SpectraBar
Item ref: 154.057UK
User Manual
LED Colour Blinder and Strobe Bar
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
The SpectraBar is a powerful 800W Multicolour LED stage-blinder bar that can produce a vast array of
moving effects, strobes and washes. Easy to setup and use via a wide range of integrated automatic and
sound to light programs or for more precise control there are 5 DMX modes to choose from. Fitted with
twist and lock power connections for a more professional feel and housed in an all-metal casing with fan
cooling for durability and reliable operation. Also supplied with fixing plates allowing end-to-end
connection to more units for a bigger effect.
In the box:
Your SpectraBar should arrive with you in a single carton in good condition. The carton should contain
1 x main unit, 1 fixing bracket with thumbscrews, 1 x twist and lock UK mains lead and 1 x user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com
154.057UK User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Citronic SpectraBar
Summary of Contents for Citronic SpectraBar
- Page 1 The SpectraBar is a powerful 800W Multicolour LED stage-blinder bar that can produce a vast array of moving effects, strobes and washes. Easy to setup and use via a wide range of integrated automatic and sound to light programs or for more precise control there are 5 DMX modes to choose from.
-
Page 2: Rear Panel Controls
Placement: • Use the included mounting bracket to fix to a stand or lighting truss. • Use secondary safety fixings if mounting overhead. • Keep away from damp or dusty environments. • Ensure adequate airflow around the fixture housings. • Ensure adequate access to controls and connections. -
Page 3: Dmx Mode
DMX mode: The SpectraBar can be controlled by DMX signal, simply connect the DMX signal source to the DMX input on the unit via a balanced XLR lead. Extra fixtures can be controlled by the same DMX signal by looping through the DMX out on the unit. - Page 4 116-119 Effect 29 120-123 Effect 30 124-127 Effect 31 128-131 Effect 32 132-135 Effect 33 136-139 Effect 34 140-143 Effect 35 144-147 Effect 36 148-151 Effect 37 152-155 Effect 38 156-159 Effect 39 160-163 Effect 40 164-167 Effect 41 168-171 Effect 42 172-175 Effect 43...
- Page 5 168-175 Effect 21 176-183 Effect 22 184-191 Effect 23 192-199 Effect 24 200-207 Effect 25 208-215 Auto Mode(Effect ) 216-223 DMX Sound mode1 224-231 DMX Sound mode2 232-255 DMX Sound mode3 No Function (CH2-Ch4) Dynamic effect1 (CH2-CH3 Control colour) 10-14 Dynamic effect2 (CH2-CH3 Control colour) 15-19 Dynamic effect3 (CH2-CH3 Control colour)
-
Page 6: Specifications
230-234 Dynamic effect47 (CH2-CH3 Control colour) 235-255 Dynamic effect48 (CH2-CH3 Control colour) 0-255 Effect Speed (slow -> Fast) No Function Strobe 10-255 Slow->Fast 36 Channel mode: Channel Value Function 0-255 LED1 Red (0-100%) 0-255 LED1 Green (0-100%) 0-255 LED1 Blue (0-100%) “”... - Page 7 Beam angle 135° Modes DMX, Master/Slave, Auto, Show, Sound DMX channels 5, 9, 36, 49 and 144CH Connections Power in/out (twist and lock), DMX in/out (3pin XLR) Dimensions 117 x 80 x 1000mm Weight 5.5kg Troubleshooting: Check mains voltage is correct and outlet is switched on No power (mains) Check twist and lock power lead is connected properly Check control panel mode settings...
