High Performance
+ 130 Watts Power Supply
+ Short Circuit Protection
+ Over Voltage Protection
+ Rack Mountable
+ Fan Failure LED
TECHNICAL SPECIFICATIONS
Product Specifications
DPS-510
LEDs
Protection
Electrical & Emissions Summary
Input Voltage
Output Voltage
Power Consumption
Heat Dissipation
Physical Specifications
Temperature
Humidity
Dimensions (Wx D x H)
Safety Agency Certifications
Safety
Warranty Information
Warranty*
Ordering Information
DPS-510
DES-3010PA
DPS-510 Redundant Power Supply
The DPS-510 is the backup Redundant Power Supply for
the DES-3010PA. When the DES-3010PA is equipped with
the DPS-510, both power supplies are switched on and
share the current load. In case the power supply of the
DES-3010PA should fail, the DPS-510 will instantaneously
take 100% of the load without any loss. The DPS-510
provides up to 130 Watts of redundant power to help insure
that even PoE powered devices such as phones, APs, and
cameras remain alive and active in the event the internal
power supply fails. In addition, the DPS-510 also supports
130 watt Redundant Power Supply for the DES-3010PA
Power, Fan Failure
Over voltage protection; short circuit protection
100 to 240 VAC, 50 ~60 Hz Internal Universal Power Supply
48V, 2.7A
130 watts. (max.)
13.9BTU
Operating: 0° ~ 40° C (32º to 104º F)
Storage: -10° ~ 70° C (14º to 158º F)
Operating: 10% ~ 90% RH, Non-condensing
Storage: 5% ~ 90% RH, Non-condensing
7.09" x 11.02" x 1.73" (180.1mm x 279.9mm x 43.9mm)
FCC Class A, CE Mark Class A, VCCI Class A, CUL
1-Year
130 Watt Redundant Power Supply
Managed L2 Switch with (8) 10/100Mbps PoE Ports and (1) Gigabit SFP and (1) 1000Base-T Copper Port
1-Year warranty available only in the U.S.A and Canada
*
a fan-failure signal to indicate when a fan is about to fail
based on detected reduced fan RPM. The DPS-510 is rack
mountable and can be mounted in an EIA standard-size
19-inch rack. If rack mounting is not required, the DPS-510
can also be easily placed on a desktop or wiring closet
shelf. The DPS-510 includes everything you need to get
started right out of the box including: AC Power cord, RPS
cable for connecting to the DES-3010PA, Rack mounting
brackets for rack installations and rubber feet for desktop
or shelf mounting.
D-Link Systems, Inc. 17595 Mt. Herrmann Street Fountain Valley CA 92708 www.dlink.com
©2004 - 2006 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link
logo, and RangeBooster N are trademarks or registered trademarks of D-Link Corporation
or its subsidiaries in the United States and other countries. Other trademarks or registered
trademarks are the property of their respective owners
