Atlanta Attachment Company 1390HCB Technical Manual & Parts Lists

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical Manual & Parts Lists
Model
1390HCB
Revision 1.2 Updated Aug 15, 2016
Atlanta Attachment Company
362 Industrial Park Drive
Lawrenceville, GA 30046
770-963-7369 • www.atlatt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1390HCB and is the answer not in the manual?

Questions and answers

Related Manuals for Atlanta Attachment Company 1390HCB

Summary of Contents for Atlanta Attachment Company 1390HCB

  • Page 1 Model 1390HCB Revision 1.2 Updated Aug 15, 2016 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
  • Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.

  • Page 4: Table Of Contents

    Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................
  • Page 5 Technical Manual & Parts Lists Manual 2 ..............................21 Manual 3 ..............................21 Setup ................................. 21 Setup Seals ..............................21 Other Operator Controls ........................... 22 Light Tower Indicator ..........................23 Motor Drives and Settings ........................24 Editing Motor Drive Parameters ....................... 25 Motor Drive Parameters ..........................
  • Page 6 Technical Manual & Parts Lists 1391056 Lower Roll Feed ........................65 1391446 Roller Assembly, 24” ......................... 66 1406758 Input Conveyor Assembly #4 ....................68 1406260 Upper Stop Eye Assembly ......................69 1406265 Lower Stop Eye Assemblies ...................... 70 1406297 Outfeed Frame Clamp Assembly ....................71 1406280 Power Cabinet, 480V .........................
  • Page 7 1391480 Pusher Assembly, Left ......................129 1391488 Pusher Assembly, Right ......................130 1391077 Gate Pivot Cylinder Assembly....................131 1391623 Infeed Sensor Assembly ......................132 1390HCB-PD Pneumatic Diagram ......................133 1390HCB-WD1 Wiring Diagram, Control Box ..................134 1390HCB-WD2 SBUS Wiring Diagram ....................135...

  • Page 8: Important Safety Instruction

    Mandatory Information All persons operating and/or working on the 1390HCB Autopack should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction.

  • Page 9: Liability

    Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.

  • Page 10: Safety Equipment On The Machines

    Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...

  • Page 11: Protective Eyewear

    Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.

  • Page 12: Important Notices

    Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated.
  • Page 13 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.

  • Page 14: Maintenance

    Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.

  • Page 15: Repair

    Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.

  • Page 16: A Word To The End User

    Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.

  • Page 17: Component Identification

    Technical Manual & Parts Lists Component Identification Figure 1...

  • Page 18: Machine Layout

    Technical Manual & Parts Lists Machine Layout Refer to Figure 1 on page Error! Bookmark not defined.. A. Infeed End 1. Top Film Roll storage 2. Bottom Film Roll Storage B. Machine Controls 3. Touch Screen 4. Pause/Stop Cable 5. Side Doors 6.

  • Page 19: Power Requirements

    Technical Manual & Parts Lists NOTE: The machine has 3 adjustable width settings. They are typically set to 84" for Cal-Kings, 80" for Queen, XL Full and Twin beds, and 76” for regular Full and Twin beds. If required, the width settings can be set to any three positions desired, within the 72”-85”...

  • Page 20: Machine Safety

    Technical Manual & Parts Lists Machine Safety The 1390B Auto-Pack is large machine and has many powerful drives and mechanisms. ANYONE assigned to operate and/or maintain this machine must be properly trained by an Atlanta Attachment technician, or a trained and qualified factory mechanic. Operation and/or maintenance of this machine by untrained personnel may result in a serious injury or even death.

  • Page 21: Warning 1

    Technical Manual & Parts Lists WARNING 1 In auto mode, this machine can start automatically at any time. Therefore, when the machine is turned - NEVER ENTER INSIDE THE MACHINE - NEVER CRAWL UNDER THE MACHINE - NEVER CLIMB ON TOP OF THE MACHINE - NEVER REACH INSIDE THE MACHINE FOR ANY REASON - NEVER PLACE ANY PART OF YOUR BODY INSIDE THE MACHINE WARNING 2...

  • Page 22: Machine Operation

    Technical Manual & Parts Lists Machine Operation Machine Start (Cold) 1. Turn the Main On/Off switch to the ON position. See Fig. 3. 2. Turn the Main Air valve to the ON position. The pressure gauge should be set to 80 PSI. See Fig. 4. 3.

