Infinity
Item ref: 150.467UK
User Manual
Flying Strobe Moving Head
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
A mesmerizing moving head comprising 2 panels of 250 bright RGB LEDs which combine with infinite Pan
and tilt movement to provide room filling effects from any position. The unit can be operated on show
mode, sound-to-light or by DMX and can be free standing or mounted to trussing using the supplied fixing
bracket. Ideal as a feature light in bars, nightclubs and functions, the Infinity moving head offers endless
possibilities.
In the box:
Infinity should arrive with you in a single carton in good condition. The carton should contain
1 x main unit with brackets, 1 x UK twist and lock mains lead and 1 x manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com
150.467UK User Manual
Advertisement
Related Manuals for Citronic Infinity
Summary of Contents for Citronic Infinity
- Page 1 The unit can be operated on show mode, sound-to-light or by DMX and can be free standing or mounted to trussing using the supplied fixing bracket. Ideal as a feature light in bars, nightclubs and functions, the Infinity moving head offers endless possibilities.
- Page 2 Placement: • Use the included mounting brackets to fix to a stand or lighting truss. • Use secondary safety fixings if mounting overhead. • Keep away from damp or dusty environments. • Ensure adequate airflow around the fixture housings. • Ensure adequate access to controls and connections.
-
Page 3: Manual Control Menu
Manual control menu: Press the “MENU” button to enter the settings menu. Press “UP” and “DOWN” buttons to navigate through various setting functions. Press “ENTER” button to confirm the desired setting: www.avsl.com 150.467UK User Manual... - Page 4 DMX mode: Infinity can be controlled by DMX signal, simply connect the DMX signal source to the DMX input on the unit via a balanced XLR lead. Extra fixtures can be controlled by the same DMX signal by looping through the DMX out on the unit.
- Page 5 15 Channel: www.avsl.com 150.467UK User Manual...
- Page 6 19 Channel: www.avsl.com 150.467UK User Manual...
- Page 7 Specifications: Power supply 110-240Vac, 50/60Hz (IEC) Power consumption 140W Fuse rating LED power 500 x 0.2W-RGB strobe Modes Show mode, sound, master/slave, DMX512 DMX channels 12, 15 and 19CH Beam angle 70° Pan range 360° infinite Tilt range 360° infinite Connections Power in/out (twist and lock), DMX in/out (3pin XLR) Dimensions...
-
Page 8: Troubleshooting
Troubleshooting: Check mains voltage is correct and outlet is switched on No power (mains) Check mains lead and fuse (if fuse continually blows, refer to your dealer) Check control panel mode settings No light output Check DMX settings from controller (dimmer levels, blackout etc.) Check that unit is in DMX mode and ensure the A on the DMX address flashes to confirm it’s receiving a DMX signal...
