Cast Tec Cougar Inset Eco Plus Installation And Operating Instructions Manual

Multi-fuel stove

Advertisement

Quick Links

Cougar Inset Eco Plus Manual
Ref No: I17. V1.
COUGAR INSET ECO PLUS
Multi-fuel stove
Ref No: I17. V1.
Version 01 (03.10.2022)
Installation and Operating Instructions
The Cougar Inset Eco Plus stove must be installed by a suitably qualified engineer.
Instructions must be given to the user when installation is completed, and the installer must instruct user of the
correct use of the appliance and control operation.
The Cougar Inset Eco Plus is manufactured for Arbeia Trading Limited, a division of: Cast Tec Ltd. East Side,
Tyne Dock, South Shields NE33 5SP
Website:
www.casttec.co.uk
- Tel. 0191 4974280

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cougar Inset Eco Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Cast Tec Cougar Inset Eco Plus

  • Page 1 Instructions must be given to the user when installation is completed, and the installer must instruct user of the correct use of the appliance and control operation. The Cougar Inset Eco Plus is manufactured for Arbeia Trading Limited, a division of: Cast Tec Ltd. East Side, Tyne Dock, South Shields NE33 5SP Website: www.casttec.co.uk...
  • Page 2: Table Of Contents

    Cougar Inset Eco Plus Manual Ref No: I17. V1. TABLE OF CONTENTS THE CLEAN AIR ACT 1993 AND SMOKE CONTROL AREAS ..................3 INSTALLATION ESSENTIALS ..........................4 PRE-INSTALLATION CHECKS ..........................4 TECHNICAL INFORMATION ..........................5 INSTALLATION ..............................6 FITTING INSTRUCTIONS ............................8 FIT THE INDIVIDUAL COMPONENTS IN THE FOLLOWING ORDER ................
  • Page 3: The Clean Air Act 1993 And Smoke Control Areas

    The Cast Tec Cougar Inset Eco has been recommended as suitable for use in smoke control areas when burning wood logs. The Cast Tec Cougar Inset Eco must be fitted with a permanent stop to prevent closure of the secondary air control beyond 50% open.
  • Page 4: Installation Essentials

    Cougar Inset Eco Plus Manual Ref No: I17. V1. INSTALLATION ESSENTIALS The installation of a fireplace or stove must be in accordance with local codes and regulations in each country and other national and European standards that apply. Your Cougar Inset stove must be installed by a Competent Person registered with a Government Approved Competent Person’s Scheme.
  • Page 5: Technical Information

    Cougar Inset Eco Plus Manual Ref No: I17. V1. TECHNICAL INFORMATION TECHNICAL DATA ACCORDING TO NEN EN 13229:2001 and NEN EN13229 - A2: 2004 WOOD Anthracite STOVE Cougar Inset Eco Plus Multi-Fuel FUEL 4.6 kW 4.8 kW NOMINAL HEAT OUTPUT 79.2 %...
  • Page 6: Installation

    Cougar Inset Eco Plus Manual Ref No: I17. V1. INSTALLATION Unpacking the stove After removing the outer packaging, unbolt the combustion chamber from the wooden pallet and place it gently on its back. The cardboard packaging can be placed underneath to prevent marring. Remove the leg pack from the stove and bolt each leg securely to the underside of the base on the combustion chamber, using the bolts provided (found inside the stove).
  • Page 7 Cougar Inset Eco Plus Manual Ref No: I17. V1. Chimney THIS PRODUCT IS SUITABLE FOR CHIMNEY INSTALLATION ONLY. The stove is a radiant room heater and must be connected to a chimney of the proper size and type. The chimney must have a cross sectional area of at least 124cm2 or a diameter of at least 125mm.
  • Page 8: Fitting Instructions

    Cougar Inset Eco Plus Manual Ref No: I17. V1. FITTING INSTRUCTIONS Step 1. Prepare the fireplace area with fireback or milner brick removal. Ensure the opening is suitable for fitting of the insert stove opening required, i.e. remove fire surround trim if fitted.
  • Page 9: Fit The Individual Components In The Following Order