  • Page 23: Bottom Film Loading

    Technical Manual & Parts Lists Bottom Film Loading The standard 1390HCB machine comes with a pull out Bottom Film Roll storage rack that can handle up to (3) 12” diameter x 120” long rolls of plastic film. The Bottom Film Rack can be assembled two ways so it can be pulled out to the left or to the right of the machine for loading.

  • Page 24: Top Film Loading

    Technical Manual & Parts Lists Top Film Loading The standard 1390HCB machine comes with a Top Film Roll storage rack that can handle up to (4) 12” diameter x 120” long rolls of plastic film. Important note! The film rolls must be loaded such that they unwind counter-clockwise, looking from the left side of the machine (see “Film Routing”...

  • Page 25: Film Routing

    Technical Manual & Parts Lists Film Routing The Top and the Bottom plastic film routing is very important. The illustration below (Figure 11) must be carefully followed. For the operator’s convenience, a copy of this illustration is attached to the left input post of the machine.

  • Page 26: Film Splicing

    Technical Manual & Parts Lists Film Splicing 1. When the plastic film runs out (from any roll), cut off the last 3 to 4 feet of it in order to eliminate any plastic that was adhered to the core and may have glue residue left on it. Make sure that there is no adhesive left on the film.

  • Page 27: Machine Controls

    Technical Manual & Parts Lists Machine Controls Main Screen Figure 13 This is the main screen. From this screen you can start the machine, see the temperature of all three seal bars, and view the piece count. You can also access the setup, manual and piece count screens.

  • Page 28: Manual 2

    Technical Manual & Parts Lists Manual 2 Figure 16a Manual 2 provides controls for infeed sizing and outfeed sizing. Manual 3 Figure 16b Manual 3 provides controls for the outfeed conveyor, cross sealing, side sealing. Note that pressing Reset will close the top and bottom film pinch rollers automatically.

  • Page 29: Other Operator Controls

    Technical Manual & Parts Lists Other Operator Controls 1. Emergency Stop & Power On - allows the machine to be turned on and stopped. 2. Stop Pull Cable - stretched above the INPUT conveyor in the loading area, allows the operator to quickly stop the machine in case of any problems.

  • Page 30: Light Tower Indicator

    Power is turned OFF, or otherwise disabled. Note: If the above indications do not solve the problem, please refer to “Troubleshooting” on page 42 of this manual for additional help or call Atlanta Attachment Company’s service department at 770-963- 7369.

  • Page 31: Motor Drives And Settings

    Technical Manual & Parts Lists Motor Drives and Settings The 1390B machine has four motor drives. The following images below show the physical drive locations. The table in the bottom right corner shows the drive machine parameters and their settings. These parameters may vary slightly based on the final installation requirements.

  • Page 32: Editing Motor Drive Parameters

    Technical Manual & Parts Lists Editing Motor Drive Parameters In effort to minimize the amount of information that the operator/mechanic has to look through, only the pages that pertain to the drive programming and drive faults are shown here. For more information refer to the manufacturer’s (AC Tech) manual included with the machine.

  • Page 33: Seal Bar Maintenance And Replacement

    Technical Manual & Parts Lists Seal Bar Maintenance and Replacement WARNING: Wait until the heat sealing bar has cooled enough (approx. 3 hours) before servicing seal bars or the areas near the bars. If maintenance on the machine is absolutely necessary before sealing bars have had a chance to cool down, the person performing the maintenance must use safety equipment approved by OSHA or local law to protect against burns.
  • Page 34 Technical Manual & Parts Lists There are four major variables for obtaining a good weld. 1. Temperature: The value is set via the control panel. The degrees are expressed in Fahrenheit. Try not to alter the temperature settings as much as possible. A variation of 5 degrees in Fahrenheit temperature will change the clarity of welded materials.

  • Page 35: Side Sealing Bars

    Technical Manual & Parts Lists Side Sealing Bars WARNING: Wait until the heat sealing bar has cooled enough (approx. 3 hours) before servicing seal bars or the areas near the bars. If maintenance on the machine is absolutely necessary before sealing bars have had a chance to cool down, the person performing the maintenance must use safety equipment approved by OSHA or local law to protect against burns.
  • Page 36 Technical Manual & Parts Lists Alignment (continued) Loosen the four screws (a) and (b) securing the two bearings and slide up or down to meet the proper angle. Check after each adjustment. It is very likely need to adjust the height of the bar. (F).

