TD30,TD50,TD75
TD50
Wascomat provides efficient washers, dryers, flatwork ironers and wetcleaning systems
in a size and model for every laundry and wetcleaning need!
INSTALLATION MANUAL
OPERATING MANUAL
RMC
Dryer type TD30 from serial number: 20300 / 0021709
Dryer type TD50 from serial number: 20500 / 0016692
Dryer type TD75 from serial number: 20750 / 0006062
516-371-4400
516-371-4400
,TD75
DOC NO. 487 14 59 11 REV. 06
RMC
US
Advertisement
Table of Contents
Related Manuals for Wascomat TD30
Summary of Contents for Wascomat TD30
- Page 1 TD30,TD50,TD75 TD50 ,TD75 Dryer type TD30 from serial number: 20300 / 0021709 Dryer type TD50 from serial number: 20500 / 0016692 Dryer type TD75 from serial number: 20750 / 0006062 Wascomat provides efficient washers, dryers, flatwork ironers and wetcleaning systems...
- Page 2 If they are not registered, you can validate your warranty claim by providing information about when and where you purchased the Wascomat machine(s), the model and serial number(s). Additional warranty proof may also be required.
- Page 3 Dryer(s) must not be installed or stored in an area where it will be exposed to water and / or weather. The wiring diagram A for the dryer is located where shown. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 5 SECURE PLACE FOR FUTURE REFERENCE. Warning: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personnel injury or death. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 7 Be sure to keep the machine(s) in proper working order: Follow all maintenance and safety procedures. Further information regarding machine safety, service and parts can be obtained from your dealer or from Wascomat through its Customer Service Department . All requests for assistance must include the model, serial number and electrical characteristics as they appear on the machine identification plate.
- Page 8 DO NOT use dryer in the presence of dry cleaning solvents. DO NOT store or use flammable liquids or aerosols near dryer. 487 22 26 50 487 14 59 11 - TD30 TD50 TD75 US...
- Page 9 487 18 97 40.00 HÖYRYLIITÄNTÄ 487 18 97 40 Suurin sallittu paine 1000 kPa. LPG (propane) conversion kit. 487 22 26 53.00 Gas dryer only. 487 22 26 53 Steam dryer only 487 14 59 11 - TD30 TD50 TD75 US...
- Page 10 (service) door. The connecting wires must be properly sized to handle the rated current. NOTE: Component failure due to improper voltage application will VOID THE WARRANTY. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 11 2,000 feet are made by changing each burner orifice. If these conversions are necessary, contact your local dealer or the Wascomat Sales Department. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 12 An in-line pressure regulator must be installed in the gas supply line (header) if (natural) gas line pressure exceeds 12-inches water column pressure. (continued next page) 487 14 59 11 - TD30 TD50 TD75 US...
- Page 13 ALL components / materials must conform to NATIONAL FUEL GAS CODE specifications. It is important that gas pressure regulators meet applicable pressure requirements and that gas meters are rated for the total amount of appliance BTU’s being supplied. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 14 Do not try to light any appliance. Do not touch any electrical switch; do not use any phone in your building. Evacuate the room, building or area. Contact appropriate authorities. *Applies only to floor mops containing polypropylene. 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 15: Table Of Contents
Dimension sketch - Adapter for direct fresh-air intake ....51 The manufacturer reserves the right to modify design and material specifications without notice. 487 14 59 11 - TD30 TD50 TD75 US... -
Page 17: Dimension Sketch
8 3/4" 37 3/8" 83 1/2" 59 3/4" 10 5/8" 23 1/2" 5 5/8" 6 3/4" 8 3/4" 37 3/8" 90 1/2" 59 3/4" 10 5/8" 23 1/2" 5 5/8" 6 3/4" 487 14 59 11 - TD30 TD50 TD75 US... -
Page 18: Gas Heated Dryer
8” W.C. Propane gas: Minimum 13” W.C. 13” W.C. 13” W.C. Maximum < 70 dB (A) < 70 dB (A) < 70 dB (A) 11. Noise level: Gas heated -US only 487 14 59 11 - TD30 TD50 TD75 US... - Page 19 ISO 7/1-R1/2 ISO 7/1-R3/4 10. Gas pressure: See page regarding pressure 11. Noise level: < 70 dB (A) < 70 dB (A) < 70 dB (A) Gas heated - US only 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 20: Electric Heated Dryer