    Cougar Inset Eco Plus Manual Ref No: I17. V1. FIT THE INDIVIDUAL COMPONENTS IN THE FOLLOWING ORDER 1. Grate Support Tilt the grate support up on one side and pass it carefully through the door opening. 2. Grate The grate simply lays into the grate...
  • Page 10: Down Draughts

    Cougar Inset Eco Plus Manual Ref No: I17. V1. DOWN DRAUGHTS However well designed constructed and positioned, the satisfactory performance of the flue can be adversely affected by down draught caused by nearby hills, adjacent tall buildings or trees. These can deflect wind to blow directly down the flue or create a zone of low pressure over the terminal.
  • Page 11: Permanent Air Vent Extractor

    Cougar Inset Eco Plus Manual Ref No: I17. V1. An air vent outside the building should not be located less than the dimensions specified within the Building Regulations and B.S. 8303: Part 1 from any part of any flue terminal.
  • Page 12: Commissioning & Handover

    Cougar Inset Eco Plus Manual Ref No: I17. V1. COMMISSIONING & HANDOVER On completion of the installation allow a suitable period of time for any fire cement and mortar to dry out, when a small fire may be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and emitted safely to the atmosphere.
  • Page 13 Cougar Inset Eco Plus Manual Ref No: I17. V1. Fig. 6 If there is a studded wall surrounding the fireplace as in Fig.6, ensure the clearances in this Fig7 are adhered to. Cast Tec Ltd...
  • Page 14: Floor Protection

    Cougar Inset Eco Plus Manual Ref No: I17. V1. FLOOR PROTECTION It is recommended that this appliance is installed on a solid, level, concrete base, a non combustible hearth conforming to current Building Regulations must extend to the front of the appliance.
  • Page 15: Use

    Cougar Inset Eco Plus Manual Ref No: I17. V1. • Painted products: the fireplace may emit an irritating gas when used for the first time, and it may smell a little. The gas is not toxic, but the room should be thoroughly ventilated.
  • Page 16 Cougar Inset Eco Plus Manual Ref No: I17. V1. Very Important: Wood is a material that contains a great deal of gas (approximately 75 %). The gases are released when the wood is lit and heated up. For this reason, it is important that the gases are ignited quickly after stoking.
  • Page 17 Cougar Inset Eco Plus Manual Ref No: I17. V1. Very Important: The stove door should never be opened when the stove is being fired vigorously. l We would strongly recommend that you do not leave your stove alit at night. It...
  • Page 18: Ash Removal

    Cougar Inset Eco Plus Manual Ref No: I17. V1. ASH REMOVAL Fig. 9 (Use of ashpan) It is essential to keep the grate free from a heavy build up of ashes. This product is equipped with a grate riddling device which is used to “shake”...
  • Page 19: Spare Parts

    Cougar Inset Eco Plus Manual Ref No: I17. V1. SPARE PARTS Cast Tec Ltd...
  • Page 20 Cougar Inset Eco Plus Manual Ref No: I17. V1. SPARE PARTS TABLE Name Code Quantity Frame I1403 Grate I1114 Moving grate I1115 Collar 125(2) Ashpan handle CA0105 Door I1407 Spin valve CAF0660 Fire bar I1120V2 Inside frame CANK01 Outside frame...
  • Page 21 Cougar Inset Eco Plus Manual Ref No: I17. V1. SPARE PARTS TABLE Name Code Quantity Washer CA0321 Roller CA0148 Back brick FRI17U211 Back brick FRI17U211-A Left brick FRI17U212 Right brick FRI17U213 Baffle FRI17U229 Glass CA10-I11 Door handle catch CA1507A Cylindrical type handle...
  • Page 22: Operational Problems & Troubleshooting

    Cougar Inset Eco Plus Manual Ref No: I17. V1. OPERATIONAL PROBLEMS & TROUBLESHOOTING PROBLEM PROBABLE CAUSES ACTION • Use the recommended fuel. • Wood green, too damp • To light the fire, use small, very dry or poor quality. twigs.
  • Page 23 Cougar Inset Eco Plus Manual Ref No: I17. V1. Cast Tec Ltd...
