  • Page 1 PULSAR MEASUREMENT Greyline OCF 6.1 Instruction Manual Manual Version A.2.0...
  • Page 2 Note: This page has been left blank intentionally.

  • Page 3: Table Of Contents

    PULSAR MEASUREMENT CONTENTS CONNECTIONS ......................................... 4 KEYPAD SYSTEM ....................................... 6 CALIBRATION MENU ...................................... 7 ICONS ........................................... 8 MAIN DISPLAY........................................9 MESSAGE ICON ......................................... 9 STATUS ..........................................9 PASSWORD ........................................10 UNITS/MODE ........................................11 CALIBRATION ........................................13 CHANNEL SETUP ......................................16 RELAY PARAMETERS .....................................

  • Page 4: Connections

    OCF 6.1 INSTRUCTION MANUAL CONNECTIONS: POWER INPUT: The standard model requires AC power input between 100 to 240 VAC 50/60Hz. No adjustments are necessary for voltages within this range. Optional DC: 9-32 VDC. Connect to + and - terminals. Optional Thermostat and Heater modules are available rated for 115 VAC or 230 VAC. IMPORTANT NOTE: To comply with CSA/UL electrical safety standards, AC power input and relay connection wires must have conduit entry to the instrument enclosure.
  • Page 5 PULSAR MEASUREMENT CONNECTIONS SENSOR CORE SHLD SERIAL COMMUNICATION OPTION RS-485 Output EXTRA RELAYS OPTION RLY3 RLY4 RLY5 RLY6 POWER INPUT – 4-20mA HEATER OPTION RLY2 RLY1...

  • Page 6: Keypad System

    OCF 6.1 INSTRUCTION MANUAL KEYPAD SYSTEM The OCF 6.1 uses a menu system. Arrows show the four directions to leave a menu box. Press a key to move to the next item in the direction shown. Move the cursor (highlighted) under numerals and increase or decrease numerals with the ...

  • Page 7: Calibration Menu

    PULSAR MEASUREMENT CALIBRATION MENU --Units/Mode--------  Mode Flow Linear Volume --Techs Menu------- ’ Multiplier  Dist = Max Decimal Barrier Flow USG/m Standpipe Decimal Long Pulse Temperature Gain --Calibration-------  Range 32.00 ft This menu is accessed by 1.00 ft pressing &...

  • Page 8: Icons

    OCF 6.1 INSTRUCTION MANUAL ICONS  Message waiting. Press Data logging Data logging USB file download. File download completed. Download Error. Echo OK. Loss of Echo .

  • Page 9: Main Display

    PULSAR MEASUREMENT MAIN DISPLAY USG/m 0.000 The main display shows the units selected from the Units/Mode menu, Level, Range, Flow, HRT, and Volume rate being measured, TOTALIZER and RELAY states. The OCF 6.1 will start-up with this display. 20130.8 USG...

  • Page 10: Password

    OCF 6.1 INSTRUCTION MANUAL 24 HR LOG --24 hr log----------  Date Jun 22/2020 Total 50138 USG Press  from the main display to view a formatted flow report from Average 34.82 USG/m Maximum 52.20 USG/m instruments with a built-in data logger. Press  to scroll down one day or Max Time 11:08:00 repeatedly to scroll to a specific date.

  • Page 11: Units/Mode

    PULSAR MEASUREMENT UNITS/MODE --Units/Mode--------  Mode Flow Linear At Mode, press the  and then the  or  to select Flow or Velocity. Flow Volume Multiplier mode displays the flow rate in engineering units (e.g. gpm, litres/sec, etc.) Decimal Press the ...
  • Page 12 OCF 6.1 INSTRUCTION MANUAL UNITS/MODE cont. --Units/Mode--------  Mode Flow Linear At Flow, press the  and then the  or  to select the engineering units Volume Multiplier for flow rate. Press  to store your selection then  to the next menu item. Decimal Flow USG/m...

