- Page 1 Installation manual Tumble dryer SD–12E, SD–12G 0180500987C/EN Original instructions 2022.09.02...
-
Page 3: Table Of Contents
Contents Contents 1 Safety Precautions ..........................5 Gas heated tumble dryer: ......................7 General safety information......................7 Commercial use only........................7 Symbols............................8 2 Technical data.............................9 Drawing ............................9 Technical data .........................10 Connections ..........................10 3 Setup ............................... 11 Unpacking ..........................11 Recycling instruction for packaging ...................12 Siting ............................13 Mechanical installation ......................14 4 Reversing the door ..........................15... -
Page 5: Safety Precautions
Installation manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • The machine is not to be used if industrial chemicals have been used for cleaning. •... - Page 6 Installation manual • Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire.
-
Page 7: Gas Heated Tumble Dryer
Installation manual 1.1 Gas heated tumble dryer: • Before installation, check that the local distribution conditions, nature of gas and pres- sure and the adjustment of the appliance are compatible. • The machine is not to be installed in rooms containing cleaning machines with per- chloroethylene, TRICHLOROETHYLENE or CHLOROFLUOROCONTAINING HY- DROCARBONS as cleaning agents. -
Page 8: Symbols
Installation manual 1.4 Symbols Caution Caution, hot surface Caution, high voltage Read the instructions before using the machine... -
Page 9: Technical Data
Installation manual 2 Technical data 2.1 Drawing fig.W01608 Operating panel Door opening, ⌀ 570 mm Electrical connection Exhaust connection 1098 Footprint fig.X02473... -
Page 10: Technical Data
Installation manual 2.2 Technical data Net Weight（electric heating） Net Weight（Gas heating） Drum volume litres Drum diameter Drum depth Drum speed, medium load Rated capacity, filling factor 1:18 (Max. load) Heating: Electricity（230V） 4.84 Nominal Heat Input （Gas dryer） Maximum air flow m3/h Maximum static back pressure A-weighted emission sound pressure level at working stations... -
Page 11: Setup
Installation manual 3 Setup 3.1 Unpacking Note! Two persons are recommended for the unpacking. The machine is delivered fixed onto the transport pallet with packing strap. Remove packing strap from the machine then remove the transport pallet. Remove all the packing from the machine. Note! When moving the machine, handle it with care. -
Page 12: Recycling Instruction For Packaging
Installation manual 3.2 Recycling instruction for packaging fig.X02415 Fig. Description Code Type Cardboard packaging PAP 20 Paper Packaging box sticker PAP 22 Paper Bar code sticker PAP 22 Paper Wrapping film HDPE 2 Plastics Front corner protection PS 6 Plastics Back corner protection PS 6 Plastics... -
Page 13: Siting
Installation manual 3.3 Siting The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The following clearances are recommended: • The requirement to allow the door to open completely is 36 inches (91 cm). •... -
Page 14: Mechanical Installation
Installation manual 3.4 Mechanical installation Level the machine with the feet of the machine. The maximum height adjustment of the feet is 15 mm. It is important to lock the feet with nuts (A). For the gas dryer, the four feet should be locked with the expansion bolts and foot press plates in the accessory bag to prevent straining of the gas supply when the appliance is moved, at least the two diagonal feet should be fixed. -
Page 15: Reversing The Door
Installation manual 4 Reversing the door Disconnect the power to the machine. Demount the hinge and remove the door. fig.W01611 Demount the screws on the door module except for (A) and (B). Rotate back door plate parts (C) and the middle frame (D) by 180 degrees. - Page 16 Installation manual Demount the two magnets (A) and the protective cover (B) and move them to the opposite side. fig.W01613 Remount the two magnets (A) and the protective cover (B). Remount the door on the opposite side and fasten the hinges. fig.W01614 Connect the power to the machine.
-
Page 17: Evacuation System
Installation manual 5 Evacuation system 5.1 Air principle The fan creates low pressure in the machine, drawing air into the drum via the heating unit. The heated air passes through the garments and the drum holes. The air then flows out through a lint filter positioned below the drum. Then the air is evacuated through the fan and exhaust system. -
Page 18: Exhaust Duct
Installation manual 5.3 Exhaust duct • Only rigid or flexible metal duct should be used for exhausting. • Plastic ducting is not to be used. • Recommended material for exhaust is galvanized steel. • The duct is not to be assembled with screws of other fastening means that extend into the duct and catch lint. •... -
Page 19: Exhaust Dimensioning
Installation manual Number of machines ⌀ mm Exhaust duct Recommended 0.04 0.16 0.35 0.35 0.63 0.63 0.98 0.98 1.41 1.41 area of fresh air intake Minimum area of 0.03 0.117 0.223 0.31 0.351 0.468 0.585 0.702 0.846 1.17 fresh air intake The exhaust duct diameter must not be reduced. -
Page 20: Outside Ductwork Protection
Installation manual 5.6 Outside Ductwork Protection To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be in- stalled where the exhaust exits the building. If the ductwork travels vertically up through the roof, it should be pro- tected from the weather by using a 180°... -
Page 21: Electrical Connection
Installation manual 6 Electrical connection 6.1 Electrical installation The electrical installation may only be carried out by qualified personnel. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary. -
Page 22: Single-Phase Connection
Installation manual 6.2 Single-phase connection For electric heated dryer, demount the cover panel from the supply unit. Connect the earth and other wires as shown. ELECTRICAL CONNECTION (Electric heated) Grounding Wire Power Cord Power Cord Ground Screw (Green) Terminal Block Screw Outlet Receptacle –... -
Page 23: Install The Electronic Coin Meter (Coin Operated Models)
Installation manual 6.4 Install the Electronic Coin Meter (Coin Operated Models) 1. Unlock control panel with the provided key. 2. Loosen four screws in the control panel. 3. Extract the four terminals of the display PCB, and remove the main control panel, then demount the control panel seat. - Page 24 Installation manual 6. Mount the control panel seat carefully, don’t damage the coinmeter. 7. Reinstall the control panel seat by using the four screws. fig.W01622 the crossbeam plastic clip total four screws the four terminals of the display PCB (Electric heated) main control panel Connect the four terminals of the display PCB, the above figure shows the connection of four terminals of electric heating dryer, but for the gas heated dryer, the four terminals are directly connected to the display board.