0.8” W.C. 1.3” W.C. Evacuation max. 9. - - 10. - - < 70 dB (A) < 70 dB (A) < 70 dB (A) 11. Noise level: Electric heated - US only 487 14 59 11 - TD30 TD50 TD75 US... - Page 21 80 Pa 200 Pa 340 Pa 9. - - 10. - - 11. Noise level: < 70 dB (A) < 70 dB (A) < 70 dB (A) Electric heated - US only 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 22: Steam Heated Dryer
Recommended pressure (absolute) 145 PSI 145 PSI 145 PSI Max. allowable pressure < 70 dB (A) < 70 dB (A) < 70 dB (A) 11. Noise level: Steam heated - US only 487 14 59 11 - TD30 TD50 TD75 US... - Page 23 Recommended pressure (absolute) 1000 kPa 1000 kPa 1000 kPa Max. allowable pressure < 70 dB (A) < 70 dB (A) < 70 dB (A) 11. Noise level: Steam heated - US only 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 24: Motor Specifications
1600 rpm 1700 rpm Revolutions per minute: Blower motor 1-phase: 0.55kW / 0.7hp Effect 3340 rpm Revolutions per minute: Drum motor 1-phase: 0.7kW / 0.9hp Effect 1700 rpm Revolutions per minute: 487 14 59 11 - TD30 TD50 TD75 US... - Page 25 Revolutions per minute: 2 x 1700 rpm Blower motor 3-phase: Effect 1.2kW / 1.6hp Revolutions per minute: 3200 rpm Drum motor 3-phase: Effect 0.37kW / 0.5hp Revolutions per minute: 1700 rpm 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 26: Setup
5. Fig. 4 Push the dryer from the front. 6. Remove the steel pipe by tilting the dryer forward while removing the pipe. If necessary, the dryer can be rolled into position using pipes. 487 14 59 11 - TD30 TD50 TD75 US... - Page 27 Section A-A Warning Don`t cover the top plate of the tumble dryer. There are vent holes in the top plate which must not be obstructed ! Gas dryers type 75 only. 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 28: Reversing The Door
10. Fig. 4 Mount door pin A on screw at door hinge. The new pin location must correspond with the new position of the door switch. To be continued on the following page. 487 14 59 11 - TD30 TD50 TD75 US... - Page 29 The dryer must stop. If the dryer starts with the door open, or fails to stop when the door is opened during operation, repair or replace the door switch, as necessary. 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 30: Special Installation
Kit no. 472 77 77 01. The four fittings are fastened to the base by means of 4 x M10 expander bolts. Drilling plan Type 3530 / 50 Type 3290 / 30 Type 3650 / 75 487 14 59 11 - TD30 TD50 TD75 US... -
Page 31: Exhaust System
After this, the air is evacuated through the blower and exhaust system. It is very important that the dryer gets enough fresh air, see next section. 487 14 59 11 - TD30 TD50 TD75 US... -
Page 32: Fresh-Air
Type 30: 250 cu.ft./min - 540 cu.ft./min (430 m /h - 925 m Type 50: 490 cu.ft./min - 810 cu.ft./min (840 m /h - 1380 m Type 75: 650 cu.ft./min (1100 m 487 14 59 11 - TD30 TD50 TD75 US... -
Page 33: Exhaust Duct
(minimum) (0.15) (0.35) (0.45) (0.60) (0.75) (0.90) (1.05) (1.20) (1.35) (1.50) 3 /4 3 /4 Each machine requires a 15 ” x 15 ” fresh-air inlet opening. (400 x 400 mm) 487 14 59 11 - TD30 TD50 TD75 US... - Page 34 Installation manual Evacuation system Gentle bends Several dryers on a shared exhaust duct 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 35: Nonreturn Flap
Service organization/dealer If you have questions relating to the design of the exhaust system, please contact your local dealer or service organization. Exhaust illustrations Acceptable wind wind wind Unacceptable wind wind 487 14 59 11 - TD30 TD50 TD75 US... -
Page 36: Steam Installation
The function check is described in the back of this manual. Pipe insulation All pipes must be insulated in order to reduce risk of burning. Insulation also reduces loss of heat to the surroundings. 487 14 59 11 - TD30 TD50 TD75 US... -
Page 37: General
NPT plugged tap, accessible for test gage connection, must be Pressure regulator installed immediately upstream from the gas (optional) propane only supply connections to the dryer. Gas shutoff valve ” NPT plugged tap 487 14 59 11 - TD30 TD50 TD75 US... - Page 38 6. Check that the gas is burning evenly and with a bluish flame. The numbers in brackets refer to the page regarding the gas valve. Function check The function check is described in the back of this manual. 487 14 59 11 - TD30 TD50 TD75 US...
- Page 39 Contact your dealer, or Wascomat, for the part number of the conversion kit appropriate for your altitude. Please contact your dealer or Wascomat if the current gas type is not propane / natural gas. 1. Remove nozzle.