  • Page 13: Calibration

    PULSAR MEASUREMENT CALIBRATION --Calibration-------  Range 32.00 ft Press  to Calibration and  to enter. Use  or  to position  1.00 ft before each menu item and  to enter. When settings are completed press  Mode...
  • Page 14 OCF 6.1 INSTRUCTION MANUAL CALIBRATION cont. --Calibration-------  Range 32.00 ft Choose between OFF, FIR (Default), or LOW PASS. Damping 1.00 ft Mode Flow When measured flows are outside the Window of the 20mA 28.890 L/s running average, the FIR filter will reduce the damping 18.878 L/s Offset 0.00 ft...
  • Page 15 PULSAR MEASUREMENT CALIBRATION - for Open Channel Flow 1. Before starting the calibration determine: MAX RANGE = ____________________ (Maximum range = distance from the Sensor to Zero flow point) b) MAX LEVEL = ____________________ (Maximum level of flow through flume or weir)

  • Page 16: Channel Setup

    OCF 6.1 INSTRUCTION MANUAL CHANNEL SETUP Channel Setup-- ----  Type V-notch Custom Venturi Khafagi Rect Weir w/EC Rect Weir Trapez idal Montana Cutthroat HL Flume H Flume HS Flume Leopld-Lagco Palmer Bowlus Parshall Channel Setup-- ---- Channel Setup-- ---- --Channel Setup------ ...
  • Page 17 PULSAR MEASUREMENT CHANNEL SETUP cont. Channel Setup-- ---- Channel Setup-- ---- Channel Setup-- ----  Type HL Flume  Type H Flume  Type HS Flume Size 3.0ft Size 0.5ft Size 0.4ft 4.0ft 4.5ft 1.0ft 3.0ft 0.8ft 2.5ft 0.6ft 2.0ft 0.4ft...
  • Page 18 A curve fit is performed, and the software provides the K and n values to program into the meter. You can also contact a Pulsar Measurement technician for these values. IMPORTANT: The OCF requires that the K & n coefficients are from a flow equation where flow is in units of CFS, and head in units of feet.

  • Page 19: Relay Parameters

    PULSAR MEASUREMENT RELAY PARAMETERS --Relay Parameters--  Relay Function Flow Press  and  or  to select a relay (2 relays are standard, Relay 10000 USG/m 8000 USG/m 4 additional are optional). LOE mode Press  or  to select Off, Temperature, Function Pulse or Flow.

  • Page 20: Data Logging

    OCF 6.1 INSTRUCTION MANUAL DATA LOGGING --Data Logging------- Log Site ID Setup Mode Flow File Format .LG2 Date Jun 22/2020 Select Data Logging from Menu Selections. Time 11:27:40 Interval 10sec 60min Enter a number from 00 to 99. The site ID will 30min Log Site ID 15min...
  • Page 21 PULSAR MEASUREMENT RETRIEVE LOG FILE Plug a USB Flash Memory Drive (one is included with the OCF 6.1) into the USB output port on the instrument. The instrument display will show the USB file download icon until the log file is transferred to the memory card and then display file download completed icon.

  • Page 22: Special Functions

    OCF 6.1 INSTRUCTION MANUAL SPECIAL FUNCTIONS --Special Functions-  Language English Analog Out 4-20mA Select English, Spanish or French Language Backlight High Reset Totalizer Select 4-20mA or 0-5V mode for the analog output. Capture Par Analog Out Restore Defaults New Password 0000 Select High, Medium or Low for continuous Backlight...
  • Page 23 PULSAR MEASUREMENT SIMULATION --Simulation--------  Test Actual Flow 250USG Exercises the 4-20mA (0-5V) output, digital display and control relays. 4-20mA Flow 4.00 Relays 1 2 3 4 5 6 Select Maximum and press  to simulate maximum Test Flow, Range or Level and to output 20mA (5V) to the analog channel.

