Cub Cadet 19A70030100 Installation Manual page 2

RZT Models with a Fixed Front Axle
1. Attach the left bracket to the left side of the front axle with
a 31⁄4-inch screw and 5⁄16" flange nut. Do not fully tighten the
hardware at this time. Repeat on the right side.
See Figure 1-3.
2. Secure the weight bar to the left bracket and right bracket
using the 21⁄2-inch screws and 3⁄8" flange nuts.
See Figure 1-4.
3. Tighten the hardware installed in step 1 to secure the
brackets to the front axle.
To order replacement parts, call the Customer Dealer Referral Line at 1-877-282-8684
Figure 1-3
Figure 1-4
or visit www.cubcadet.com to find the nearest Cub Cadet dealer in your area.