  • Page 37: Symptoms And Adjustments Of The Cross Seal Bar

    Technical Manual & Parts Lists Symptoms and adjustments of the cross seal Bar (a), (b), (c), (f) and (g) in the previous graph are types of heat sealing problems that also apply to the cross seal bar with the following additions: (D).

  • Page 38: Cross Bar Chain Tension

    Technical Manual & Parts Lists Cross Bar chain tension Chains are responsible for parallel movement of the cross seal bar. To check tension and adjust if needed: The chain (a) displacement is approximately 0.5 inches (12 mm) on center if light pressure is applied to the chain. The adjusting tensioners (c) are located at the upper ends of the chain system.

  • Page 39: Adjusting The Seal Bar Pressure

    Technical Manual & Parts Lists Adjusting the Seal bar Pressure Note: For cross seal bar see: symptoms and adjustment of cross seal bar. WARNING: Wait until the heat sealing bar has cooled enough (approx. 3 hours) before servicing seal bars or the areas near the bars. If maintenance on the machine is absolutely necessary before sealing bars have had a chance to cool down, the person performing the maintenance must use safety equipment approved by OSHA or local law to protect...
  • Page 40 Technical Manual & Parts Lists Example B Lack depth Good seal Good seal...

  • Page 41: Upper Seal Bar Element Replacement

    Technical Manual & Parts Lists Upper Seal Bar Element Replacement WARNING: Wait until the heat sealing bar has cooled enough (approx. 3 hours) before servicing seal bars or the areas near the bars. If maintenance on the machine is absolutely necessary before sealing bars have had a chance to cool down, the person performing the maintenance must use safety equipment approved by OSHA or local law to protect against burns.
  • Page 42 Technical Manual & Parts Lists 5) On the three tallest studs remove the top nut and back out the bottom nut to the end of stud without removing.
  • Page 43 Technical Manual & Parts Lists 6) Remove all of the remaining nuts from shorter studs. This will allow the seal bar assembly to slide out pass stainless steel guards far enough for servicing. Warning: It is imperative to lay out a large pad to protect parts being removed from this point on. 7) Using two closed end wrenches remove the nuts while leaving the bolts in place.
  • Page 44 Technical Manual & Parts Lists 10) On one end of the new heating element make a mark 3 ½” in from the tip with a sharpie. Starting with your mark begin inserting the heating element into the open slot of seal bar. Once in place, you should have 3 ½...
  • Page 45 Technical Manual & Parts Lists (4) Bend heat element up approximately 30 degrees. After replacement is complete refer to Adjusting the Seal bar Pressure on page 32 for final adjustments.

  • Page 46: Shimming The Seal Bar

    Technical Manual & Parts Lists Shimming the Seal Bar Note: For cross seal bar see: symptoms and adjustment of cross seal bar; once adjustment is complete, move to #3 on this page 30. Follow procedures for replacing Left and Right seal edge or heating element page.34. After replacement, some very important steps are needed for the system to perform properly.

  • Page 47: Mattress Size Adjustments

    Technical Manual & Parts Lists Mattress Size Adjustments The 1390HCB machine is designed to automatically detect and adjust itself for one of the two basic bed lengths: 75” and 80”. To detect the bed length, the machine uses one proximity sensor which is mounted on a rectangular guide rail.

  • Page 48: Lockout Procedure

    Technical Manual & Parts Lists Weekly Check the main air supply filter for any accumulation of oil or debris. Empty the filter bowl before it is filled to the maximum level indicated on the side of the bowl. Check the smoothness of the up/down movement of the Cross Seal Bar. If the bar chatters at all or does not move smooth, wipe the rods clean and apply a coat of sewing head oil to keep the rods lightly lubricated.

  • Page 49: Troubleshooting

    Technical Manual & Parts Lists Troubleshooting Machine does not power up when the Power ON button is pressed. 1. Check to make sure all four Emergency Stops are pulled out and operational. 2. Check for a short circuit. Turn off all breakers, and turn the machine back ON. If it comes ON, switch ON one breaker at a time.

  • Page 50: Sensor Adjustments

    Technical Manual & Parts Lists Sensor Adjustments Proximity Switch All proximity switches used on the 1390B machine have 8mm sensing range. The distance between the end of the sensor and the target flag should be set at about 5/32” for best performance. Cross Seal Photo Detector The amplifier sensitivity for the Cross Seal bar is located in the bottom-right corner of the main...

  • Page 51: Assembly Drawings & Parts Lists

    Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...