  • Page 24: Sensor Mounting Methods

    OCF 6.1 INSTRUCTION MANUAL SENSOR MOUNTING METHODS...
  • Page 25 PULSAR MEASUREMENT SENSOR MOUNTING/LOCATION - Open Channel Flow Applications Each sensor is equipped with a 3/4 inch isolation coupling which MUST be used in your installation. A threaded nipple or length of conduit may be used to position the sensor at the desired height. The sensor should be hand- tightened by turning the sensor stem only.
  • Page 26 OCF 6.1 INSTRUCTION MANUAL TYPICAL SENSOR POSITIONING FOR FLUMES AND WEIRS Always refer to the flume or weir manufacturer’s instructions for correct measurement point upstream from the flume or weir. Location of the sensor is critical for accurate flow measurement. If manufacturer’s instructions are not available, the following guidelines are generally accepted.
  • Page 27 PULSAR MEASUREMENT ZERO POSITIONING OF SENSOR - Open Channel Flow Applications Locate the sensor at the position upstream from the throat of the flume or weir plate as recommended by the manufacturer. A technique for accurate sensor height adjustment is shown:...
  • Page 28 OCF 6.1 INSTRUCTION MANUAL ENCLOSURE INSTALLATION Locate the enclosure within 20 ft (6 m) of the sensor (500 ft -150 m optional). The enclosure can be wall mounted with the four mounting screws (included) or panel mounted with Option PM Panel Mount kit from Pulsar Measurement.

  • Page 29: Error/Warning Messages

    PULSAR MEASUREMENT ERROR/WARNING MESSAGES No valid echoes received within the LOE TIME setting. The OCF 6.1 will force ECHO LOSS the display and outputs to zero until a new echo is received. Your choice of Units exceeds 9,999,999. Use USMG/d, IMG/d or m3/d...

  • Page 30: Field Troubleshooting

    OCF 6.1 INSTRUCTION MANUAL FIELD TROUBLESHOOTING SYMPTOMS CHECK Display - full scale - zero - erratic - random - drifting up - drifting down prompt - flashing ECHO LOSS Calibration Non-Linear SYMPTOMS FAULTS SOLUTIONS Unit “See’s” Wrong Target Due To: - sensor cover not removed - remove protective cover after installation A,C,D,F...
  • Page 31 PULSAR MEASUREMENT FIELD TROUBLESHOOTING Cont. SYMPTOMS CHECK Unit Picks-Up Interference Due To: - noise from high pressure fill - install submerged fill pipe - sensor coupling over tightened - hand tighten only (like a light bulb) - sensor coupling not used...
  • Page 32 OCF 6.1 INSTRUCTION MANUAL FIELD TROUBLESHOOTING Cont. SYMPTOMS CHECK Wiring Problems Due To Sensor Cable: - open circuit - check connections/continuity (8850 to 12700 A,C,F, ohms max./-30°C to +70°C) - short circuit - check connections/continuity (8850 ohms min.) - too long (max 500 ft., 150 m) - bundled/run in conduit with power cable - insulate - sensor ground shorted to...
  • Page 33 PULSAR MEASUREMENT PZxx Series Sensors Troubleshooting Resistance measured (between the shield and center wire) across the coaxial cable ends by mulitmeter indicates ambient temperature. Resistance vs. Temperature Values are in Ohms TEMP °C 10000 10039 10078 10117 10156 10195 10234...

  • Page 34: Applications Hotline

    Obtain an RMA Number from Pulsar Measurement - Before shipping a product to the factory please contact Pulsar Measurement by telephone, fax or email to obtain an RMA number (Returned Merchandise Authorization). This ensures fast service and correct billing or credit.
  • Page 35 If a product manufactured by Pulsar should prove defective within the first year, return it freight prepaid to Pulsar Measurement along with a copy of your invoice. This warranty does not cover damages due to improper installation or handling, acts of nature, or unauthorized service.

