Summary of Contents for Brooks VISALERTPlus
- Page 1 Plus VISALERT for Mains Power Instruction Manual Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your Alarm. The leaflet should be regarded as part of the product. If you are just installing the unit, the leaflet MUST be given to the householder.
-
Page 3: Table Of Contents
Contents Introduction 1.1 Features 1.2 Warning 1.3 Overview 1.4 Compatibility 1.5 Specifications 2. Installation and Wiring 2.1 Important Safety Instructions PLUS → Easi-fit base 2.2 Locating VISALERT 2.2.1 Visual alerting Device 2.2.2 Emergency luminaire PLUS → Easi-fit base 2.3 Mounting VISALERT 2.4 Wiring and Termination PLUS 2.5 Remnoving the VISALERT... - Page 4 3. Operation 3.1 Testing the Alarm System “TEST” 3.2 Fault Indications 4. Lithium Battery Warnings 5. Guarantee 6. Revision History Table of figures PLUS LED module Figure 1. VISALERT PLUS easi-fit Base Figure 2. VISALERT PLUS removed Figure 3. VISALERT PLUS without base Figure 4.
-
Page 5: Introduction
Introduction... -
Page 6: Features
PLUS continues Brooks’ commitment to fire safety for the hearing impaired. The VISALERT PLUS is the next generation of Brooks’ visual alerting devices designed to wake a VISALERT sleeping occupant. Brooks recognises the need to alert a sleeping occupant but also recognises PLUS , now includes that once awake they need to make their way to a place of safety. -
Page 7: Warning
Non-removable integrated rechargeable lithium batteries. • Up to 7 days back-up power in the event of power outages. • Interconnectible with Brooks’ range of 230Vac smoke, heat, carbon monoxide and multi sensor alarms. • Interconnection options for hardwired or wireless. -
Page 8: Overview
Overview PLUS are shown in Figure 1 below and the termination The front and rear views of the VISALERT section of the Easi-fit base is shown in Figure 2. PLUS LED module Figure 1 - VISALERT... -
Page 9: Figure 2. Visalert Plus Easi-Fit Base
PLUS easi-fit Base Figure 2 - VISALERT... -
Page 10: Compatibility
Compatibility Needs to be mounted to Easi-fit base. PLUS can be used with Brooks 230VAC hardwire alarms and interconnected via The VISALERT hardwire or wireless utilising EIB3000MRF module (if fitted). Interconnection of Brooks series alarms can be as follow: Hardwire interconnection alarms: •... -
Page 11: Figure 3. Visalert Plus Removed
PLUS removed Figure 3 - VISALERT... -
Page 12: Specifications
Specifications On Board Power Supply 230V AC, 50Hz, 18mA, 4 W with Lithium battery back-up Operating Temperature -0 °C to +40 °C Dimensions 147mm Dia x 60.4mm H, see Figure 4 Interconnection Up to 12 interconnected devices • External trigger Input wiring Open Circuit •... -
Page 13: Installation And Wiring
Installation and Wiring... -
Page 14: Important Safety Instructions
• The VISALERT consumer mains supply powering the smoke alarms to which it is interconnected. PLUS is designed to suit a Brooks Easi-fit Base and be mounted on a ceiling. • The VISALERT The device must not be exposed to dripping or splashing. -
Page 15: Locating Visalert Plus → Easi-Fit Base
• An appropriate disconnect device (e.g. Circuit Breaker) shall be provided to the circuit PLUS and the Alarms, as part of the building installation. powering the VISALERT PLUS • Mains must be turned off before installing / replacing the VISALERT PLUS or the Alarms from two different •... -
Page 16: Figure 5. Mounting And Preparing Easi-Fit Base For Termination
PLUS system and follows the same mounting procedure as base is supplied with the VISALERT those found with Brooks mains powered alarm systems. In Figure 5 below you will find the correct mounting procedure for the Easi-fit base. Steps for mounting Easi-fit base:... - Page 17 L: LIVE → connect to the house wires coloured brown or marked ‘L’ N: Neutral → connect to the house wires coloured blue or marked ‘N’ IC: Interconnect → connect to the common line between Brooks smoke alarms to trigger the alert in the event of an emergency.