-
Page 40: Gas Valve Type 30, Type 50
Gas installation - Type 30 and Type 50 Gas valve 1. Nozzle 2. Measuring branch, nozzle pressure 3. Cover screw 4. Adjusting screw 5. Control box, gas valve 6. Measuring branch, supply pressure 3 + 4 487 14 59 11 - TD30 TD50 TD75 US... -
Page 41: Gas Valve Type 75
Gas valve 1. Nozzle 2. Measuring branch, nozzle pressure 3. Cover screw 4. Adjusting screw 5. Control box, gas valve 6. Measuring branch, supply pressure 7. Air reducing plate. 3 + 4 487 14 59 11 - TD30 TD50 TD75 US... -
Page 42: Gas Installation
11.0 11.0 71600 Natural gas 37.78 Propane 93.7 11.0 11.0 136400 Natural gas 37.78 Propane 93.7 11.0 11.0 151200 Natural gas 37.78 ** Nozzle dimension at altitude up to 1999 ft. 487 14 59 11 - TD30 TD50 TD75 US... -
Page 43: Electric Installation
2. Pass the feeder cable through cable gland**, fig. 1. 3. Connect the feeder cable as illustrated. 4. Remount cover plate A. 5. Function check the dryer. The function check is described in the back of this manual. 487 14 59 11 - TD30 TD50 TD75 US... - Page 44 Electric heated dryer type 50 and 75 only On electric heated dryers the cable gland is not mounted. The cable gland is in the drum and has to be mounted on the beam. ∗ ∗ ∗ ∗ 487 14 59 11 - TD30 TD50 TD75 US...
- Page 45 Gas heating and Steam heating 3 connection 3 connection Gas heating and Steam heating Gas heating and Steam heating 1 connection 1 connection 120V - 1 AC 208-240V - 1 AC 487 14 59 11 - TD30 TD50 TD75 US...
-
Page 46: Fuse Sizes, Effects And Voltages Type 30
1.0 kW 14.5 kW Electric 400-480V 3AC 60HZ 13.5 kW 1.5 kW 15.0 kW 208-240V 3AC 60Hz 18 kW 1.0 kW 19.0 kW 400-480V 3AC 60Hz 18 kW 1.5 kW 19.5 kW 487 14 59 11 - TD30 TD50 TD75 US... -
Page 47: Fuse Sizes, Effects And Voltages Type 50
25.5 kW Electric 400-480V 3AC 60Hz 24 kW 1.5 kW 25.5 kW 208-240V 3AC 60Hz 30 kW 1.5 kW 31.5 kW 100A 400-480V 3AC 60Hz 30 kW 1.5 kW 31.5 kW 487 14 59 11 - TD30 TD50 TD75 US... -
Page 48: Fuse Sizes, Effects And Voltages Type 75
2 kW 208-240V 3AC 60Hz 30 kW 2 kW 32 kW 100A Electric 400-480V 3AC 60Hz 30 kW 2 kW 32 kW 400-480V 3AC 60Hz 36 kW 2 kW 38 kW 487 14 59 11 - TD30 TD50 TD75 US... -
Page 49: Connections Basic-3 Print Board
Installation manual Connections on Basic - 3 print board Single coin insertion slot White Double coin insertion slot Remote or card-operated start units ± 487 14 59 11 - TD30 TD50 TD75 US... -
Page 50: Function Check
Fig. 2 Remember to fit the screws on the sides of the front panel. Service organization / dealer If deficiencies or errors are detected, please contact your local service organization / dealer. 487 14 59 11 - TD30 TD50 TD75 US... -
Page 51: Dimension Sketch - Adapter For Direct Fresh-Air Intake
Ø12.4” (Ø 315) TD50, TD75 Ø15.75” (Ø 400) TD30 = 9 7/16" TD30 = 47" TD50 = 12 3/16" TD50 = 49 3/8" TD75 = 12 3/16" TD75 = 56 7/8" 487 14 59 11 - TD30 TD50 TD75 US... - Page 53 EXPAND, MODERNIZE, RETOOL OR BUILD A NEW LAUNDRY WITH LOW-COST FINANCING OR LEASING FROM WASCOMAT* With Wascomat/Viking financing or leasing you can obtain and install durable, efficient, state-of-the-art Wascomat washers, dryers and non-polluting, environmentally-friendly wetcleaning equipment to meet all anti-pollution regulations.
- Page 54 Coin operated and com m ercial wetcleaning need. energ y and gas efficient, user friendly W ith the push of a button, the unique Wascomat TD dryer m odels with optional unique Wascom at “Dual-Use” Wetcleaner converts to an ideal laundry Residual Moisture Control (RMC).
