- Page 1 SYSTEM MANUAL FT1-SB Single Zone Fire Alarm System...
- Page 2 Description Written By Draft 0 2/9/2008 Original Document. A. Shenouda C. Orr Issue 1 4/11/11 Update drawing in figure 7 A. Shenouda A. Shenouda Issue 2 18/11/19 Change Brooks addresses, logo and add some corrections to Iss 1 A. Shenouda...
-
Page 3: Table Of Contents
FT1-SB System Manual MA370 Iss. 2 INDEX INTRODUCTION ................................. 4 ......................... 4 MPORTANT NFORMATION ..........................4 YSTEM VERVIEW ............................5 PECIFICATIONS ..............................5 EATURES SYSTEM COMPONENTS ............................6 ......................... 6 RONT ISPLAY ODULE ...................... 7 ERMINATION AND ONTROL ODULE ............................8 OWER UPPLY CONTROLS AND INDICATIONS ........................... - Page 4 FT1-SB System Manual MA370 Iss. 2 FIGURE LIST Figure 1 FT1-SB Display ............................6 Figure 2 FT1-SB Termination & Control Module ....................7 Figure 3 Din rail Power supply..........................8 Figure 4 Typical Relay or Sounder Control Circuit ..................... 11 Figure 5 Zone Input Circuit ..........................
-
Page 5: Introduction
Introduction 1.1 Important Information The Brooks Firetracker FT1-SB is a customised single zone conventional fire alarm panel designed to protect switch boards. In conjunction with compatible smoke and/or heat detectors and auxiliary devices, FT1-SB provides a complete single zone automatic fire detection and alarm system. FT1- SB is designed to meet the requirements of the Australian standard AS7240.2 and for specific use... -
Page 6: Pecifications
Termination Module - 90mm x 106mm x 58mm (H/W/D) Power Supply – 90mm x 22mm x 100mm (H/W/D) 1.4 Features The Brooks FT1-SB system is designed to utilise state of the art technology: • Microprocessor based system for both display and termination/control modules. -
Page 7: System Components
MA370 Iss. 2 System Components 2.1 Front Display Module The front display of Brooks FT1-SB is shown in Figure 1. Figure 1 FT1-SB Display The front display of FT1SB compromises indicators and controls for the system functions as shown Figure 1 above. The alarm zone facility is segregated and includes a separate controls and LED indicators for each function, i.e. - Page 8 MA370 Iss. 2 2.2 Termination and Control Module The Termination & Control Module of Brooks FT1-SB is shown in Figure 2 below. Figure 2 FT1-SB Termination & Control Module The termination and control module to be mounted on a DIN rail at a convenient location within the switchboard cabinet.
-
Page 9: Figure 3 Din Rail Power Supply
FT1-SB System Manual MA370 Iss. 2 2.3 Power Supply Brooks FT1-SB is powered by a DIN rail switch mode power supply as shown in Figure below Figure 3 Din rail Power supply Features: Universal AC input • Short circuit / Overload / Over voltage Protections •... -
Page 10: Controls And Indications
FT1-SB System Manual MA370 Iss. 2 Controls and Indications Except the “Power ON” indicator, the default state of the LED indicators and the buzzer are OFF. 3.1 LED flash functions The FT1-SB LED indicators use the following flash pattern to signal the system conditions. Table 2 FT1-SB LED Indicating Patterns Indicators Pattern... - Page 11 FT1-SB System Manual MA370 Iss. 2 3.3 Control Functions Table 4 FT1-SB Control Buttons Control Condition Description Silences the panel buzzer until a new fault Buzzer Mute Buzzer Off or alarm occurs Reset active alarm or fault Disable active test mode. Reset System resetting Note: If alarm or fault condition still active,...
-
Page 12: Supervised Output
FT1-SB System Manual MA370 Iss. 2 3.4.2 Supervised Output FT1-SB provides one supervised voltage output protected with 1 Amp fuse. External relays, sounders, or strobes, shall be connected as shown in Figure 4 Figure 4 Typical Relay or Sounder Control Circuit If the supervised output is not used, the EOL resistor must be installed on the output terminals on the control / termination module. -
Page 13: Figure 5 Zone Input Circuit
FT1-SB System Manual MA370 Iss. 2 Table 6 Compatible Actuating Devices Part No. Manufacturer Description 4452 Panasonic Conventional photoelectric smoke detector 4375 Panasonic Conventional heat detector 60⁰ C 4376 Panasonic Conventional heat detector 80⁰ C 6295 Panasonic Conventional enclosed heat detector 60 degrees 6296 Panasonic Conventional enclosed heat detector 80 degrees... -
Page 14: Installation And Commissioning
INSTALLATION AND COMMISSIONING This chapter provides the installation and commissioning guidelines. The installation and the commissioning of Brooks FT1-SB shall be carried out in accordance of AS3000. The block wiring diagram of FT1-SB is shown in Figure 6 below. DET. -
Page 15: Figure 7 Control / Termination Module & Power Supply Mounting
FT1-SB System Manual MA370 Iss. 2 Figure 7 Control / Termination Module & Power Supply mounting Rear Front Figure 8 FT1-SB Front Display typical mounting... -
Page 16: Wiring
FT1-SB System Manual MA370 Iss. 2 4.1.2 Wiring The wiring of FT1-SB must be carries out according to the block wiring diagram shown in Figure 6, page 13. 4.1.3 Visual inspection Full functional testing and visual check is carried out in the factory for FT1-SB before delivery. Upon completion of installation and prior to applying power, a visual inspection should be carried out to ensure: All detectors are connected with the correct polarity. -
Page 17: Actual Test
FT1-SB System Manual MA370 Iss. 2 4.2.3 Actual Test Alarm Test 1. Using an aerosol smoke can, spray each smoke detector in turn and check the following: • Alarm LED illuminates steady Buzzer is steady On • • Alarm relays on the Control / Termination Module are energised Supervised alarm output is active (24V on the terminals) •... -
Page 18: Product Guarantee
