Cycling the Unit

The fans continue to free-wheel for several minutes when the unit cycles off. This is normal. If

the unit is furnished with an Xtreme low ambient control, the condenser fan also cycles on and

off during cooling. This maintains the head pressure on the compressor under Xtreme low

ambient conditions, and is normal. The bottom of the compressor stays warm even when the unit

is off to keep the lubricating oil warm and separated from the refrigerant.

Normal settings are between 54 and 58 Deg F (12-14 Deg C).

Wine cellars have a natural temperature gradient of approximately 5 to 10 degrees between floor

and ceiling. To increase or decrease the temperature in various zones, change the air flow

patterns.

To keep the entire wine cellar at the same temperature, set the remote interface controller to run

the supply fan continuously and not just when the cooling is operating. Set Setting 7 to Setting

NOTE: To monitor the Cellar Temperature, place thermometers in various

locations in the cellar to monitor the temperature zones. Change the

temperature in various zones by shifting the air flow patterns.

The optional grilles furnished with Wine Guardian are single directional. Rotate the grilles to

change the direction of the air flow.

When using multiple supply ductwork, it is necessary to balance the air flow between the

ductwork. If too much air flows though one duct but not enough air flows from the other duct,

install a damper or other restriction into the duct with too much air. That will force more air to

flow out the other duct.
