Wavecom W 4010 User Manual page 9

To enter the configuration menu, the MODUL key has to be pressed while
switching the W 4010 on.
Key F1 Baud rate
Key F2 Length/Stoppbit
Key F3 Parity
Key F4 Stationaddress
Key BU-ZI Store Parameters
To leave this menu, switch the W 4010 off.
In the menu "settings"
TERMINAL-SETTINGS and DATA TRANSMISSION. This data have, of course, to
suit to that of the
W 4010.
Data transmission
Terminal emulation
Terminal settings
The configuration of the serial RS232 interface and the presetting of the
unit`s address can be effected at the configuration menu.
150
300
600
1200
2400
4800
9600
19200 Baud
7/1
7/2
8/1
8/2
none
even
odd
0 - 15
Storage of the configuration
following data
Connection to COM 1
Transmission rate to 9600 Baud
Databits to 7
Stoppbits to 1
Parity none
Hardware record or no record
TTY (common)
Terminal-Modi
X local echo
CR ---> CR/LF
column to 80
Baud
Baud
Baud
Baud
Baud
Baud
Baud
7 Databits, 1 Stoppbit
7 Databits, 2 Stoppbits
8 Databits, 1 Stoppbit
8 Databits, 2 Stoppbits
no parity
Even parity
Odd parity
have to be programmed
X line formatting
X Receipt and transmission
Page 9
under
