To enter the configuration menu, the MODUL key has to be pressed while switching the W
4010 on.
Key F1 Baudrate
Key F2 Length/Stoppbit
Key F3 Parity
Key F4 Stationaddress
Key BU-ZI Store Parameters
To leave this menu, switch the W 4010 off.
In the menu "settings" following data have to be programmed under TERMINAL-
SETTINGS and DATA TRANSMISSION. This data have, of course, to suit to that of the
W 4010.
Data transmission
Terminal emulation
Terminal settings
150 Baud
300 Baud
600 Baud
1200 Baud
2400 Baud
4800 Baud
9600 Baud
19200 Baud
7/1
7/2
8/1
8/2
none
even
odd
0 - 15
Storage of the configuration
Connection to COM 1
Transmission rate to 9600 Baud
Databits to 7
Stoppbits to 1
Parity none
Hardware record or no record
TTY (common)
Terminal-Modi X line formatting
X local echo
CR ---> CR/LF X Receipt and transmission column to 80
7 Databits, 1 Stoppbit
7 Databits, 2 Stoppbits
8 Databits, 1 Stoppbit
8 Databits, 2 Stoppbits
no parity
Even parity
Odd parity