-
Page 25: Gas Connection
Installation manual 7 Gas connection 7.1 Fasten the label Before installing the machine fasten the label the “user instructions” on the inside of the door in a suitable place and at the front panel. The label must have the correct country code, choose the correct label from the gas kit. User Instructions Read the technical instructions before installing the appliance. -
Page 26: Connect The Dryer To The Gas Supply
Installation manual 7.3 Connect the dryer to the gas supply 1. Remove the cap from the end of the gas inlet. 2. Install a female 3/8” NPT adampter at the end of the dryer gas inlet, the male size of the adampter is R1/2”. 3. -
Page 27: Table Of Pressure
Installation manual 7.5 Table of pressure The data label shows the injector size and the injector pressure and the countries that use this gas quality: (Pressure: 1mmH O=10Pa=0.1mbar) Liquiedpetrole- Gas category Inlet pressure Injector pres- Injector size (⌀ Reference gas Label code May be avail- um gases... - Page 28 Installation manual 1. Unplug dryer or disconnect power. 2. Turn off gas supply using the shut-off valve that supplies the dryer. 3. Remove the lower panel. fig.W01625 The Lower Panel Shut off the gas pipe valve. Use a wrench to lossen the hexagon nut union counterclockwise. fig.W01626 gas pipe valve union...
- Page 29 Installation manual Disconnect ignitor wires from harness and then take out the gas valve. Remove the burner injector from the valve and replace it with the injector inside the accessory bag. Torque the new injector to 30 in-lbs (3.4 N·m). Use the injector (diameter 1.21mm) for both Butane gas and Propane gas Grab the dimples (not the cap) with the lips of needle nosed pliers to twist the cover until the marking LPG point toward the base point.
- Page 30 Installation manual 14. Sign and date one of the STICKER B (Conversion Record) and apply it on the right side panel adjacent to the gas valve. 15. Reinstall the lower panel. fig.W01630 Apply STICKER B Here Leak Check 1. Turn on gas supply. 2.
- Page 31 Installation manual Pressure Test 1. Loosen the pressure measuring screw in the test nipple. 2. Connect the airtight hose to the pressure test nipple. (Airtight hose will attach between the pressure test nipple and manometer). 3. Connect opposite end of hose to manometer. 4.
-
Page 32: Data Label
Installation manual 7.8 Data label When the machine is to be converted to another gas type, the data label at the front panel of the machine must be updated in order for the data to be correct. Select the Sticker C (Rating Plate of Propane Gas) or Sticker D (Rating Plate of Butane Gas) in the accessory bag covering the original data label as shown below. -
Page 33: Coin Meter Operation
Installation manual 8 Coin meter operation In coin operated machines prices for programs and other operational parameters must be programmed during ma- chine setup. Prices can be programmed as Euros or as the number of coins or tokens required to start and to add additional dry- ing time. -
Page 34: Free Dry / Opl Mode
Installation manual 8.2 Free Dry / OPL Mode When the Amount To Start (ATS) register for a program is set to 0.00 (00 in “token mode”), the program operates in “Time per push mode” (this is free dry mode). In this mode, each time a program button is pressed, the remaining time is incremented. -
Page 35: Promotion Via The Real Time Clock (Rtc)
Installation manual 8.5 Promotion via the real time clock (RTC) The RTC and Promotion times are set and displayed in 24hr format. (e.g. 1:15 PM = 13:15). The promotion days of the week are represented by a two digit number (nn). The RTC’s built in calendar adjusts for leap years. Promotion set up requires setting the RTC and up to four pairs of Promotional start and stop times and percentages. -
Page 36: Function Check
Installation manual 9 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Whenever a repair has been made, a function check must be performed before the machine can be used again. Check the automatic stop of the machine •... -
Page 37: Disposal Information
Installation manual 11 Disposal information 11.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 40 Electrolux Professional AB 341 80 Ljungby, Sweden Share more of our thinking at www.wascomat.com...
