/transporter within the applicable time limits. Contact us and/or your transport insurer without delay. Never operate a damaged machine. Interim Storage f the machine has to be stored temporarily, it must be oiled or greased and stored in a dry place where it is protected from the weather in order to avoid damage. -
Page 13: Local Regulations
Technical Manual & Part List Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. Machine Installation This equipment must be installed by an Atlanta Attachment Co. technician, or by a properly trained and authorized technician/mechanic. -
Page 14: Maintenance, Care, Adjustment
Technical Manual & Part List Maintenance, Care, Adjustment The activities and intervals specified in the Instruction Manual for carrying out adjustments, maintenance and inspections must be observed and parts replaced as specified. All hydraulic and pneumatic lines should be examined for leaks, loose connections, rubbing and damage whenever the machine is serviced. -
Page 15: Ventilation/Hazardous Gases
Technical Manual & Part List If it is necessary to carry out work on live parts, a second person should be on hand to operate the emergency OFF switch or master switch with voltage release in the event of an emergency. The working area should be cordoned off and marked by a warning sign. -
Page 16: Operation
Technical Manual & Part List Operation Touch Screen Details Main Ready Screen Operator Level Screens Technical Manual & Part List Page... - Page 17 Technical Manual & Part List Returns to Ready screen Language, press to select available Language Reset or reboot of program Exit – returns to previous page Piece Counter, press to access reset function Clock, press to set time Technical Manual & Part List Page...
- Page 18 Technical Manual & Part List Mechanic or Higher Security Level Screens Enter code to increase level Technical Manual & Part List Page...
- Page 19 Technical Manual & Part List Technical Manual & Part List Page...
- Page 20 Technical Manual & Part List Technical Manual & Part List Page...
-
Page 21: Assembly Drawings & Parts Lists
Technical Manual & Part List Assembly Drawings & Parts Lists The materials contained herein are confidential and proprietary information of Atlanta Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials. -
Page 22: 11406Ca Matt Compression Workstation, 45 X 64
Technical Manual & Part List 11406CA MATT COMPRESSION WORKSTATION, 45 x 64 AAC Drawing Number 9008890 Rev 1 Technical Manual & Part List Page... - Page 23 Technical Manual & Part List Technical Manual & Part List Page...
-
Page 24: 1278-6160G Foot Switch Assembly, 11458
Technical Manual & Part List 1278-6160G FOOT SWITCH ASSEMBLY, 11458 AAC Drawing Number 192819B Rev 1 Technical Manual & Part List Page... -
Page 25: 14061134 Hydraulic Power Package
Technical Manual & Part List 14061134 HYDRAULIC POWER PACKAGE AAC Drawing Number 14061134 Rev 0 Technical Manual & Part List Page... -
Page 26: 14061105 Compression Encorder Assembly
Technical Manual & Part List 14061105 COMPRESSION ENCORDER ASSEMBLY AAC Drawing Number 14061105 Rev 0 Technical Manual & Part List Page... -
Page 27: 1306600 Idler Pulley Assembly
Technical Manual & Part List 1306600 IDLER PULLEY ASSEMBLY AAC Drawing Number 1306600 Rev 0 Technical Manual & Part List Page... -
Page 28: 1306601 Positioning Encorder Assembly
Technical Manual & Part List 1306601 POSITIONING ENCORDER ASSEMBLY AAC Drawing Number 1306601 Rev 2 Technical Manual & Part List Page... -
Page 29: 14061205 Platten Assembly
Technical Manual & Part List 14061205 PLATTEN ASSEMBLY AAC Drawing Number 14061205 Rev 1 ITEM QTY. PART NUMBER DESCRIPTION ITEM QTY. PART NUMBER DESCRIPTION 1306320 MOUNT, BEARING,WELDMENT MM91665A630 SPRING,RETAINING,EXT,3" 1315062 BRACKET, BACKSTOP SENSOR MMGNSS8H30 GEAR, SPUR, 8P, 30T, 14.5PA 1315067 MOUNT, BACKSTOP SENSOR MMGRP207-20 BEARING, PILLOW BK, 1.25B... -
Page 30: 14061225 Main Console Assembly
Technical Manual & Part List 14061225 MAIN CONSOLE ASSEMBLY AAC Drawing Number 14061225 Rev 0 Technical Manual & Part List Page... - Page 31 Technical Manual & Part List 14061225 parts list ITEM QTY. PART NUMBER DESCRIPTION 0411-1063 ROD, THREADED, 5/8-11 X 5 1306005 RETAINER,SHAFT,GEARBOX 1393369 KEY, GEARMOTOR 1406005 BRACKET,MTG,BEARING 1406053 MOUNT, BEARING,SLIDE 1406103 MOTOR MOUNT BKT 1406106 MOTOR MOUNT PLATE 14061143 PLATE, NUT, 1/4-20 (4), 5/16X1.5X2.5 1406116 REGULATOR ASSY 14061170...