  • Page 36: Appendix A - Options

    Junction Box (Option JB2X) may be installed to extend cable up to 500 ft (152m) as required during installation. No adjustment is required when the sensor cable is extended or shortened. Use only RG62AU (or RG62U) coaxial cable which is available from Pulsar Measurement or your local distributor. Nominal impedance of RG62AU cable is 93 ohms.
  • Page 37 PULSAR MEASUREMENT EXTENDED SENSOR CABLE INSTALLATION IN MANHOLE MANHOLE COVER JB X XC EXTENDED SENSOR CABLE UP TO 500 ft 152 m CONDUIT TO ELECTRONICS ULTRASONIC SENSOR...
  • Page 38 OCF 6.1 INSTRUCTION MANUAL SENSOR INTRINSIC SAFETY (OPTION ISB) When connected through Intrinsic Safety Barriers, PZ** Series sensors are certified for installation in a hazardous location rated: Class I, Groups C,D Class II, Groups E,F,G Class III The Intrinsic Safety Barrier may be ordered with the instrument and is supplied mounted in the electronics enclosure.
  • Page 39 PULSAR MEASUREMENT GN SPEC ISB The intrinsic safety barrier assemblies installed in the OCF 6.1 limit the voltage and current supplied to the transducers to the values listed under ‘Barrier Specifications’. To safely install a Greyline transducer certified for use in...

  • Page 40: Modbus® Communication

    OCF 6.1 INSTRUCTION MANUAL MODBUS® COMMUNICATION MODBUS® serial interface connections are made at the RS485 card’s terminal block if your OCF 6.1 was ordered with this card, or if one was added after installation. Card location: SENSOR CORE SHLD SERIAL COMMUNICATION RS-485 Output EXTRA RELAYS OPTION...
  • Page 41 PULSAR MEASUREMENT Transceiver: 2-wire, half-duplex MODBUS Address (MAC address) range: 1-255 (Default: 001) BAUD rates: 4800, 9600, 19200, 38400, 57600, 76800 or 115200 (Default: 9600) Data Bits: Parity: None, Even, Odd (Default: Even) Stop Bits: 1, 2 (Default: 1) Termination: 120 Ohms or none (Default: None) Jumper JP1 position 1 &...
  • Page 42 OCF 6.1 INSTRUCTION MANUAL MODBUS® MEMORY MAP Register Description Register Data Over Read/ Comments Address Type Range Range Write Reset Volume Coil Read/ Turn coil ON (1) to reset total on OCF 6.1. Total Write Turn coil to OFF (0) once reset is complete. Register Description Register...
  • Page 43 PULSAR MEASUREMENT Register Description Register Type Format Type Comments Address 30114 Flow Rate - USG/day Input Register Floating Point Register (2 of 2) 30115 Flow Rate - ft Input Register Floating Point Register (1 of 2) 30116 Flow Rate - ft...
  • Page 44 OCF 6.1 INSTRUCTION MANUAL Register Description Register Type Format Type Comments Address 30139 Flow Rate - m /day Input Register Floating Point Register (1 of 2) 30140 Flow Rate - m /day Input Register Floating Point Register (2 of 2) 30141 Flow Rate - IG/sec Input Register...
  • Page 45 PULSAR MEASUREMENT Register Description Register Type Format Type Comments Address 30164 Flow Rate - bbl/day Input Register Floating Point Register (2 of 2) bbl = US Oil Barrel = 42 Gallons 30165 Previous day Average Input Register Floating Point Register (1 of 2)
  • Page 46 OCF 6.1 INSTRUCTION MANUAL Register Description Register Type Format Type Comments Address 30187 Previous day Average Input Register Floating Point Register (1 of 2) USMG = US Million Flow Rate - USMG/min Gallons 30188 Previous day Average Input Register Floating Point Register (2 of 2) USMG = US Million Flow Rate - USMG/min Gallons...
  • Page 47 PULSAR MEASUREMENT Register Description Register Type Format Type Comments Address 30211 Previous day Average Input Register Floating Point Register (1 of 2) IG = Imperial Gallons Flow Rate - IG/day 30212 Previous day Average Input Register Floating Point Register (2 of 2)
  • Page 48 OCF 6.1 INSTRUCTION MANUAL Register Description Register Type Format Type Comments Address 30307 Volume Total - m Input Register Floating Point Register (1 of 2) 30308 Volume Total - m Input Register Floating Point Register (2 of 2) 30309 Volume Total - USMG Input Register Floating Point Register (1 of 2) USMG = US Million...
  • Page 49 PULSAR MEASUREMENT Register Description Register Type Format Type Comments Address 30331 Previous day Volume Input Register Floating Point Register (1 of 2) bbl = US Oil Barrel = 42 Total - bbl Gallons 30332 Previous day Volume Input Register Floating Point Register (2 of 2)
  • Page 50 OCF 6.1 INSTRUCTION MANUAL Register Description Register Type Format Type Comments Address 30555 Sensor A Volume - m Input Register Floating Point Register (1 of 2) Tank volume, not flow volume. 30556 Sensor A Volume - m Input Register Floating Point Register (2 of 2) Tank volume, not flow volume.
  • Page 51 PULSAR MEASUREMENT Register Description Register Type Format Type Comments Address 30931 mA Output 1 - 20mA Input Register Floating Point Register (2 of 2) Value 30940 mA Output 1 - Output Input Register Floating Point Register (1 of 2) Current mA feedback on...
  • Page 52 OCF 6.1 INSTRUCTION MANUAL Register Description Register Type Format Type Comments Address 30951 Time Units Input Register Index (0 to 3) 0 = Second 1 = Minute 2 = Hour 3 = Day 30961 Echo Confidence Input Register Integer...
  • Page 53 PULSAR MEASUREMENT ENCLOSURE HEATER AND THERMOSTAT - Option TH Instruments can be factory-equipped with an Enclosure Heater and Thermostat or the module can be customer- installed. The Thermostat is factory set to turn ON at 40°F (4.5°C) and OFF at 60°F (15.5°C). Power consumption is 15 Watts.
  • Page 54 OCF 6.1 INSTRUCTION MANUAL POWER INPUT OPTION 9-32VDC OCF 6.1 Level & Flow Monitors may be ordered factory-configured for 9-32VDC power input. QUICK BENCH TEST: Connect Sensor as shown below, then Power. When properly connected figures will show on the large LCD display.