-
Page 18: Figure 6. Visalert Plus Termination
Terminating procedure is as follows: PLUS termination Figure 6 - VISALERT Routing the mains cable for the Easi-fit base As denoted in the left figure above, if the mains wires are recessed, bring the wires through the port on the rear side of the Easi-fit base. As denoted in the right figure above, If the mains wires are being brought along the surface or through a conduit, enter through the removable trunking door on the side of the Easi-fit base. -
Page 19: Wiring And Termination
iii. If interfacing to 16mm trunking carefully cut around the marked section, leaving the top intact and replace the section. (If you are not using surface wiring, the removable section must be left in place for electrical safety reasons). iv. There are two other positions which are also suitable for the surface wiring to enter (and exit) the Alarm, one next to the removable section and another directly opposite Carefully align the mounting plate and screw into place. -
Page 20: Figure 7. Visalert Plus Connection Diagram
PLUS is mounted. interconnect (I) to where VISALERT Remove the terminal cover on the Easi-fit Base and terminate the incoming three wires L, N & I into the plug as shown in Figure 7 below. PLUS connection diagram Figure 7 - VISALERT... - Page 21 PLUS onto the Easi-fit Base by sliding the unit on left to right as Mount the VISALERT shown below: Warning: Mixing (or leaving unattached) the Live and Neutral connections when interconnecting Alarms/Controllers may damage all the interconnected devices - ensure that the same colour wires are used throughout the premises for Live, Neutral and Interconnect wires.
- Page 22 Easi-fit base. A maximum of 12 Smoke / Heat / CO / multi-sensor Alarms and accessory devices (e.g. FAC20 or PLUS ) can be interconnected in a Brooks Alarm system. Each device must be counted VISALERT when assessing the total number of devices.
-
Page 23: Remnoving The Visalert Plus
PLUS Removing the VISALERT PLUS is required to be removed from the easi-fit base, the same method to If the VISALERT remove any alarm from the easi-fit base can be used as shown in Figure 8 below. PLUS from the easi-fit base Figure 8 - Remove VISALERT... -
Page 24: Operation
Operation... -
Page 25: Testing The Alarm System "Test
Brooks recommend frequent testing of the system to ensure its continued and safe operation. PLUS : The following are guidelines for testing VISALERT • After the system is installed. • Once monthly thereafter. • After prolonged absence from the dwelling (e.g. after holiday period). - Page 26 Check the functioning of the mains battery back-up directly after installation and then at least yearly as follows: ➢ Turn off the mains power at the distribution board and check that the green indicator light is now flashing (1 flash every second) to indicate the Warning Device is on backup battery power.
- Page 27 Dip Switches...
-
Page 28: Fault Indications
PLUS has two flavours, flash (UL1971) for hearing impaired and steady (AS2293) The VISALERT to function as an emergency luminaire. Moving any dip switch to the STEADY function side will enable the emergency luminaire function. PLUS is triggered by In flash mode the LEDS will flash a high intensity when the VISALERT receiving an alarm signal from either the interconnect or the EIB3000MRF. -
Page 29: Lithium Battery Warnings
Internal Battery... - Page 30 PLUS is fitted with two lithium-Ion 2ICR19/66 batteries 7.2V, 2.42Ah, 17.42Wh. The VISALERT Do not dismantle, open or shred cells. b) Do not short-circuit a cell or battery. Do not attempt to remove the battery from its enclosure. d) Do not expose cells or batteries to heat or fire. Avoid storage in direct sunlight. Do not subject cells or batteries to mechanical shock.
-
Page 31: Guarantee
Guarantee... - Page 32 If the product has any defect due to faulty workmanship or material it is to be returned to Brooks freight paid. Brooks will, at its sole discretion, repair or replace the item free of charge. On returning the complete product, proof of purchase will be required, all accessories MUST be returned.
-
Page 33: Revision History
Revision History... - Page 34 Issue Date Description Written By Checked By 14/06/2024 Initial Revision...
- Page 35 Conforms to AS/NZS 62368.1:2022...
- Page 36 Brooks Australia PTY Ltd. Website: www.Brooks.com.au NSW - Head Office P.O. Box 7050 Silverwater NSW 1811 4 Pike Street Rydalmere NSW 2116 Ph: 02 9684 1466 9/71 Victoria Crescent, Abbotsford VIC 3067 Ph: 03 9879 5294 P.O. Box 101 Woodville SA 5011...