-
Page 32: 1406116 Regulator Assembly
Technical Manual & Part List 1406116 REGULATOR ASSEMBLY AAC Drawing Number 1406116 Rev 0 NO QTY PART # DESCRIPTION 1406114 MOUNT, REGULATOR AA198-5110 FILTER/REGULATOR/LOCKOUT AAFNAN200-02 MUFFLER,1/8 NPT AAQME-3-4 MALE ELBOW 3/8OD TUBE SSHC01048 1/4-20 X 3/4 HEX CAP WWFS1/4 WASHER,FLAT,SAE,1/4 WWL1/4 WASHER,LOCK, 1/4 Technical Manual &... -
Page 33: 14061170 Control Assembly
Technical Manual & Part List 14061170 CONTROL ASSEMBLY AAC Drawing Number 14061170 Rev 0 Technical Manual & Part List Page... - Page 34 Technical Manual & Part List Technical Manual & Part List Page...
-
Page 35: 14061177 E-Stop Assemlby
Technical Manual & Part List 14061177 E-STOP ASSEMLBY AAC Drawing Number 14061177 Rev Technical Manual & Part List Page... -
Page 36: 14061181 Touch Screen Assembly
Technical Manual & Part List 14061181 TOUCH SCREEN ASSEMBLY AAC Drawing Number 14061181 Rev 0 ITEM QTY. PART NUMBER DESCRIPTION 0411-3708 NUT PLATE,BOX MOUNT 1406059 MOUNT, TOUCH SCREEN 14061179 BUTTON BOX, E-STOP/START 4082105 TOUCHSCREEN. 10", SUB ASSEMBLY 4082105B HMI BACKING PLATE, EEE10TSM 4300574 MOUNT, HMI, PC DISPLAY NNE1/4-20... -
Page 37: 1406C-Hd Hydraulic Diagram
Technical Manual & Part List 1406C-HD Hydraulic diagram AAC Drawing Number 125595D Rev 0 Technical Manual & Part List Page... -
Page 38: 1406C-Pd Pneumatic Diagram
Technical Manual & Part List 1406C-PD Pneumatic Diagram AAC Drawing Number 125593D Rev 0 Technical Manual & Part List Page... -
Page 39: 1406A-Wd1 Wiring Diagram, Power
Technical Manual & Part List 1406A-WD1 Wiring Diagram, Power AAC Drawing Number 125687D Rev 0 Technical Manual & Part List Page... -
Page 40: 1406A-Wd2 Wiring Diagram, Serial Bus
Technical Manual & Part List 1406A-WD2 Wiring Diagram, Serial Bus AAC Drawing Number 125689D Rev 0 Technical Manual & Part List Page... -
Page 41: 1406A-Wd3 Wiring Diagram, Safety
Technical Manual & Part List 1406A-WD3 Wiring Diagram, Safety AAC Drawing Number 125017E Rev 0 Technical Manual & Part List Page... - Page 42 Technical Manual & Part List Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA Technical Manual & Part List Page...
