Related Manuals for Hafele TANDEM 450
Summary of Contents for Hafele TANDEM 450
- Page 1 TANDEM 450 Name Mounting Instructions 450mm TANDEM swivel pull-out pantry 8 kg 3,5 kg 70 kg Empty weight + Load 4x20 4x16 Art. No. 732.25.660...
- Page 2 TANDEM 450 Name SYMBOLS Warning! Incorrect! Correct! Secure/Secured! Release/Released! Do not use a cordless screwdriver! Use a PZ2 screwdriver! PZ-2 Optional element! Audible click on engagement! All dimensions in mm! When a routered door or door with a routered pattern is being used with this mechanism please ensure the screw location is taken into consideration as the screw supplied may be too long.
- Page 3 TANDEM 450 Name min. 1700 1675 4x15 1 6 9...
- Page 4 TANDEM 450 Name Door right Door left min. 1700 1225 min. 1700 1225 In case of top bearing is in same hight as hinge, the bearing is to move to the next possible In case of top bearing is in same...
- Page 5 TANDEM 450 Name Door right 4x20 45er 397mm...
- Page 6 TANDEM 450 Name Door left Door left mounted State at delivery p. 5 10.1 10.2 For left mounted door mirror image...