  • Page 55: Conversion Guide

    PULSAR MEASUREMENT CONVERSION GUIDE FROM MULTIPLY BY US GALLONS CUBIC FEET 0.1337 US GALLONS IMPERIAL GALS 0.8327 US GALLONS LITRES 3.785 US GALLONS CUBIC METERS 0.003785 LITRES/SEC 15.85 LITRES CUBIC METERS 0.001 BARRELS US GALLONS BARRELS IMPERIAL GALS 34.9726 BARRELS LITRES 158.9886...

  • Page 56: Specifications

    OCF 6.1 INSTRUCTION MANUAL SPECIFICATIONS 7.4 / 188 mm " 6.46 / 164 mm " 5.12 / 130 mm " Accuracy: ±0.25% of Measured Range or 2 mm, whichever is greater. Repeatability and Linearity: 0.1% F.S. Displays: White, backlit matrix - displays flow rate, totalizer, relay states, operating mode and calibration menu...
  • Page 57 PULSAR MEASUREMENT Optional Sensor PZ32T Maximum Range: 32 ft. (10 m) Deadband (blanking): Programmable, minimum 12” (305 Beam Angle: 8° at 3 DB Temperature Compensation: Automatic, continuous Operating Frequency: 42 KHz Exposed Materials: PVC and Teflon Operating Temperature: - 40° to 150°F (-40° to 65°C) Operating Pressure: 20 psi (1.35 Bar) maximum...
  • Page 58 OCF 6.1 INSTRUCTION MANUAL www.pulsarmeasurement.com service@pulsarmeasurement.com Copyright © 2020 Pulsar Measurement Ltd.. Registered Address: 1 Chamberlain Square CS, Birmingham B3 3AX Registered No.: 3345604 England & Wales Rev 1.0...
